System Components

Enclosures

BB-1024 BB-1072

Flush Trim Rings

Batteries

W = 5 15/16"
H = 3 3/4"
BA-124
D = 4"
BA-110
W = 7 1/8"
H = 6 1/2"
D = 3"
BA-140
BA-117
Figures Not Drawn to Scale

Remote Annunciators

UP TO UP TO
32 ZONES 80 ZONES
4
Model
BB-1024
(add suffix "R" for red
enclosure)
BB-1072 (add suffix "R" for
red enclosure)
Model
FA-UNIV-TRB (add suffix
"R" for red enclosure)
FA-1072TR
(add another suffix R for
red enclosure)
Model
W = 6 1/2"
H = 5"
D =6 7/8"
W = 7 5/8" 12-volt batteries (2
H = 6 7/8"
required for 24 volts)
D = 6 3/8"
Model
RA-1000 Series
UP TO
128 ZONES
Description
Surface enclosure 24 circuits
Surface enclosure 72 circuits
Description
Flush trim ring in Black
Flush trim ring
Description
10 to 40 AH
Description
Remote multiplex annunciator panels
