System Status Messages

After installing the RC7/RC7GS, the LCD screen displays operating system
status messages which is the default screen after exiting all other setting or
meter functions. Operating parameters include; Battery State-of-charge (SOC),
Time Remaining to Run, Time Left to Charge and Set Shore Power. The Gen
Start-Stop switch is also available from these displays (RC7GS only).
Press the DOWN arrow to scroll through each display. When the last menu
item is reached, the display wraps back to the first menu item in a continuous
loop.
1.

Battery State of Charge

This meter displays the estimated state-of-charge (SOC) of the battery or
battery bank. The SOC is based on the estimated battery capacity. Since
discharging the batteries to less than one half of their amp-hour capacity may
damage the batteries, the meter estimates the 0% SOC and protects the
batteries from over discharge.
The display can be viewed as a percent-of-capacity or bar graph by
pressing the Settings push-button (RIGHT arrow).
Battery State of Charge Displays (Percent and Bar Graph)
2.

Time Left to Run

This meter displays the estimated hours the batteries will support the load
before requiring recharging. The meter is accurate to 1/10 of an hour
(6 minutes).
1 999 Trace Engineering
ã
Batt State of Charge:
xx% Full
Figure 62
Time Left to Run:
x.x Hours
Figure 63
Time Left to Run Display
RC7 & RC7GS Remote Controls
Batt State of Charge:
E [] [] [] [] [] [] [] [] [] F
3.0 OPERATION
