RC7 & RC7GS Remote Controls
3.0 OPERATION

RC7GS Setup Menu

The RC7GS (Generator Start) features several additional setup menu
selections related to automatic generator starting, stopping and generator quiet
time.
1.

Set Clock (RC7GS only)

Some generator functions are based on the time of day. The clock must be
properly set to ensure the programmed function will perform at the correct time.
The clock uses 24-hour time and ranges from 00:00 to 23:59.
To access the Set Clk menu, scroll down past the generator menus by
pressing the DOWN arrow. A flashing cursor appears below (and behind) the
hour (H) or minute (M) characters in the display. Every eight seconds the cursor
alternates positions. When the cursor is under the hour digit, press the Settings
push-button to increment the hours to the current hour (00 to 23). When the
cursor is under the minutes digit, press the Settings push-button to increment the
minutes to the current minute (0 to 59). Press and hold the Settings push-button
to quickly increment the time, or press and release to increment the selected
digit by one unit at a time.
Increments Digit
(Settings push-button)
14
Figure 23
RC7GS Front Panel
Hour selected
Set Clk: 0-23:59
HH:MM
Figure 24
Set Clock Display
