RC7 & RC7GS Remote Controls
3.0 OPERATION
7. Transformer Temperature
This meter displays the internal temperature of the inverter/charger's
transformer. The scale is divided into counts, which do not directly correspond to
the Fahrenheit or Celsius temperature scale. A higher reading indicates a lower
temperature. This meter is useful for service technicians.
8. FET Temperature
This meter displays the relative temperature of the Field Effect Transistors.
The scale is divided into counts, which do not directly correspond to the
Fahrenheit or Celsius temperature scale. A higher reading indicates a lower
temperature. This meter is useful for service technicians.
9. Estimated Battery Capacity
This meter displays the estimated battery amp-hour capacity based upon
the average amp-hours used and the rate and duration of the charging cycles.
Multiply the reading by eight to arrive at the approximate battery capacity. This is
only an approximation and becomes more accurate as the number of charge/
discharge cycles increases (approximately 15–20 charge/discharge cycles).
NOTE: If battery power is removed from the inverter, the calculation process
restarts. 15–20 charge/discharge cycles must complete to reach accurate battery
capacity.
30
Xformer Temp:
000 Counts
Meter Mode Display–Transformer Temperature
FET Temp:
000 Counts
Meter Mode Display–FET Temperature
Est. Bat. Cap:
Meter Mode Display–Estimated Battery Capacity
Figure 59
Figure 60
00 Amp-hrs(x8)
Figure 61
