RC7 & RC7GS Remote Controls
3.0 OPERATION
3.

Inverter LED

The green Inverter LED indicates the inverter is switched ON and ready to
provide backup power. If there is no ac power, the inverter LED will be ON solid,
indicating that the inverter/charger is in the inverter (ON) mode.
Inverter LED
ON (solid)
Flashing
Slow Flash
Flashing
OFF
4.

Charge LED

The Charge LED indicates the current battery charge mode.
Charge LED
ON (solid)
Slow Flash
Fast Flash
Very Fast Flash
OFF
5.

Batt. Full LED

The Batt. Full LED indicates the state of charge on the batteries. This LED
will not illuminate until the batteries have charged up to at least 90%. The
duration of the LED's ON time will increase until the batteries reach 100%, which
at that time, the LED will be ON solid. In the inverter mode, the OFF time
duration of the LED will increase until the batteries discharge to below 90% at
which time the LED will extinguish.
Batt. Full LED
Solid
Flashing
OFF
6.

Error LED

The Error LED indicates that there is a problem with the inverter/charger or
batteries. Check the LCD display to find and correct the nature of the problem.
Error
ON (solid)
6
Other LEDs or Devices
Charge LED (flashing)
Error LED ON + Buzzer
Other LEDs or Devices
Batt. Full LED ON
Other LEDs or Devices
Other LEDs or Devices
Meaning
Inverter ON
Inverter ready (charging)
Load Sense Searching
Inverter Error
Inverter Switched OFF
Meaning
Bulk Charging
Absorption Charging
Float Charging
Equalize Charging
Inverter Mode (no charging)
Meaning
Battery Fully Charged (100%)
Battery Charged 90% or
higher
Battery Below 90% Charge
Meaning
Check System
