Trace Engineering RC7 Installation And Operator's Manual page 19

8. LCD Contrast
The LCD Contrast menu adjusts the contrast to accommodate changing
lighting conditions and viewing angle. The default setting is Max. Contrast.
LCD Contrast:
LCD Contrast:
Max Contrast 87%
9. External Shunt
When two inverter/chargers are utilized in a system, an additional RC7 can
be used as a battery "fuel gauge." This requires an external shunt. Refer to the
inverter/charger's Operator's manual for instructions on installing an external
shunt. The External Shunt menu selects the fuelgauge unit. The default is None.
External Shunt:
None
10. Fuelgauge Cutout
The Fuelgauge Cutout menu sets the battery voltage zero percent state of
charge (0% SOC) with no load. This is the point at which the battery has zero
reserve amp-hours remaining. The Fuelgauge meter uses this number to
determine the 0% battery state-of-charge voltage. The default is 9.5 VDC.
Fuelgauge Cutout:
Fuelgauge Cutout:
9.5VDC=0%SOC
10.3VDC=0%SOC
1 999 Trace Engineering
ã
RC7 & RC7GS Remote Controls
LCD Contrast:
• • • •
62%
Figure 20
LCD Contrast Selections
External Shunt: External Shunt:
This Inverter Other Inverter
Figure 21
External Shunt Selections
• • • • • • • •
Figure 22
Fuelgauge Cutout Selections
3.0 OPERATION
LCD Contrast:
• • • •
Min Contrast
Fuelgauge Cutout:
Fuelgauge Cutout:
11.8VDC=0%SOC
11.7VDC=0%SOC
13
