System Status Messages

AC Source Inverter Mode
System Status:
System Status:
Searching
Waiting for AC
System Status:
System Status:
Inverting
AC Available
System Status:
Pending Genstart
System Status:
Cranking Genset
Genset Status:
Starter Cooldown
Operating Display
Bat State Of Chg
Bat State Of Chg
XX% of Full
E
Time Left To Run
X.X Hours
Time Left toChg
X.X Hours
Gen Start/Stop:
Press (On/Off)
The Settings arrow enables you to move
across the columns. The Menu
Down arrows enable you to scroll through
the headings along the left column.
©
Copyright Trace Engineering Co. Inc.
t h
5916 195 Street, NE
Arlington, WA 98223 USA
Charger Mode
System Status:
Bulk Charging
System Status:
AbsorptionChg
System Status:
Float Charging
RC7GS Only
Avg Shunt Amps
-/+ 0 Amps DC
F
Battery:
00.0 Volts DC
Inv/Chg Current:
+/- 0 Amps DC
AC Input
000 Vac 000 Vpk
AC Output:
000 Vac
Up and
AC Input:
0 Amps AC
Tel (360) 435-8826
Fax (360)435-2229
www.traceengineering.com
Error Mode
System Status:
Otemp/Less Load
System Status:
Oload/Less Load
System Status:
Hibat Stop Charge
System Status:
Lobat Start Charge
System Status:
Gen Wont start
System Status:
Low Genset Volts
System Status:
Gen Quiet Fault
Meters Display
Pass-thru Amps:
0 Amps AC
Battery Temp
000 counts
Xformer Temp:
000 counts
FET Temp:
000 counts
Est. Bat. Cap:
47 Amp-hrs(x8)
