KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
MAIN GEAR ASSEMBLY
(2) Main gear carbon
(2) 75mm diameter wheel
(2) Fiberglass wheel pant
(2) Set of axles
(4) 4mm x 20mm machine screws
(4) 4mm flat washers
(4) 8mm flat washers
TAIL WHEEL ASSEMBLY
(1) Tail wheel bracket w/ wire
(1) 25mm diameter wheel
(1) Plate Aluminum
(2) 3mm x 10mm wood screws
(2) 3mm x 20mm machine screws
(2) Spring
(2) 3mm flat washers
ELEVATOR CONTROL SYSTEM
(2) Set control horn
(2) 3mm x 20mm machine screws
(4) Aluminum ball
(4) Nylon ball link
(4) 3mm x 12mm screws
(2) 6mm flat washer
(2) 3mm nut
(1) 3mm x 165mm metal pushrod
(1) 3mm x 105mm metal pushrod

KIT CONTENTS

RUDDER CONTROL SYSTEM
(1) Set control horn
(1) 3mm x 35mm machine screws
(2) Aluminum ball
(2) Nylon ball link
(2) 3mm x 12mm screws
(1) 6mm flat washer
(1) 3mm nut
(1) 3mm x 85mm metal pushrod
AILERON CONTROL SYSTEM
(2) Set control horn
(2) 3mm x 35mm machine screws
(4) Aluminum ball
(4) Nylon ball link
(4) 3mm x 12mm screws
(2) 6mm flat washer
(2) 3mm nut
(2) 3mm x 80mm metal pushrod
MOTOR MOUNT ASSEMBLY
(2) Engine mount
(4) 4mm x 30mm screws
(8) 4mm flat washer
(4) 8mm flat washer
(4) 4mm x 30mm screws
(8) 4mm nut
1
EDGE 540
THROTTLE CONTROL SYSTEM
(1) 1,3mm x 600mm wire
(1) 3,5mm x 350mm nylon
pushrod housing
(1) Metal connector
FUEL TANK
(1) Nylon fuel Tank
(1) Metal clunk
(1) Pre - assembled stopper w / 3 tube
MISCELLANEOUS ITEMS
(1) Aluminum dihedral
(4) Wing screws
(2) 4mm x 30mm nylon screws
(4) 2.6mm x 10mm wood screws
(2) 4mm x 35mm wood screws
(1) Wooden plate
(1) Wood box
(4) Triangular wooden
(1) Spinner
(2) 8mm flat washer
(1) Cowling
(1) Decal
(1) Instruction manual
