Triggering an Ethernet Frame Delay Measurements Session

Table 3: Monitor Ethernet Delay Command Parameters

Parameter Parameter Range
one-way or two-way NA
remote-mac-address Unicast MAC address
1–8191
mep identifier
maintenance-domain Existing MD name
name
maintenance-association Existing MA identifier
ma-id
count count 1–65535 (default: 10)
Copyright © 2012, Juniper Networks, Inc.
To perform Ethernet frame delay measurement, make sure that the following
configuration statement is NOT present:
[edit routing-options]
ppm {
no-delegate-processing; # This turns distributed PPMD OFF.
}
Ethernet OAM
Ethernet Frame Delay Measurements on page 119
Triggering an ETH-DM Session on page 123
Viewing ETH-DM Statistics on page 124
Configuring One-Way ETH-DM with Single-Tagged Interfaces on page 125
Configuring Two-Way ETH-DM with Single-Tagged Interfaces on page 130
Configuring ETH-DM with Untagged Interfaces on page 134
Before Ethernet frame delay measurement statistics can be displayed, they must be
collected. To trigger Ethernet frame delay measurement, use the
delay-measurement (one-way | two-way) (remote-mac-address | mep identifier)
maintenance-domain name maintenance-association ma-id [count count] [wait time]
operational command.
The fields for this command are described in
Description
Perform a one-way or two-way (round-trip) delay measurement.
Send delay measurement frames to the destination unicast MAC address
(use the format xx:xx:xx:xx:xx:xx). Multicast MAC addresses are not
supported.
The MEP identifier to use for the measurement. The discovered MAC
address for this MEP identifier is used.
Specifies an existing maintenance domain (MD) to use for the
measurement.
Specifies an existing maintenance association (MA) identifier to use for
the measurement.
(Optional) Specifies the number of Ethernet frame delay frames to send.
The default is 10.
Chapter 11: ITU-T Y.1731 Ethernet Frame Delay Measurements
Table 3 on page 123.
monitor ethernet
