JUNOS Enhanced Services J-series
Services Router Quick Start
12 October 2007
Part Number: 530-021753-01
Revision 1
JUNOS Enhanced Services J-series Services Routers provide flow-based security
services, IP routing, WAN and LAN connectivity, and management services. Available
in several models, Services Routers typically connect small, branch, or regional offices
to a central site, and link Internet service provider (ISP) networks.
The JUNOS Enhanced Services J-series Services Router Quick Start provides instructions
to initially set up J2320, J2350, J4350, and J6350 Services Routers. You need no
previous JUNOS software experience, but must have managed a network and
configured other routers. For more information, see the JUNOS Enhanced Services
J-series documentation at
What You Need To Know ................................................................................3
Management IP Address ...........................................................................3
J-Web Access ............................................................................................3
CLI Console Access ...................................................................................3
Secure Context and Router Context ..........................................................3
Required Licenses .....................................................................................4
Slot Numbers ............................................................................................4
Interfaces and Ports ..................................................................................4
Remote Access .........................................................................................4
Before You Begin .............................................................................................5
Installing a Services Router .............................................................................6
Installing J2320 and J2350 Services Routers .............................................6
Installing J4350 or J6350 Services Routers ................................................7
Connecting Power to a Services Router ...........................................................8
http://www.juniper.net/techpubs
.
1
Advertisement
Table of Contents
Related Manuals for Juniper JUNOS J Series
Summary of Contents for Juniper JUNOS J Series
-
Page 1: Table Of Contents
J2320, J2350, J4350, and J6350 Services Routers. You need no previous JUNOS software experience, but must have managed a network and configured other routers. For more information, see the JUNOS Enhanced Services J-series documentation at http://www.juniper.net/techpubs Contents What You Need To Know ................3 Management IP Address ................3 J-Web Access ....................3... - Page 2 JUNOS Enhanced Services J-series Services Router Quick Start Basic Connection and Configuration with the J-Web Interface ......9 Step 1. Connecting, Logging In, and Starting the J-Web Interface .....9 Step 2. Configuring Basic Settings with J-Web Quick Configuration ..10 Step 3. Installing the JUNOS Enhanced Services Software .......12 Step 4.
-
Page 3: Contents What You Need To Know
What You Need To Know What You Need To Know Management IP Address When you first connect a management PC or laptop to a built-in Ethernet port on a Services Router, the router acts as a DHCP client and attempts to perform an autoinstallation. -
Page 4: Required Licenses
JUNOS Enhanced Services J-series Services Router Quick Start To protect against attacks launched from within the zone, the following screens are enabled for the untrust zone: ICMP ping-of-death, IP source route options, IP teardrop, TCP land attack, and TCP SYN flood. The default policy for the untrust zone denies all traffic. -
Page 5: Before You Begin
Before You Begin Before You Begin Before installing and connecting a Services Router, read Safety Warnings Summary” on page 17. Then make sure you have the equipment listed in Table 1 on page 5. Table 1: Equipment Required for Services Router Installation Electrical Connection Rack Installation Management Access... -
Page 6: Installing A Services Router
JUNOS Enhanced Services J-series Services Router Quick Start Attach the mounting brackets to either the center or front of the chassis, as shown in Figure 2 on page 6. Figure 2: Attaching Mounting Brackets Installing a Services Router WARNING: DC-powered Services Routers are intended for installation in a restricted access location. -
Page 7: Installing J4350 Or J6350 Services Routers
Installing a Services Router Figure 4: Hanging a J2350 Router in a Rack Have a second person install a mounting screw into each of the two aligned holes. With a number 2 Phillips screwdriver, tighten the screws. Verify that the mounting screw on one side of the rack is aligned with the mounting screw on the opposite side and that the router is level. -
Page 8: Connecting Power To A Services Router
JUNOS Enhanced Services J-series Services Router Quick Start Figure 5: Hanging the Router in the Rack Install at least two mounting screws into each mounting bracket, in addition to the center screws from which the router hangs. Connecting Power to a Services Router J2320, J2350, and J4350 Services Routers have a fixed power supply. -
Page 9: Basic Connection And Configuration With The J-Web Interface
Basic Connection and Configuration with the J-Web Interface If the power supply includes a on/off switch, turn the switch to on. For a DC power supply only: Ensure that the voltage across the DC power source cable leads is 0 volts and that the cable leads cannot become active during installation. -
Page 10: Step 2. Configuring Basic Settings With J-Web Quick Configuration
JUNOS Enhanced Services J-series Services Router Quick Start Power on the router by pressing the power button on the front panel. Wait until the LED on the front panel turns solid green. STATUS Turn on the power to the management device. The router assigns an IP address to the management device within the 192.168.1/24 subnetwork if the device... - Page 11 Basic Connection and Configuration with the J-Web Interface Table 2: J-Web Set Up Quick Configuration (continued) Field Description Loopback Address Reserved IP address that is always available on the router. By default, this address is set to 127.0.0.1/32 fe-0/0/0 Address IP address and prefix length of built-in Ethernet port 0.
-
Page 12: Step 3. Installing The Junos Enhanced Services Software
JUNOS Enhanced Services J-series Services Router Quick Start Step 3. Installing the JUNOS Enhanced Services Software For information explaining how to install the JUNOS Enhanced Services software if your Services Router is running JUNOS software, see the JUNOS Enhanced Services Migration Guide. -
Page 13: Step 2. Configuring Basic Settings With The Cli
Basic Connection and Configuration with the CLI On the PC or laptop, start the terminal emulation program (such as Microsoft Windows HyperTerminal), select the port, and configure the following port settings: 9600 (bits per second), (data bits), none (parity), (stop bits), and (flow control). -
Page 14: Step 3. Installing The Junos Enhanced Services Software
JUNOS Enhanced Services J-series Services Router Quick Start Set a default route (default gateway) for IPv4 packets. For example: root# set routing-options static route 1.6.2.1/24 next-hop 10.1.1.50 Configure one or more static routes: root# set routing-options static route destination-prefix next-hop address Set the hostname. -
Page 15: J-Web Basics
J-Web Basics J-Web Basics The task bar at the top of the J-Web interface identifies the main J-Web functions. You access specific tasks on the left. Monitor—Output from common commands show Configuration—Quick Configuration wizards and a graphical version of the CLI Diagnose—Ping, traceroute, and packet capture Manage—Configuration file management and licenses Events—System log messages... - Page 16 JUNOS Enhanced Services J-series Services Router Quick Start ping Ping remote target quit Exit the management session request Make system-level requests restart Restart software process Set CLI properties, date/time, craft interface message show Show system information Start secure shell on another host start Start shell telnet...
-
Page 17: Safety Warnings Summary
NOTE: This is a summary of safety warnings. For a complete list of warnings, including translations, see the JUNOS Enhanced Services J-series Services Router Getting Started Guide at http://www.juniper.net/techpubs/ WARNING: Certain ports on the router are designed for use as intrabuilding (within-the-building) interfaces only (Type 2 or Type 4 ports as described in... - Page 18 JUNOS Enhanced Services J-series Services Router Quick Start CAUTION: For routers with AC power supplies, an external surge protective device (SPD) must be used at the AC power source. Permit only trained and qualified personnel to install or replace Services Router components.
-
Page 19: Compliance Statements For Nebs
Compliance Statements for NEBS WARNING: The attached power cable is only for this product. Do not use the cable for another product. Compliance Statements for NEBS This product complies with the following Network Equipment Building System (NEBS) standards: The equipment is suitable for installation as part of the Common Bonding Network (CBN). -
Page 20: Declarations Of Conformity
JUNOS Enhanced Services J-series Services Router Quick Start Declarations of Conformity Declarations of Conformity... -
Page 21: Junos Enhanced Services And Related Documentation
To configure and operate a Integrated Services Module, you must also use WX documentation. Table 4 on page 23 lists the JUNOS software manuals and release notes and WX manuals. All documents are available at http://www.juniper.net/techpubs/ JUNOS Enhanced Services and Related Documentation... - Page 22 JUNOS Enhanced Services J-series Services Router Quick Start Table 3: JUNOS Enhanced Services Documentation Book Description JUNOS Enhanced Services Design and Provides guidelines and examples for designing and Implementation Guide implementing IP Security (IPSec) virtual private networks (VPNs), firewalls, and routing on J-series routers running the JUNOS Enhanced Services software.
- Page 23 JUNOS system software. JUNOS System Basics Configuration Guide Describes Juniper Networks routing platforms and explains how to configure basic system parameters, supported protocols and software processes, authentication, and a variety of utilities for managing your router on the network.
- Page 24 JUNOS API and Scripting Documentation JUNOScript API Guide Describes how to use the JUNOScript application programming interface (API) to monitor and configure Juniper Networks routing platforms. JUNOS XML API Configuration Reference Provides reference pages for the configuration tag elements in the JUNOS XML API.
-
Page 25: Requesting Support
Products made or sold by Juniper Networks or components thereof might be covered by one or more of the following patents that are owned by or licensed to Juniper Networks: U.S. Patent Nos. 5,473,599, 5,905,725, 5,909,440, 6,192,051, 6,333,650, 6,359,479, 6,406,312, 6,429,706, 6,459,579, 6,493,347, 6,538,518, 6,538,899, 6,552,918, 6,567,902, 6,578,186, and 6,590,785.
