4. FUEL SYSTEM

Precautions in Operation

General Information
Warning
Gasoline is a low ignition point and explosive materials, so always work in a well-ventilated place and
strictly prohibit flame when working with gasoline.
Cautions
● Do not bend off throttle cable. Damaged throttle cable will make unstable drive-ability.
● When disassembling fuel system parts, pay attention to O-ring position, replace with new one as
re-assembly
● There is a drain screw in the float chamber for draining residual gasoline.
● Do not disassemble air cut valve arbitrarily.
Specification
ITEM
Carburetor diameter
I.D. number
Fuel level
Main injector
Idle injector
Idle speed
Throttle handle clearance
Pilot screw
Tool
Special service tools
Vacuum/air pressure pump
Fuel level gauge
4-2
To this chapter contents
UA25A
Ø22mm
PTG 050
14.8mm
# 110
# 35
1700 ± 100rpm
1~3 mm
2 turns
