- Page 1 8 8 0 Altamar ™ | Aspen ™ | Cameo ™ | Capri ™ Majesta ™ | Marin ™ | Maxxus ™ | Optima ™ o w n e r ’ s m a n u a l 6530-395Y Rev. A...
- Page 2 Attention New Hot Tub Owner! ® Congratulations on the purchase of your new Sundance hot tub! The following is a list of automated functions performed by your hot tub. These functions are listed below in an attempt to suppress any operational concerns you may have during the first 24-hours of ownership! Also listed below are important maintenance recommendations you should observe on a regular basis to protect your new investment.
-
Page 3: Table Of Contents
Optima Air Controls Diagram ............. 33 9.13 Cameo Hot Tub Features............34 9.14 Cameo Massage/Waterfall Selector Diagram ......35 9.15 Cameo Air Controls Diagram ............. 36 9.16 Altamar Hot Tub Features ............37 © Sundance Spas, Inc. All Rights Reserved... - Page 4 880 SERIES 9.17 Altamar Massage/Waterfall Selector Diagram ......38 9.18 Altamar Air Controls Diagram ............ 39 9.19 Majesta Hot Tub Features............40 9.20 Majesta Massage/Waterfall Selector Diagram ......41 9.21 Majesta Air Controls Diagram ............ 42 9.22 Marin Hot Tub Features ............. 43 9.23 Marin Massage/Waterfall Selector Diagram ......
- Page 5 880 SERIES 12.7 Programming the Change Filter Reminder ........ 59 12.8 Programming the CLEARRAY™ (Ultraviolet) Water Purification System ............59 13.0 Hot Tub Maintenance ............61 13.1 Cleaning/Replacing the Filter Cartridge ........61 13.2 Quick Release Door (Except Maxxus and Aspen Models) ..63 13.3 Draining And Refilling..............
-
Page 7: Important Hot Tub Owner Information
Section 4.0 titled, “Locating Your Sundance Hot Tub” (page 9) or as prescribed by your authorized Sundance Spas dealer. Sundance hot tubs constantly strives to offer the finest hot tubs... -
Page 8: Important Safety Instructions For All Spa Owners
880 SERIES Important Safety Instructions for all Spa Owners REAd ANd FOLLOW ALL INSTRUCTIONS CAREFULLY! This spa was manufactured to meet the standards and specifications outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using this spa, basic safety precautions should always be followed, including: dANGER: RISk OF SEVERE INjURY OR dROWNING! - Page 9 880 SERIES • A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG (8.4 mm²) solid copper conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
- Page 10 880 SERIES WARNING: RISk OF SEVERE INjURY OR dEATH! • Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, if pregnant or possibly pregnant, consult your physician before using a spa. •...
- Page 11 880 SERIES WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g. an infection, bacteria or virus) and/or respiratory ailments that could be present in the air or water. Consult a licensed architect or building contractor to determine your specific needs if installing your hot tub indoors.
-
Page 12: Entrapment Risk
880 SERIES Entrapment Risk The Consumer Products Safety Commission/USA has reported that users of pools and spas have become entrapped (stuck) to drain and/or suction fittings causing death, drowning, or serious injury (see diagram below). This spa was manufactured to meet the standards and specifica- tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”... -
Page 13: Hyperthermia
A Warning Sign is provided in your warranty packet. Please install at a location near your spa, where it is visible to users of the spa. For additional or replacement Warning Signs please contact your local Sundance spas dealer and reference item number #6530-082. Page 7... -
Page 14: Important Additional Csa Safety Instructions (Canada Only)
880 SERIES Important Additional CSA Safety Instructions (Canada Only) When using this electrical equipment, basic safety precautions should always be followed, including the following: 1. REAd ANd FOLLOW ALL INSTRUCTIONS. 2. A green colored terminal or a terminal marked G, Gr, Ground, Grounding or the symbol* is located inside the supply termi- nal box or compartment. -
Page 15: Locating Your Sundance Hot Tub
880 SERIES Locating Your Sundance Hot Tub IMPORTANT: Because of the combined weight of the spa, water and users, it is extremely important that the base upon which the spa rests be smooth, flat, level and capable of uniformly supporting this weight, without shifting or settling, for the entire time the spa is in place. -
Page 16: Outdoor Location
880 SERIES Outdoor Location In selecting the ideal outdoor location for your hot tub, we suggest that you take into consideration the following: • The proximity to changing area and shelter (especially in regions subject to cold weather). • The pathway to and from your hot tub (this should be free of debris so that dirt and leaves are not easily tracked into the hot tub). -
Page 17: General Electrical Safety Instructions
Nonetheless, this hot tub must be installed properly to ensure dependable usage. Please contact your local Sundance Spas dealer or local building department should you have any questions regarding your installation. Proper grounding is extremely important. Sundance hot tubs are equipped with a current collector system. -
Page 18: Electrical Installation Instructions (240V Service)
880 SERIES Electrical Installation Instructions (240V Service) IMPORTANT NOTICE: The electrical wiring of this hot tub must meet the requirements of the National Electrical Code (NEC) and any applicable state, local or country codes. The electrical circuit must be installed by a qualified electrician and approved by a local building/ electrical inspection authority in your state or country. - Page 19 880 SERIES 7. Select the power supply entrance you want to use (Figures A-B, pages 13-14) and remove the short cabinet panel from the front of the hot tub, then feed cable through the large opening provided on the bottom of the control box. 8.
- Page 20 880 SERIES Figure B (Equipment Area for All Models Except Maxxus/Aspen) SPA CONTROLLER Note: Equipment location (such as pumps, CLEARRAY™ system, drain, heater etc.) varies by model. Jets Pump Control Box Filter/Circulation Pump Power Supply Entrance(s) ™ Jets Pump 10. CLEARRAY (Ultravoilet) Heater Purification System...
-
Page 21: Power Requirements
880 SERIES Power Requirements ® Sundance hot tubs are designed to provide optimum performance and flexibility of use when connected to their maximum electrical service. However, they are shipped factory configured for their most common preferred electrical connection. If you prefer, a qualified technician can perform a minor circuit board modification that allows the hot tub to operate on a different electrical service (see table below). -
Page 22: Export 50 Hz Power Options
880 SERIES North American 60 Hz Capri 240V/40A* 240V/50A** Voltage 240 VAC 240 VAC Max. Current Draw Number of Wires Circuit Breaker (2-Pole) 40A* 50A** In this configuration, the heater will not operate while the jets pump is running or when the blower is running. In this configuration, the heater will operate while the jets pump and blower are running. -
Page 23: Hot Tub Fill Up Procedure
880 SERIES Export 50 Hz Capri 230V/12,1A 230V/23,6A Voltage 230 VAC 230 VAC Frequency 50 Hz 50 Hz Max. Current Draw 12,1 Amps* 23,6 Amps** Wattage 2,8 kW 5,4 kW Number of Wires Standard 12,1 Amp (2,8 kW) configuration. The heater will not operate while the jets pump is running. -
Page 24: Activate Jets Pumps
880 SERIES IMPORTANT: Always fill your hot tub through the filter bucket after draining. Failure to do so may cause air to be trapped in either pump, preventing the pump from circulating water. Remove the hose and replace the filter cartridge as illustrated in Section 13.1. 3. - Page 25 880 SERIES temperature increases or decreases by one degree each time either button is pressed. • The heater will turn off when the temperature corresponding to the thermostat setting is achieved. Important Heater details: • The maximum temperature for which the hot tub can be set is 104°F (40°C) and the minimum is 80°F (27°C).
- Page 26 880 SERIES Water Fill Volume Average Sodium Model Fill Volume* dichlor Altamar .......395 Gal (1,495 L) ......10.0 oz Aspen .........XXX Gal (X,XXX L) ......XX.X oz Cameo ........370 Gal (1,401 L) ......9.0 oz Capri ........260 Gal (984 L) ........ 7.0 oz Majesta .......330 Gal (1,249 L) ......
- Page 27 880 SERIES 13. Consult your authorized Sundance Spas dealer for chemical recom- mendations, then add chemicals to hot tub water to achieve a con- stant sanitizer reading within the levels recommended on the inside cover of this manual. 14. Turn on all jet pumps and the blower when adding chemicals to...
-
Page 28: Hot Tub Features
880 SERIES Hot Tub Features Main Control Panel Functions (except Capri Models) A. Select Button: Scrolls menu through filter cycle programming features. Manually activates the circulation pump when it is in an off state for a 1 hour duration. 2 or 3 Pump Spa Control Panel B. -
Page 29: Main Control Panel Functions (Capri Models Only)
880 SERIES Main Control Panel Functions (Capri Models Only) A. Select Button: Scrolls menu through filter cycle programming features. Manually activates the circulation pump when it is in an off state for a 1 hour duration. B. Cycle Button: Accesses filter cycle program mode and advances display to next cycle. -
Page 30: Lcd Screen Functions
880 SERIES LCd Screen Functions = Lock: Indicates panel, set temperature, or filter cycle program- ming is locked. STANDARD = Heat: Indicates heater is on. = Sanitizer: Indicates that the sanitizing system is on (page 70). The Electronic Ballast (page 13) solid red light indicates that the CLEARRAY™... -
Page 31: Maxxus Hot Tub Features
880 SERIES Maxxus Hot Tub Features Main Control Panel lid. The suction fitting filter requires Handrails with LED Light (2 ea.) periodic cleaning for optimum perfor- Lights (2 ea.) mance) Pillows (4 ea.) 16. AquaTerrace Waterfall Control Valve Fluidix Nex Jets (8 ea.) 17. -
Page 32: Maxxus Massage/Waterfall Selector Diagram
880 SERIES Maxxus Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selectors 1 and 2 to divert water between designated jet groups. Massage Selectors (1-2) • Massage Selector #1 controls pump #1. • Massage Selector #2 controls pump #2. Waterfall Selector (3) •... -
Page 33: Maxxus Air Controls Diagram
880 SERIES Maxxus Air Controls diagram Air Control Operation Rotate Air Controls 1-8 to add air to designated jet groups. Turn the Blower on to add air to jets group 9. Spa operation subject to change without notice. Page 27... -
Page 34: Aspen Hot Tub Features
880 SERIES Aspen Hot Tub Features To Be Announced Spa features subject to change without notice. Page 28... -
Page 35: Aspen Massage/Waterfall Selector Diagram
880 SERIES Aspen Massage/Waterfall Selector diagram To Be Announced Spa operation subject to change without notice. Page 29... -
Page 36: Aspen Air Controls Diagram
880 SERIES Aspen Air Controls diagram To Be Announced Spa operation subject to change without notice. Page 30... -
Page 37: Optima Hot Tub Features
880 SERIES 9.10 Optima Hot Tub Features Main Control Panel cleaning for optimum performance) Handrails with LED Light (2 ea.) 16. AquaTerrace Waterfall Control Valve Light 17. AquaTerrace Waterfall Filtration Return Pillows (4 ea.) 18. Fluidix ST Jets (16 ea.) Fluidix Nex (4 ea.) 19. -
Page 38: Optima Massage/Waterfall Selector Diagram
880 SERIES 9.11 Optima Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selectors 1 and 2 to divert water between designated jet groups. Massage Selectors (1-2) • Massage Selector #1 controls pump #1. • Massage Selector #2 controls pump #2. Waterfall Selector (3) •... -
Page 39: Optima Air Controls Diagram
880 SERIES 9.12 Optima Air Controls diagram Air Control Operation Rotate Air Controls 1-5 to add air to designated jet groups. Spa operation subject to change without notice. Page 33... -
Page 40: Cameo Hot Tub Features
880 SERIES 9.13 Cameo Hot Tub Features Control Panel cleaning for optimum performance) Handrails with LED Light (2 ea.) 16. AquaTerrace Waterfall Control Valve Light AquaTerrace Waterfall Filtration Pillows (3 ea.) Return Fluidix Nex Jets (6 ea.) 18. Fluidix ST Jets (12 ea.) Fluidix Intelli-Jets (2 ea.) 19. -
Page 41: Cameo Massage/Waterfall Selector Diagram
880 SERIES 9.14 Cameo Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selectors 1 and 2 to divert water between designated jet groups. Massage Selectors (1-2) • Massage Selector #1 controls pump #1. • Massage Selector #2 controls pump #2. Waterfall Selector (3) •... -
Page 42: Cameo Air Controls Diagram
880 SERIES 9.15 Cameo Air Controls diagram Air Control Operation Rotate Air Controls 1-5 to add air to designated jet groups. Turn the Blower on to add air to jets group 6. Page 36 Spa operation subject to change without notice. -
Page 43: Altamar Hot Tub Features
880 SERIES 9.16 Altamar Hot Tub Features Main Control Panel lid. The suction fitting filter requires Handrail with LED Light periodic cleaning for optimum perfor- Light mance) Pillows (3 ea.) 16. AquaTerrace Waterfall Control Valve Fluidix Nex (4 ea.) 17. AquaTerrace Waterfall Filtration Return Fluidix Intelli-Jets (6 ea.) 18. -
Page 44: Altamar Massage/Waterfall Selector Diagram
880 SERIES 9.17 Altamar Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between designated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #2. Waterfall Selector (2) • Waterfall Selector #2 controls waterfall output. Continuously Powered jets (3) •... -
Page 45: Altamar Air Controls Diagram
880 SERIES 9.18 Altamar Air Controls diagram Air Control Operation Rotate Air Controls 1-5 to add air to designated jet groups. Turn the Blower on to add air to jets group 6. Spa operation subject to change without notice. Page 39... -
Page 46: Majesta Hot Tub Features
880 SERIES 9.19 Majesta Hot Tub Features Main Control Panel fitting/filter are located under the filter Handrail with LED Light lid. The suction fitting filter requires Light periodic cleaning for optimum perfor- Pillows (3 ea.) mance) Fluidix Nex (6 ea.) 16. -
Page 47: Majesta Massage/Waterfall Selector Diagram
880 SERIES 9.20 Majesta Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between designated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #2. Waterfall Selector (2) • Waterfall Selector #2 controls waterfall output. Continuously Powered jets (3) •... -
Page 48: Majesta Air Controls Diagram
880 SERIES 9.21 Majesta Air Controls diagram Air Control Operation Rotate Air Controls 1-5 to add air to designated jet groups. Page 42... -
Page 49: Marin Hot Tub Features
880 SERIES 9.22 Marin Hot Tub Features Main Control Panel fitting/filter are located under the filter lid. Integrated Handrail The suction fitting filter requires periodic Light cleaning for optimum performance) Pillows (4 ea.) 16. AquaTerrace Waterfall Control Valve Fluidix Nex (2 ea.) 17. -
Page 50: Marin Massage/Waterfall Selector Diagram
880 SERIES 9.23 Marin Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between designated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #2. Waterfall Selector (2) • Waterfall Selector #2 controls waterfall output. Continuously Powered jets (3) •... -
Page 51: Marin Air Controls Diagram
880 SERIES 9.24 Marin Air Controls diagram Air Control Operation Rotate Air Controls 1-4 to add air to designated jet groups. Turn the Blower on to add air to jets group 5. Spa operation subject to change without notice. Page 45... -
Page 52: Capri Hot Tub Features
880 SERIES 9.25 Capri Hot Tub Features Control Panel Vortex Jet (1 ea.) Integral Handrail Filter Lid (The filter cartridge and suction Gravity Drain fitting/filter are located under the filter Pillows (3 ea.) lid. The suction fitting requires periodic Fluidix Nex Jets (2 ea.) cleaning for optimum performance) Fluidix ST Jets (10 ea.) AquaTerrace Waterfall... -
Page 53: Capri Massage/Waterfall Selector Diagram
880 SERIES 9.26 Capri Massage/Waterfall Selector diagram Massage Selector Operation Rotate Massage Selector 1 to divert water between designated jet groups. Massage Selectors (1) • Massage Selector #1 controls pump #1. Waterfall Selector (2) • Waterfall Selector #2 controls waterfall output. Spa operation subject to change without notice. -
Page 54: Capri Air Controls Diagram
880 SERIES 9.27 Capri Air Controls diagram Air Control Operation Rotate Air Controls 1-3 to add air to designated jet groups. Turn the Blower on to add air to jets group 4. Spa operation subject to change without notice. Page 48... -
Page 55: Operating Instructions
880 SERIES 10.0 Operating Instructions Your Sundance ® hot tub has a touch-sensitive control panel, massage selector valves and air control knobs located on the top rim of the hot tub (Sections 9.4-9.27, pages 25-48). These controls let you operate many of the special functions of your Sundance ®... -
Page 56: Activate Jets Pump 1
880 SERIES A. Press and hold the WARMER ( ) button then; B. Press and hold the jETS 1 ( ) button at the same time for 2 seconds. You will see the temperature rise to 106°F (41°C) on the LCD display. -
Page 57: Light Button (Main Control Panel; Capri Model Only)
880 SERIES High-Speed Color Blend Mode Press Once Low-Speed Color Blend Mode Press Again Freeze Color Blend Mode: Press Selects or “freezes” your low speed blending color of choice. Again NEAR BLUE (X4) VIOLET (X5) RED (X6) AMBER (X7) GREEN (X8) AQUA (X9) WHITE (X10) Press... -
Page 58: Selecting The Desired Massage Action
880 SERIES The center button selects Random Freeze Near Color Color Blue Purple Amber Green Aqua White random mode or one of 7 constant colors on the footwell and waterfall Center Button Selects Waterfall And Footwell Light Color Mode lights. In random mode, press a second time to freeze random color or continue pressing for one of 7 constant colors. -
Page 59: Air Controls
On the rim of your hot tub is a screw-off cap labeled “SunScents Fragrance Dispenser” (pages 25-46). It is designed to contain packages of a specially made fragrance available from your Sundance Spas dealer. The fragrance is carried into the hot tub water by the air coming through the injector system when the air blower is on. -
Page 60: Indicator Light
880 SERIES 10.14 Indicator Light The indicator light located on the front cabinet panel of the hot tub is an early detection system that will notify you when the hot tub needs immediate attention. A solid white light indicates that all operations are normal. A solid red light indicates that immediate attention is required to clear or fix an error code. -
Page 61: Clean-Up "Blow-Out" Cycle
880 SERIES 11.4 Clean-Up “Blow-Out” Cycle The clean-up cycle is once per day in both Standard and Economy modes at 12:00 (noon) for two minutes. This is not user programmable. • Maxxus and Aspen Models: Jets pump 3 and blower activate for approximately 45 seconds to circulate any water in the plumbing. -
Page 62: Programmable Filter/Heating Cycles (Economy Mode Only)
880 SERIES 5. Press the (dISPLAY) button to save changes and recall the main water temperature display. Note: If no button is pressed within 30 seconds, all changes are recorded and the screen automatically returns to the standard water temperature display. When the standard mode is selected (Section 11.3), the filter/circulation pump automatically turns on for a heat call regardless of the pump’s programmed start time and duration. -
Page 63: Adjusting Time Of Day
880 SERIES This means the system is ready to accept you changes to the start time for cycle number one. Simultaneously, the large four-digit display in the center of the screen displays the currently programmed start time for that cycle. At this point, you have four options. You may: 1. -
Page 64: Programming The Date
880 SERIES 12.4 Programming The date The control system allows you program the month, day, year, and day of the week. To accomplish this, press (dISPLAY) , (MOdE) , and (dISPLAY) button within five seconds each. The current hour setting will be displayed, followed by AM or PM. Then, press the (dISPLAY) button again to display minutes. -
Page 65: Programming The Change Filter Reminder
880 SERIES 12.7 Programming the Change Filter Reminder Your new hot tub is equipped with a programmable “Change Filter” reminder icon that flashes on the control panel display after a specified number of days. It is designed to remind you to perform routine filter system maintenance on a regular basis but does not affect hot tub operation in any way. - Page 66 880 SERIES 2. Press the (UP) or (dOWN) button to change the status of the CLEARRAY System from either “ON” to “OFF”. Note: If the “OFF” option is selected, then there is no need to continue with the steps below. Selecting “OFF” disables the duration countdown timer.
-
Page 67: Hot Tub Maintenance
Hot Tub Maintenance Proper and regular maintenance of your hot tub will help it retain its beauty and performance. Your authorized Sundance Spas dealer can supply you with all the information, supplies, and accessory products you will need to accomplish this. - Page 68 880 SERIES All models include a suction cover filter (#6540-213) located directly under the MICROCLEAN® Ultra filter cartridge assembly that prevents debris from entering the hot tub plumbing when jets pump 1 is running. This filter should be cleaned every 2 months. TO dECREASE RISk OF dEATH, dROWNING, OR ENTRAPMENT, ALWAYS TURN POWER TO THE HOT TUB OFF BEFORE REMOVING THE MICROCLEAN ULTRA FILTER ASSEMBLY!
-
Page 69: Quick Release Door (Except Maxxus And Aspen Models)
880 SERIES 2. Rinse debris from all outer filter (1) pleats using a garden hose and high-pressure nozzle. Repeat process until all filter pleats are clean. Then rinse debris from inside of filter (1). If chemical cleaners are used, follow manufacturers instructions. -
Page 70: Draining And Refilling
880 SERIES 13.3 Draining And Refilling About every 3 to 6 months, you will should replace the hot tub’s water. The frequency depends on a number of variables including the amount of use, attention paid to water quality maintenance, etc. You will know it is time for a change when you cannot control sudsing and/or you can no longer get the normal feel or sparkle to the water even though the key water balance measurements are all within the proper parameters. -
Page 71: Cleaning The Hot Tub Interior
If you are not certain as to the suitability of a particular cleanser, consult your authorized Sundance Spas dealer. Regardless of the cleanser used, use extreme care to assure that no soap residue is left on the surface. -
Page 72: Pillow Care (Capri Model Only)
880 SERIES Place both hands on Press inward with Flex pillow lip inward Gently pull outward on pillow with thumbs as thumbs to curl pillow 2-3" to get a good pillow to release mounting shown. lip inward so you can grip on the ends. -
Page 73: Vinyl Cover Care And Maintenance
6. Use only recommended cover lift systems. 7. Use only chemicals and cleaners recommended by Sundance Spas. 8. Remember to keep spa covered when not in use. Maintaining proper water levels assures efficient operation and efficient electrical usage. -
Page 74: Restarting Your Hot Tub In Cold Weather
9. Re-install cabinet side panels and cover hot tub so that no moisture can enter into it. Consult your Sundance Spas dealer if you have any questions regarding winter use or winterizing. -
Page 75: Water Quality Maintenance
For specific guidance on maintaining water quality, consult your Authorized Sundance Spas dealer who can recommend appropriate chemical products for sanitizing and maintaining your hot tub. WARNING:... -
Page 76: Clearray™ Water Purification System
880 SERIES the jets pump(s) and leave the spa cover open for a minimum of 20 min- utes. By doing this you will allow excess chemical vapors to exit the spa, protecting pillows and plastic knobs from chemical attack. WARNING: RISk OF PERSONAL INjURY, dROWNING OR ENTRAPMENT! Never leave your hot tub unattended for any reason while the... -
Page 77: Clearray™ Lamp Replacement And Quartz Tube Maintenance
880 SERIES 14.4 CLEARRAY™ Lamp Replacement and Quartz Tube Maintenance Important: It is MANdATORY that the UV lamp is replaced and the quartz tube be cleaned every 12 months to maintain optimum performance. Figure 1 dANGER: TURN THE SPA BREAkER TO THE OFF POSITION! WARNING: ALLOW LAMP TO COOL dOWN PRIOR TO... - Page 78 880 SERIES 4. Slowly remove the UV lamp (4) out of the quartz tube. 5. Remove lamp socket (5) from the UV lamp (4), Figure 4. 6. Remove the quartz seal compression nut (7) by turning it counterclockwise, Figure 3. Use a pair of channel-lock pliers if needed, Figure 5.
-
Page 79: Other Additives
Many other additives are available for your hot tub. Some are necessary to compensate for out-of-balance water, some aid in cosmetic water treatment and others simply alter the feel or smell of the water. Your Authorized Sundance Spas dealer can advise you on the use of these additives. 14.6 Handrail Maintenance The handrails in your Sundance hot tub are manufactured from a high quality 316 stainless steel alloy. -
Page 80: Troubleshooting - Display Messages
880 SERIES If your stainless handrails shows signs of rusting you should: • Wash with fresh water (a good detergent won’t hurt). • Clean with a good car chrome polish. • Wax with an automotive or fiberglass wax. You should never: •... - Page 81 NOT ENTER THE WATER! Remove hot tub cover to speed cooling. See “Water is too hot” (page 78). If condition persists, contact your Sundance Spas dealer or qualified service technician. If the hot tub water is more than -7°C cooler than the temperature setpoint, jets pump #1 and heater will automatically activate to provide freeze protection.
- Page 82 OPEN SENSOR (heater disabled) or SHORTED SENSOR (hot tub is deactivated) The high-limit temperature sensor is non-functional. This must be repaired only by an Sundance Spas dealer or qualified service technician. OPEN or SHORTED SENSOR (heater disabled) The main temperature sensor is non-functional. This must be repaired only by an Sundance Spas dealer or qualified service technician.
-
Page 83: Troubleshooting - Procedures
2. If nothing appears on the screen: light) A. Check the household circuit breaker. B. Contact you Sundance Spas dealer or qualified service technician. Pump does not Depress JETS Button. operate and icon... - Page 84 2. Keep the cover in place while heating. 3. If “heater on” indicator is lit but no temperature rise is experienced after a reasonable period of time, con- tact your Sundance Spas dealer or qualified service technician. Filter/ 1. Verify filter/circulation pump is programmed to run 8 hours a day (page 55).
-
Page 85: North American 60 Hz Electrical Wiring Diagram
880 SERIES 17.0 North American 60 Hz Electrical Wiring diagram 17.1 North American 60 Hz Maxxus/Aspen Electrical Wiring diagram Page 79... -
Page 86: North American 60 Hz Altamar/Cameo/Capri/Majesta/Marin Electrical Wiring Diagram
880 SERIES 17.2 North American 60 Hz Altamar/Cameo/Capri/Majesta/Marin Electrical Wiring diagram Page 80... -
Page 87: Export 50 Hz Electrical Wiring Diagram
880 SERIES 18.0 Export 50 Hz Electrical Wiring diagram 18.1 Export 50 Hz Maxxus/Aspen Electrical Wiring diagram Page 81... -
Page 88: Export 50 Hz Altamar/Cameo/Capri/Majesta/Marin Electrical Wiring Diagram
880 SERIES 18.2 Export 50 Hz Altamar/Cameo/Capri/Majesta/Marin Electrical Wiring diagram Page 82... -
Page 89: Circuit Board Pin Assignments
880 SERIES 19.0 Circuit Board Pin Assignments DANGER RISK OF SHOCK OR ELECTROCUTION! 850 LCD REVX.XX JP19 JP19 Turn power off before servicing. This task should only be performed by a quali- fied technician. Refer to pages 15-16 for additional jumper configuration details. JP19-1 On = °C Off = °F... -
Page 90: Typical Hot Tub Wiring Diagrams A-B (North American 60 Hz Models Only)
880 SERIES 20.0 Typical Hot Tub Wiring diagrams A-B (North Ameri- can 60 Hz Models Only) DANGER RISK OF SHOCK OR ELECTROCUTION! Turn power off before servicing. This task should only be performed by a quali- fied technician. 2-Pole Circuit Breaker with 2-Wire Grounded Load Connection (3 Wires to Hot Tub, 2-Hot (L1-L2), 1-Ground) 240 VAC White (N)
