Coral SeaBeam Installation and Configuration Manual

Parameters for Reference

................................................................................................................
These parameters include the following information that must be verified and
recorded before registering the softphone:
Parameters that indicate that the product is authorized to operate in this Coral
system along with the number of phones
Necessary IP addresses that are used to define the IP address of the SIP Proxy
Server of the Coral SeaBeam softphone.
This chapter does not include general IP parameters that must be configured
within the Coral system in order for it to enable basic IP functionality. For an
outline of general IP parameters, refer to the VoIP Installation Manual.
Feature Authorization .....................................................(Route: FEAT, 1)
These display-only parameters display the maximum number of Coral SIP phones that
are authorized for use with the Coral system. If the number of phones to be installed
exceeds the number authorized, contact your manufacturer's representative to increase
the number of authorized Coral SeaBeam, T207S and T208S phones in the system.
PORTS
MEDIA_CHAN
T2xxS - (Coral SeaBeam/T207S/T208S)
Size Definition.................................................................(Route: SIZ)
The system database allocates resources to manage the operation of Coral SIP stations
based on the values entered in the following fields.
If insufficient resources have been allocated in Sizes, the entry must be increased or
the IP terminals will not operate. For more information, see Chapter 4, Size Definition
of the Program Interface Reference Manual.
SIP_TERMINAL - (T207S/T208S, Coral SeaBeam, Third party SIP endpoint)
MAXIMUM_PERSONAL_PASSWORD_LENGTH
FOREIGN_PROXY
IP_MEDIA_CHANNELS
Set these entries to accommodate the total number of SIP terminals and channels
expected to be used. Verify that the maximum number of IP terminals and channels
are defined. If insufficient resources are allocated, the phones will not initialize.
Coral IPx and FlexiCom Registration 15
