Overview And Minimum Requirements - Tadiran Telecom Coral SeaBeam Installation And Configuration Reference Manual

14 Coral IPx and FlexiCom Registration
2
Program any specific features that will operate for the phone.
Customizing specific Coral features defined for the phone is not an integral
part of the registration and can be performed after the phone is operational.
3
Configure the following T207S/T208S phone parameters in the Program
IP-Ports: SIP Terminal (Route: IP,1,4), page
Interface. See
Required Zone If the phone is to be defined within a zone, define it to be
within the same zone as the UGW.
Password Define and record the authentication password between the phone
and the proxy server (default: 123456).
Media Negotiation (Early/Late) Select Late.
Hold Support (Early/Late) Select Late.

Overview and Minimum Requirements

................................................................................................................
This section provides a general description of the softphone registration process and
the Program Interface (PI) parameters that need to be programmed into the Coral
FlexiCom and Coral IPx systems. Actual Coral system programming procedures are
beyond the scope of this manual. For explanations regarding PI procedures, refer to
the Coral Program Interface and Database Reference Manual.
Before configuring the PI database, verify that the required Coral software has been
installed (see Table 5 on page
The following PI database parameters must be defined prior to connecting the
softphone to the LAN. For further details, refer to the Coral Programing Interface &
Database Reference Manual, Version 15.5 or higher.
This section includes all actions that must be performed in order for the
softphone to be able to dial make and accept calls. For information on how to
program specific features, see the Program Interface & Database Reference
Manual.
11).
Coral SeaBeam Installation and Configuration Manual
16:
