Tadiran Telecom Coral SeaBeam Installation And Configuration Reference Manual page 10

Figure 1 Coral SeaBeam
Main Components
Coral SeaBeam Installation and Configuration Manual
Device Description
Yealink devices
Legerity Telephone handset interface via PCI adapter card. Allows
PhonePort™ PCI you to dial numbers and activate Coral SeaBeam features
card directly from the handset.
Intel® 600SM PCI
A PCI VoIP card that allows you to use your regular phone
card
handset for calls routed via Coral SeaBeam.
Open SeaBeam menu
Open Video drawer
Six line keys
XFER
Dial (Make call)
Microphone control
MUTE
Mute
Clear
USB-P1K - USB hand phone
USB-P8D - USB hand phone (includes headset with
microphone for hands free calling)
USB-W1D - wireless phone with base and handset
Minimize softphone
Hide softphone
HOLD AA AC DND CONF
RECORD
FLASH REDIAL
SPEAKER
PHONE
CLEAR
Dial pad
Call Display area
Open Calls & Contacts drawer
Hang up (End call)
Speaker control
Speakerphone
About this Product 5
