Evaluation Board User Guide

ORDERING INFORMATION

COMPONENT LISTING

Table 2.
Quantity Reference Designator
2 C1, C2
4 C3, C4, C9, C10
18 GND1, GND2, P1 to P8, T4 to T11
4 LK1 to LK4
12 D1 to D4, IN1 to IN4, S1 to S4
1 J2
1 J3
1 U2
Description
10 μF, 20 V tantalum capacitor Case B
0.1 μF, 50 V capacitor, 0603
Terminal PCB, red, PK100
Header, 1-row, 3-way and jumper socket black
50 Ω jack SMB, PCB
3-pin terminal block, PCB (5 mm pitch)
2-pin terminal block, PCB (5 mm pitch)
Power-off protection ±5 V, +12 V, quad SPST switch
with 5 Ω on resistance
Rev. 0 | Page 7 of 8
UG-137
Supplier/Part Number
FEC 197427
FEC 8820023
FEC 8731144
FEC 1022248 and FEC 150410
FEC 1111349
FEC 151790
FEC 151789
Analog Devices, Inc. ADG4612BRUZ
