Ordering Information; Bill Of Materials; Related Links - Analog Devices AD8476 User Manual

UG-422

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
2 C3, C4
2 C1, C2
5 J1 to J5
9 R1 to R12
7 +VS, −VS, VOCM, GND1 to GND4
2 JP1, JP2
1 DUT1
1

RELATED LINKS

Table 2.
Resource Description
AD8476 Product page, low power, unity gain fully differential amplifier and ADC driver
Package
C7343
C0603
SMB PCM
R0603
TP1
2-pin header
8-lead MSOP
Rev. 0 | Page 6 of 8
Evaluation Board User Guide
Description
10 µF capacitor
Capacitor, 0.1 µF
SMB connector
Resistor, user defined value
Test point
2-pin Berg II 0.100" straight header
Device under test
PC board
