2. Technical data
2 Technical data

2.1 Performance data

Type:
Housing:
Dimensions:
Weight:
Connecting cable:
Mains cable:
Ambient temperature: on request
Type of protection:
Operating voltage:
Current input:
Fuse:
Switching inputs:
Switching outputs:
Interface:
Operation:
Conveying speed:
Can be combined:
Subject to changes due to technical innovation!
Control Unit GENIUS
Sheet metal, painted, pure-orange (RAL 2004) or
FDA white, food grade (RAL 9010) or
stainless steel, glass lead blasted or polished.
see page 6
6 kg
(to the detection coil) standard up to 5m (up to 50 m max.)
1,8 m with plug
IP 65
230V / 115V (+10%, -15%), selectable, 50Hz / 60Hz
approx. 120 mA
630 mA, slow-blowing
2 switching inputs for initiators
1 switching input for light barrier
1 switching input RESET
8 switching inputs for special functions and options
1 switching output 24V DC, 200mA for metal detection
2 relay switching outputs for metal detection
1 relay switching output error message
Serial interface RS232 or. RS485 (option)
Graphic display with 4-key operation
depends on type and size of the detection coil used
Detection coils of GLS, GLS-R, DLS and ELS
7
