6. Operation / Menu structure

6.3.12 Adjustment of Reject and Level monitor (option belt conveyor)

This menu is only activated if a light barrier is installed at the reject box!
During reject the product must have passed the light barrier after 3 seconds. If not, an
alarm message is generated „Not rejected".
If the light barrier is activated by a product for more than 5 seconds, the alarm message
„Reject box full" is displayed.
Reject Monitor
-> Reject : nein
Level : ja
SEL O.K.

6.3.13 Adjustment of the Diverter position monitor (option pipe conveyor)

This menu is only activated if the diverter is equipped with the appropriate sensors!
Two different times have to be set, as the forward and the reverse time is different.
Forward: 0ms
Reverse: : 0ms
To disable set to 0 ms
- + SEL O.K.
Settable time range: 0ms....step 5ms...5000ms.
The monitor generates the alarm message „Diverter position" if the diverter is not in normal position
during normal operation, or moves not or to slowly in case of metal detection.
If the times were set to short, the monitor will display „Diverter position".
To get to the menu to adjust the times press RESET button and then F1 (red lamp is still
blinking).
After resetting (or disabling) the diverter monitor the alarm signal (red lamp) have to be
reset.
Reject/Level monitoring: This menu is selected in Setup „Re-
ject/Level" on page 2.
The monitoring mode can be selected with the key „SEL".
With keys ▼ and ▲ the mode can be activated/disabled.
O.K. confirms the selection and gets back to the Setup menu page 2.
Adjustment/ Enabling of the Diverter Monitor: This is selected in
Setup menu page 2 after selecting „Diverter Monitor"
Two different times have to be set, which are selected with „SEL"
and set with + and –.
Forward: time of the diverter flap to get from the normal to reject
position.
Reverse: time to get back from reject to normal position.
The diverter monitor is enabled if the two values are set > 0 ms.
The diverter monitor is disabled if just one value is set to 0 ms.
O.K. gets back to the Setup menu page 2
