6. Operation / Menu structure

6.3.5 Date setting

->mo,20.11.2000<-
- + day O.K.

6.3.6 Language setting

deutsch italiano
english svenska
francais dansk
nederlands
ESC O.K.

6.3.7 Serial Interface configuration (option)

This menu is only activated if Genius is equipped with a serial interface!
interface
none
printer online
printer portable
PC/SPS
ESC O.K.

6.3.8 Setting of Device and Line name

enter divece name:
DETECTOR 1
= 012...ABC...
O.K.
Setting of Date: Select in Setup menu page 1 „date".
With F3 Day, Month or Year is selectable. The keys +/- are used to
set the date.
Complete the input with „O.K."
Pressing „O.K." returns to Setup menu page 1.
Language: The language is set by selecting in menu Setup page 1
„Sprache". Use ▼ and ▲ to choose one of the 7 available languages.
„O.K." completes the selection and returns to Setup menu page 1
displayed already in the chosen language.
„ESC" returns to Setup menu page 1 without changing the preset
language.
Available languages (included in the standard software package):
deutsch
english
francais
nederlands
italiano
svenska
dansk
Interface: See operational manual „Control Unit GENIUS serial inter-
face".
enter line name:
LINIE 1
= 012...ABC...
O.K.
24
German
English
French
Dutch
Italian
Swedish
Danish
Device name / Line name: See
op. manual „Control Unit GENIUS
serial interface".
The input names will only appear
on the print outs of a connected
event printer.
