Summary of Contents for Tectronix Systems Genius
- Page 1 Operating Instructions GENIUS Control Unit 9 - 18812 96 Avenue Surrey, BC Canada, V4N 3R1 Tel: (001) 604 607-6028 Fax: (001) 604 607-6026 e-mail: service@metal-shark.com TecTronix-GENIUS-BA-CU-EN-3006.doc...
- Page 2 In addition to this, you will learn about the sophisticated options provided by the Genius electronics. If you have any problems in the set up and operation of your system, the TecTronix team are available to assist you.
- Page 3 UHMW shim beneath the bearing and nylon washers or some other non conductive material beneath the bolt head and nut/flat washer. The bolts should also be sleeved with a non conductive material. It may be neces- sary to isolate more than one roller in either direction to achieve the desired results. TecTronix-GENIUS-BA-CU-EN-3006.doc...
-
Page 4: Table Of Contents
Contents Contents General information Reasons for using the Control Unit GENIUS Symbols used Legal basis Overall view Technical data Performance data Dimensions Design and method of operation Functional principle Functional and control elements 3.2.1 GENIUS - Housing 3.2.2 GENIUS - Controller board STE 3.2.3... - Page 5 Setting of the outputs 6.4.2.7 Activation of performance validation and scheduled testing Menu Product change The use of the GENIUS metal detector for quality insurance Instruction for setting the performance test intervals Carrying out a performance validation Errors and error remedying Error messages 8.1.1...
-
Page 6: General Information
1. General information 1 General information 1.1 Reasons for using the Control Unit GENIUS • Product liability • ISO 9000 • TQM (Total Quality Management) • Protection of consumers and of machines 1.2 Symbols used = Important notes = Danger notes = Safety notes 1.3 Legal basis... -
Page 7: Reasons For Using The Control Unit Genius
2. Technical data 2 Technical data 2.1 Performance data Control Unit GENIUS Type: Housing: Sheet metal, painted, pure-orange (RAL 2004) or FDA white, food grade (RAL 9010) or stainless steel, glass lead blasted or polished. see page 6 Dimensions: Weight:... -
Page 8: Technical Data
2. Technical data 2.2 Dimensions 240 mm 260 mm 145 mm TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 9: Functional Principle
The controller acts as the central processing unit and controls the evaluation electronics, display unit, serial interface for external control units (SPS, PC) and printers. The PC can run also the Data Man- agement System INSIGHT GENIUS. TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 10: Design And Method Of Operation
3. Design and method of operation 3.2 Functional and control elements 3.2.1 GENIUS - Housing Display and key pad: G E N I U S (1) LCD display METAL DETECTOR operation (2) Function keys F1 - F4 opération (3) „Operation lamp“: lights... -
Page 11: Functional And Control Elements
3. Design and method of operation 3.2.2 GENIUS - Controller board STE 10 10 Connectors: „Mains“: Mains supply „Fault“: Potential-free change-over contact „Metal 1“: Potential-free change-over contact „Metal 2“: Potential-free change-over contact „24V Output“: 24V switching output a) 24 Inputs and outputs. - Page 12 3. Design and method of operation TecTronix-GENIUS-BA-CU-EN-3006.doc...
-
Page 13: Genius - Evaluation Electronics Board Awe
3. Design and method of operation 3.2.3 GENIUS - Evaluation electronics board AWE +22V - 22V - 30V +30V Connectors: (1) STE RS485: Interface RS485 to the controller board (2) Power Supply: Power supply from the controller board (3) Transmitter:... -
Page 14: Safety
In case of unauthorized modification or repair work all the declarations and guar- antees given by the manufacturer will become void. 4.8 Inadmissible operation Operation out of the specifications given in the technical data. Operation under high mechanical static and dynamic loads (e.g. heavy system parts or strong vibrations). TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 15: Commissioning
• Never install the electronic unit in other switchgear cabinets, because this may lead to interference effects.(e.g. from contactor controls)! • Cable lengths may only be modified after consultation with „TecTronix Systems“. Use only original cables. Lay the connecting cable in fixed installation apart from other cables (e.g. fix it with nailing clips or lay it in a cable duct). -
Page 16: Electrical Connection
Free fall mode (Rapid XXXX): connection ot test push button to activate the diverter unit. I3,I4,I6, for special applications. 12 11 14 31 34 LF LB LM IN1IN 2 LSR ST i7 Ma ins Fault Metal 2 Metal 1 24V Output. Outputs Inputs Inputs TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 17: Electrical Performance
250VAC/ 3A 120VDC/ 3A 24VDC outputs Max current load: 300mA Connection of make contacts Inputs: In1 / In2 / LS / RST against ⊥, resp. NPN outputs Connection of make contacts Inputs: i0 .. i7 against+24 V, resp. PNP outputs TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 18: Electrical Connection Of The Equipment
Mains supply by using the outlet Mains supply using alter- natively a mains connec- tion box Controller board GENIUS 4.2. If necessary, connect plug ST1 "Mains" Mains cable Control unit Mains Strip of vanish for... - Page 19 Se tting d ate La ngu age L ang uage Setup page 2 In terface Interfa ce Serial setup D evice na me D evice name Line n am e L ine na me O p tions O ptions Operating mask TecTronix-GENIUS-BA-CU-EN-3006.doc...
-
Page 20: Operation / Menu Structure
9. To get to the „Operating mask“ press F4. 10. The GENIUS is now adapted to the surrounded conditions and the product. 11. Check the proper operation by putting a metal particle through the detector and watch if it works correctly. -
Page 21: Operating Mask And Adjustment Menu
F3 setup wrong, the display skips to the operating mask. F4 operating mask Key F4 get immediately to the operating mask Exception: If no product is programmed the line F1„ change product“ is suppressed. Additional information: Date and time TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 22: Set Up Menu
It will be necessary if two detectors are close together so that they will affect each other. Software: The keys „-„ and „+“ will change the frequency stepwise. O.K. gets to STE: V#.## AWE: V#.## Setup mode page 1 O.K. TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 23: Event Recording By The Genius Log Book
6. Operation / Menu structure 6.3.2 Event recording by the GENIUS Log book GENIUS Log book: Select „Log book“ in Setup menu page 1. The last GENIUS logbook 1000 events are stored in a database and can be displayed. The latest 20.11. -
Page 24: Date Setting
Italian svenska Swedish dansk Danish 6.3.7 Serial Interface configuration (option) This menu is only activated if Genius is equipped with a serial interface! Interface: See operational manual „Control Unit GENIUS serial inter- interface face“. none printer online printer portable PC/SPS ESC O.K. -
Page 25: Setting Of The Unit For Conveying Speed
6.3.10 Adjustment of the Air pressure monitor (option) This menu is activated if Genius is equipped with an air pressure indicator! During reject the air pressure can fall under the adjusted limits of the pressure indicator. The air pressure is not monitored during and a certain time after reject (recovery time) as it can be out of limits during this time. -
Page 26: Adjustment Of Reject And Level Monitor (Option Belt Conveyor)
If the times were set to short, the monitor will display „Diverter position“. To get to the menu to adjust the times press RESET button and then F1 (red lamp is still blinking). After resetting (or disabling) the diverter monitor the alarm signal (red lamp) have to be reset. TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 27: Adjustment Of The Diverter Controller (Option Pipe Conveyor)
6. Operation / Menu structure 6.3.14 Adjustment of the Diverter Controller (option pipe conveyor) This menu is activated only if Genius is used in combination with a special diverter unit for textile fibers (Quick flap) The magnetic valve which is triggered for return motion is connected to terminals „24V Outp.“... -
Page 28: Product Teach-In Menu
• The Genius displays this product angle from 0..step 0.1...180° . Between 180° and 0° the value is displayed as „---„. The signal evaluation then is not using the product angle and provides maximum sensitivity to all kinds of metals for dry products or products without product effect. -
Page 29: Conveying Speed
O.K. Pressing „O.K.“ gets to automatic or manual teach in mode. The shown limits of the conveying speed range are absolute values! If the conveying speed is set out of this range no detection will be performed! TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 30: Automatic Product Teach-In
Metallic contaminants in product Ensure that metal-free product is used for teach-in procedure and repeat. Several trials without success: Ask TecTronix Systems service for Product effect can not be compen- help. Send test sample of the prod- sated uct. To get optimum product compensation, which results in optimum sensitivity, pay attention to the following: •... -
Page 31: Manual Setting Of Product Parameters
(three times product length incl. gap) no rejection is carried out only in case of metal detection. „F3 halfwave“: Specially used for stop and go conveying systems Drawback: Increased noise sensitivity. „F4 Previous menu“: Get to mask „Product teach in 1“ TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 32: Input / Change Of Product Name
When adding additional products the parameter of the first product are set as a default setting. The GENIUS is factory preset to the following operating modes: Free fall (gravity feed): For use with metal separators of the series Rapid 4000, 5000, 6000 Belt conveyor with timer application: For use with belt conveyor at constant speed. - Page 33 Then the outputs are reset 4. The procedure step 1 to 3 can be repeated by pressing F2. 5. F4 allows fine adjustment by hand. F3 gets to menu „Reset mode Auto / Manu“. The set values are cancelled. TecTronix-GENIUS-BA-CU-EN-3006.doc...
- Page 34 The parameters have to be set for the first product at the teach-in procedure. If products are added to the product memory, the above parameters are set automatically as preset parameters. TecTronix-GENIUS-BA-CU-EN-3006.doc...
-
Page 35: Activation Of Performance Validation And Scheduled Testing
„ESC“ returns to operation mask, inputs are ignored. ESC O.K. Note: Pressing „O.K.“ without changing the product number (i.e. change from product 1 to product 1) is interpreted as new „batch“ which resets the counter for number of metal detections and faults to. TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 36: The Use Of The Genius Metal Detector For Quality Insurance
5. Finally set for the product to be inspected the test piece numbers. 6. If several GENIUS, equipped with the serial interface, are in operation name each device and line in the Setup that each system can be identified easily. (see 6.3.8 and operational manual Control Unit GENIUS option serial interface). -
Page 37: Errors And Error Remedying
If detector head DLS is used, check on loose centering pins or fastening bolts. 8.1.4 Battery voltage too low Possible causes Remedy The buffer battery (see 3.2.2) located on the controller Contact TecTronix Systems service board is flat. 8.1.5 24V switching output overload Possible causes Remedy •... -
Page 38: Datememory Not Existing
Check diverter if tight or wedged pieces diverter too slow Check air pressure (min. 5 bars) Caution! Danger of accident! Disconnect air supply! Prolong the time settings Forward and return time set too short (see 6.3.13) Check cable and sensors Connection to the sensors defective TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 39: Undefinable Activation Of The Switching Outputs
Loose contact at the coil cables Check the connections High static charging of the material (possibly audible Avoid static charging by additional grounding meas- clicking sound at the detection coil) ures (contact TecTronix Systems service!) Use of de-ionizing equipment TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 40: Replacement Of Electronic Boards
8. Errors and error remedying 8.3 Replacement of electronic boards The Control-Unit GENIUS consists of the following three boards: Control electronics board (3), evaluation electronics board (5) and display board (8). TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 41: Replacing The Control Electronics Board
1. Disconnect voltage supply and open the cover at the electronics housing 2. Remove the used connectors (6) and remove the fastening screws (7) 3. Take out the display board (8) 4. Install the new board in reverse order! TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 42: Spare Parts, Service
Pos. No. Article Art. No. Comment / DWG No. Display cover GENIUS 33001496 Display board GENIUS 44001078 Electronics housing GENIUS mounted to the detector head 08016739 Electronics housing GENIUS remote 08016755 Evaluation electronics board GENIUS 44001036 Control electronics board GENIUS... - Page 43 9. Spare parts, service Interface cable RS485 for PC /INSIGHT 44001038 length on demand TecTronix-GENIUS-BA-CU-EN-3006.doc...
-
Page 44: Service Address
9. Spare parts, service 9.4 Service address Manufacturer’s Surround TecTronix inc. 26688 56 Avenue Langley, British Columbia Canada, V4W 3X5 Telephone: (001) 604 607-6028 Fax: (001) 604 607-6026 E-mail: service@surrtec.com TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 45: Shipping, Transport, Storing, Preservation
After packing the sea-freight crates must be properly closed. During loading care must be taken that the shipments are protected. Proper acceptance and loading of the shipment must be certified by the carrier on the bill of lading, loading list, etc. TecTronix-GENIUS-BA-CU-EN-3006.doc... -
Page 46: Index
Distance measurement ... 33 .... 29 Teach in procedure Operating mask ....20 Test points ...... 12 ....31 Operating modes .... 28 ......15 Eject duration Test push Electrical connection..15 Outputs......16, 31 .... 32 Time measurement Time measurement..32 TecTronix-GENIUS-BA-CU-EN-3006.doc...
