5.2.3 Electrical Performance
Potential-free relay contact
24VDC outputs
Inputs: In1 / In2 / LS / RST
Inputs: i0 .. i7
250VAC/ 3A
120VDC/ 3A
Max current load: 300mA
Connection of make contacts
against ⊥, resp. NPN outputs
Connection of make contacts
against+24 V, resp. PNP outputs
