6. Operation / Menu structure

6.4.2.7 Activation of performance validation and scheduled testing

no alarm
every hour
every day
every week
extern
ESC O.K.
SEL O.K.

6.5 Menu Product change

A:PRODUCT A
B:PRODUCT B
1:PRODUCT 1
ESC O.K.
Control interval: select „test interval" in menu "teach in product 2".
The alarm mode is chosen by using ▼ and ▲ followed by „O.K.".
Selection of „No alarm" or pressing key „ESC" returns to menu "teach
in product 2".
Selection of „every hour" causes a self check alarm every hour.
When chosen, the menu „Performance check" (see below) appears
automatically.
Selection of „every day" causes a self check routine at a certain
hour of a day.
Automatically the menu to input the requested „Alarm time" appears
(see above, „Set time"), then the menu „Performance check" (see
below) appears.
„every week" is identically to „daily" but in addition the requested
day of the week have to be programmed.
(For more details see also 7).
„Extern": the performance check is called, if the input LS is acti-
vated (see 5.2.2).
Performance Check: This menu appears automatically, when „Con-
trol interval" was selected. The performance validation is carried out
by putting prepared metallic test pieces through the detector.
For each product up to three different test pieces can be set. If only
one test piece is used set test piece 2 and 3 to 00.
Use key „SEL" to select test piece 1, 2 or 3 and set the identification
number
(00 .. 99) with ▼ and ▲.
Pressing „O.K." get to menu "teach in product 2".
(For more information see also 7).
Select product: after selecting „Product change" the number of prod-
ucts which were already stored are listed.
Use keys ▼ and ▲ to select a stored product. „O.K." confirms the
selection.
„ESC" returns to operation mask, inputs are ignored.
Note: Pressing „O.K." without changing the product number
(i.e. change from product 1 to product 1) is interpreted as new „batch"
which resets the counter for number of metal detections and faults to.
