6. Operation / Menu structure

6 Operation / Menu structure
This section starts with a short form instruction for the most important settings including cross refer-
ences for the comprehensive instructions.
Afterward all menus are described. To ease the handling the menu structure can be fold out.

6.1 Quick start

6.1.1 Setting of the most important parameters

Language (if necessary):
1. The operation mask appears after power on (see 6.2).
2. Press F1 „Adjustments" followed by F3 „Setup" .
3. Press five times key ↓ until „Language" is marked and press „O.K.".
4. Select language and confirm with „O.K." (see 6.3.6)
5. Return by pressing key „END" .

6.1.2 Teach-in procedure for new product

1. Press F1 „Adjustments" followed by F2 „Product teach-in".
2. If a list of preprogrammed products is displayed press key ↓ until „**NEW**" appears and confirm
with „O.K." (see 6.4.1)
3. Set the conveying speed of the product or speed of belt conveyor and confirm with „O.K.".
4. Follow the instruction on the display. Pay also attention to the
6.4.2.2!
5. Press F4 ("continue"), then F2 ("output adjust") in menu „Product teach-in".
6. Select F1 or F2 for automatic or manual Reset of the metal outputs (see 6.4.2.6).
7. Press F1 „Manual Adjustment" and set the requested „Delay time" after metal detection and acti-
vation of the outputs.
8. Confirm the inputs by pressing key „O.K.", then press F4 to get to the previous menu.
9. To get to the „Operating mask" press F4.
10. The GENIUS is now adapted to the surrounded conditions and the product.
11. Check the proper operation by putting a metal particle through the detector and watch if it works
correctly.
-window described in chapter
