B.6 Ethernet 10/100/1000Base-T RJ-45 Connector
Table B.6: Ethernet Connector Definitions
Pin
1
2
3
4
5
6
7
8
B.7 Secondary IDE 44-pin 2mm Conn.
For direct installation of 2.5" IDE HDD (2F-CN17)
For wiring out (2F-CN18)
MIC-3321 User Manual
Signal
TD+
TD-
RD+
N/C
N/C
RD-
N/C
N/C
42
