  • Page 1 User Manual AIMB-279 12/13th Gen Intel® Core™ Processor (Alder Lake / Raptor Lake), Mini-ITX with Q670E/ H610E, PCIe x16 Gen4, 2.5GbE...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the  receiver is connected. Consult the dealer or an experienced radio/TV technician for assistance.  AIMB-279 User Manual...
  • Page 4 Intel 7 i3-12100 Alder Lake 4P/8T SRL62 Intel 7 G7400TE Alder Lake 2P/4T SRL6S Intel 7 G7400E Alder Lake 2P/4T SRL6R Intel 7 G6900TE Alder Lake 2P/2T SRL6P Intel 7 G6900E Alder Lake 2P/2T SRL6Q Intel 7 AIMB-279 User Manual...
  • Page 5 PCI-E / USB Advantech PASS + Bluetooth W165M203E W165M203E M.2 A+E Wireless LAN EWM- EWM- 2230 PCI-E / USB Advantech PASS + Bluetooth W159M201E W159M201E M.2 A+E NVMe PCIe SQF-CM3V1- SQF-CM3V1- 2230 PCIe v3.1 Advantech PASS 512G-EDC 512G-EDC AIMB-279 User Manual...
  • Page 6 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the AIMB-279, check it for signs of ship- ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 7: Table Of Contents

    Board Layout: Jumper and Connector Locations........5 Figure 1.1 Jumper and Connector Locations (Top Side)..... 5 Figure 1.2 Jumper and Connector Locations (Bottom Side)..6 AIMB-279 Board Diagram ................. 7 Figure 1.3 AIMB-279 Block Diagram ........... 7 Safety Precautions ..................7 Jumper Settings ..................8 1.8.1 How to Set Jumpers..............
  • Page 8 SPI BIOS Flash Pin Header (SPI_CN1) ..........27 Table 2.33:SPI BIOS Flash Pin Header (SPI_CN1)....27 2.34 M.2 E-Key Connector (M2_E1)............... 27 Table 2.34:M.2 E-Key Connector (M2E1) ........27 2.35 CMOS Battery Connector (BAT1) ............28 Table 2.35:CMOS Battery Connector (BAT1) ......28 AIMB-279 User Manual viii...
  • Page 9 Figure 3.34.................. 52 Figure 3.35.................. 53 Figure 3.36.................. 53 Figure 3.37.................. 54 Figure 3.38.................. 54 Figure 3.39.................. 55 Figure 3.40.................. 55 Figure 3.41.................. 56 Figure 3.42.................. 56 Figure 3.43.................. 57 Figure 3.44.................. 57 Figure 3.45.................. 58 Figure 3.46.................. 58 AIMB-279 User Manual...
  • Page 10 Chapter Software Introduction & Services ... 83 Introduction ..................... 84 Value-Added Software Services ............. 84 4.2.1 Software API................84 Chapter Chipset Software Installation Utility Before you Begin ..................88 Introduction ..................... 88 Chapter Display Driver Setup......89 AIMB-279 User Manual...
  • Page 11 Introduction ..................... 90 Windows 10 Display Driver Installation ........... 90 Chapter Configuration......91 Introduction ..................... 92 Features ....................92 Installation ....................92 Windows® 10 Driver Setup (Intel® i219LM & Intel® i226)...... 92 AIMB-279 User Manual...
  • Page 12 AIMB-279 User Manual...

  • Page 13: Chapter 1 General Information

    Chapter General Information...

  • Page 14: Introduction

    Introduction AIMB-279 is designed with the Intel® Q670E/H610E PCH for industrial applications that require both performance computing and enhanced power management capabil- ities. The motherboard supports desktop Intel® Core™ i9/i7/i5/i3/Pentium®/Cele- ron® processors, up to 36 MB SmartCache, and 2 x DDR4 3200MHz SODIMM, up to 64GB.

  • Page 15: Graphics

    Power supply voltage: +3.3V, +5V, +12V, -12V, +5VSB  Power consumption: Intel® Core™ i9-13900E 5.2GHz, 2pcs 32GB DDR4  3200MHz, 24V @4.45A with 24V DC Input adapter Board size: 170 x 170 mm (6.69" x 6.69")  Board weight: 0.365 kg  AIMB-279 User Manual...

  • Page 16: Jumpers And Connectors

    Jumpers and Connectors Connectors on the AIMB-279 motherboard link it to devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure the system for your application. The tables below list the function of each of the board jumpers and connectors. Later sections in this chapter give instructions on setting jumpers.

  • Page 17: Board Layout: Jumper And Connector Locations

    Table 1.1: Connector and Header List PCI Express x16 Bifurcation Description Part Reference: SW_PEGSEL1 Board Layout: Jumper and Connector Locations Figure 1.1 Jumper and Connector Locations (Top Side) AIMB-279 User Manual...
  • Page 18 Figure 1.2 Jumper and Connector Locations (Bottom Side) AIMB-279 User Manual...

  • Page 19: Aimb-279 Board Diagram

    AIMB-279 Board Diagram Figure 1.3 AIMB-279 Block Diagram Safety Precautions Warning! Always completely disconnect the power cord from the chassis when- ever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sud- den power surges.

  • Page 20: Jumper Settings

    1.8.2 CMOS Clear (JCMOS1) The AIMB-279 motherboard contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set CMOS1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 21: Edp/Lvds Panel Voltage Selection (Jedp1_Lvds1)

    1 X16 (Default) 2 X8 1.8.6 COM1_RI# Pin RI# / 5V / 12V Selection (JSETCOM1_V1) Table 1.6: COM1_RI# Pin RI# / 5V / 12V Selection (JSETCOM1_V1) Function Jumper Setting Jumper position for RI# (default) Jumper position for 5V AIMB-279 User Manual...

  • Page 22: System Memory

    Jumper position for 12V System Memory AIMB-279 has two sockets for a 260-pin DDR4 SODIMM. These sockets use 1.2V unbuffered double data rate synchronous DRAM (DDR SDRAM). DRAM is available in capacities of 4GB, 8GB, 16GB, and 32GB. The sockets can take any combination with SODIMMs of any size, giving a total memory size of 4GB, 8GB, 16GB, 32GB, and up to max 64GB.

  • Page 23: Chapter 2 Connecting Peripherals

    Chapter Connecting Peripherals...

  • Page 24: Introduction

    Signal ADAPTER VOLTAGE ADAPTER VOLTAGE RJ-45 + USB 3.2 Stack Connector (LAN1_USB12) Table 2.2: RJ-45 + USB 3.2 Stack Connector (LAN1_USB12) Signal Signal VBUS VBUS D_1- D_2- D_1+ D_2+ RX_1- RX_2- RX_1+ RX_2+ TX_1- TX_2- TX_1+ TX_2+ AIMB-279 User Manual...

  • Page 25: Connector (Lan2)

    Signal LAN2_MDI_P0 LAN2_MDI_P2 LAN2_MDI_N0 LAN2_MDI_N2 LAN2_MDI_P1 LAN2_MDI_P3 LAN2_MDI_N1 LAN2_MDI_N3 Universal Serial Bus 3.2 (USB34) Table 2.4: Universal Serial Bus 3.2 (USB34) Signal Signal +5V_B_USBV3 +5V_B_USBV3 USB3_RX_CM_N3 USB3_RX_CM_N4 USB3_RX_CM_P3 USB3_RX_CM_P4 USB3_TX_CM_N3 USB3_TX_CM_N4 USB3_TX_CM_P3 USB3_TX_CM_P4 USB_CM_N3 USB_CM_N4 USB_CM_P3 USB_CM_P4 AIMB-279 User Manual...

  • Page 26: Displayport Connector (Dp2)

    DisplayPort Connector (DP2) Table 2.5: DisplayPort Connector (DP2) Signal Signal DPD_0+ DPD_0- DPD_1+ DPD_1- DPD_2+ DPD_2- DPD_3+ DPD_3- DPD_AUX_EN# DPD_P14 DPD_AUX+ DPD_AUX- DPD_HPD +V3.3_DPD DisplayPort Dual Port Stack-Up Connector (DP1+HDMI1) AIMB-279 User Manual...

  • Page 27: Hd Audio Interface (Analog) (Audio1)

    DP2_3+ HDMI1_z_CLK- DP2_3- DP2_AUX_EN# HDMI1_SCL DP2_AUX+ HDMI1_SDA DP2_AUX- +V5_HDMI1 DP2_HPD HDMI1_HPD +V3.3_DP1 HD Audio Interface (Analog) (AUDIO1) Table 2.7: HD Audio Interface (Analog) (AUDIO1) Signal MIC IN LINE OUT LINE IN Audio Amplifier Output Pin Header (AMP1) AIMB-279 User Manual...

  • Page 28: Pci Express X16 Slot (Pciex16_1)

    Reserved SMB_DATA Reserved Reserved +3.3V Reserved Reserved +3.3V +3.3VAUX +3.3V WAKE# PWRGD Reserved REFCLK+ TX0+ REFCLK- TX0- RX0+ Reserved RX0- DETECT# TX1+ Advantech define TX1- RX1+ RX1- TX2+ TX2- RX2+ RX2- TX3+ TX3- RX3+ Reserved RX3- Reserved AIMB-279 User Manual...
  • Page 29 RX6+ RX6- TX7+ TX7- RX7+ Reserved RX7- TX8+ Reserved TX8- RX8+ RX8- TX9+ TX9- RX9+ RX9- TX10+ TX10- RX10+ RX10- TX11+ TX11- RX11+ RX11- TX12+ TX12- RX12+ RX12- TX13+ TX13- RX13+ RX13- TX14+ TX14- RX14+ RX14- TX15+ AIMB-279 User Manual...

  • Page 30: Imvp9.1 Programming Header (Vr_Pmb1)

    Table 2.11: System Fan #1 Connector (SYSFAN1) Signal SYSTEM FAN VCC SYSTEM FAN SPEED SYSTEM FAN PWM 2.13 CPU FAN Connector (CPUFAN1) Table 2.12: CPU FAN Connector (CPUFAN1) Signal CPU FAN VCC CPU FAN SPEED CPU FAN PWM AIMB-279 User Manual...

  • Page 31: Edp Connector / Lvds Connector (Edp1_Lvds1)

    LVDS_ED0+ LVDS_OD1- LVDS_ED1- LVDS_OD1+ LVDS_ED1+ LVDS_OD2- LVDS_ED2- LVDS_OD2+ LVDS_ED2+ LVDS_OCK- LVDS_ECK- LVDS_OCK+ LVDS_ECK+ LVDS_OD3- LVDS_ED3- LVDS_OD3+ LVDS_ED3+ LVDS ENBKL LVDS VCON Table 2.14: EDP Connector (EDP1) Signal Signal LVDS DETECT# EDP_TX2- EDP_TX2+ EDP_TX1- EDP_TX1+ EDP_TX0- EDP_TX0+ EDP_TX3- AIMB-279 User Manual...

  • Page 32: Lvds Vesa, Jeida Format Selection Pin Header (Jlvds_Vcon1)

    (JLVDS_VCON1) Signal +3.3V Advantech define 2.16 EDP Panel / LVDS Panel Voltage Selection (JEDP1_LVDS1) Table 2.16: EDP Panel / LVDS Panel Voltage Selection (JEDP1_LVDS1) Signal Signal +12V +3.3V 2.17 EDP / LVDS Backlight Inverter Power Connector (INV1) AIMB-279 User Manual...

  • Page 33: At / Atx Mode Selection (Pson1)

    VCCAT +3.3V VCCATX 2.19 8-Bit General Purpose I/O Pin Header (GPIO1) Table 2.19: 8-Bit General Purpose I/O Pin Header (GPIO1) Signal Signal SIO_GPIO0 SIO_GPIO4 SIO_GPIO1 SIO_GPIO5 SIO_GPIO2 SIO_GPIO6 SIO_GPIO3 SIO_GPIO7 +V5A_GPIO 2.20 ESPI Port 80 Connector (ESPI_P80) AIMB-279 User Manual...

  • Page 34: Com1 Connector (Com1)

    ESPI_DEG_IO_0 ESPI_RST# +V3.3 ESPI_CS0# ESPI_DEG_IO_3 +V3.3SB ESPI_DEG_IO_2 2.21 COM1 Connector (COM1) Table 2.21: COM1 Connector (COM1) Signal Signal COM1_DCD# COM1_SIN COM1_SOUT COM1_DTR# COM1_DSR# COM1_RTS# COM1_CTS# COM1_RI_V# 2.22 SATA Power (SATA_PWR2) Table 2.22: SATA Power (SATA_PWR2) Signal +V12 AIMB-279 User Manual...

  • Page 35: Com2 Connector (Com2)

    COM2_RTS# COM2_CTS# COM2_RI# 2.24 SATA Power (SATA_PWR1) Table 2.24: SATA Power (SATA_PWR1) Signal +V12 2.25 PWRBTN#/ RESET#/HDD LED/SMBUS (JFP1) Table 2.25: PWRBTN#/ RESET#/HDD LED/SMBUS (JFP1) Signal Signal HDD LED+ Power Button HDD LED- SMB_DATA RESET Button- SMB_CLK AIMB-279 User Manual...

  • Page 36: Power Led Pin Header (Jfp2)

    Table 2.26: Power LED Pin Header (JFP2) Signal Power LED+ Power LED- 2.27 Serial ATA Interface Connector (SATA2) Table 2.27: Serial ATA Interface Connector (SATA2) Signal 2.28 Serial ATA Interface Connector (SATA1) Table 2.28: Serial ATA Interface Connector (SATA1) Signal AIMB-279 User Manual...

  • Page 37: Usb 2.0 Front Panel Header (Usb56)

    USB_CM_P5 USB_CM_P6 2.30 CMOS Mode Selection (JCMOS1) Table 2.30: CMOS Mode Selection (JCMOS1) Signal RTC_RESET# 2.31 Flash Descriptor Security Override Pin Header (JME1) Table 2.31: Flash Descriptor Security Override Pin Header (ME1) Signal Advantech defined Advantech defined AIMB-279 User Manual...

  • Page 38: M-Key Connector (M2_M1)

    PETp0/SATA-A+ PERST# (O)(0/3.3V) or N/C CLKREQ# (I/O)(0/3.3V) or N/C REFCLKn PEWAKE# (I/O)(0/3.3V) or N/C REFCLKp Connector key Connector key Connector key Connector key Connector key Connector key Connector key Connector key SUSCLK(32kHz) (O)(0/3.3V) PEDET (NC-PCIe/GND- 3.3V SATA) AIMB-279 User Manual...

  • Page 39: Spi Bios Flash Pin Header (Spi_Cn1)

    Table 2.33: SPI BIOS Flash Pin Header (SPI_CN1) Signal Signal SPISKT_CS0# +3.3V_SPI SPISKT_MISO SPISKT_CLK SPISKT_MOSI 2.34 M.2 E-Key Connector (M2_E1) Table 2.34: M.2 E-Key Connector (M2E1) Signal Signal +3.3V USB_D+ +3.3V USB_D- WLAN_LED1# BT_PCMCLK CNV_WR_D1- BT_PCMFRM CNV_WR_D1+ BT_PCMIN BT_PCMOUT CNV_WR_D0- BT_LED# CNV_WR_D0+ UART WAKE# AIMB-279 User Manual...

  • Page 40: Cmos Battery Connector (Bat1)

    CL_RST# CL_DAT PERp0 CL_CLK PERn0 CNV_GNSS_PA_BLANKING CNV_MFUART2_TXD REFCLKp0 CNV_MFUART2_RXD REFCLKn0 SUSCLK WLAN_RST# CLKREQ0# BT_RF_KILL# PEWAKE0# WIFI_RF_KILL# CNV_WT_D1- CNV_WT_D1+ CNV_WT_D0- CNV_WT_D0+ CNV_WT_CLK- +3.3V CNV_WT_CLK+ +3.3V 2.35 CMOS Battery Connector (BAT1) Table 2.35: CMOS Battery Connector (BAT1) Signal +VBAT AIMB-279 User Manual...
  • Page 41 COM1 RI# Selection Pin Header (JSETCOM1_V1) Table 2.37: COM1 RI# Selection Pin Header (JSETCOM1_V1) Signal Signal RI# [1] Advantech define Advantech define +12V Advantech define 2.38 PCI Express x16 Bifurcation (SW_PEGSEL1) Table 2.38: PCI Express x16 Bifurcation (SW_PEGSEL1) Signal VCC_CFG AIMB-279 User Manual...
  • Page 42 AIMB-279 User Manual...
  • Page 43 Chapter BIOS Operation...
  • Page 44 AIMB-279 setup screens. BIOS Setup The AIMB-279 Series system has AMI BIOS built in, with a CMOS SETUP utility that allows users to configure required settings or to activate certain system features. The CMOS Setup saves the configuration in the CMOS RAM of the motherboard. When the power is turned off, the battery on the board supplies the necessary power to pre- serve the CMOS RAM.
  • Page 45 System Date using the <Arrow> keys. Enter new values via the keyboard. Press the <Tab> or <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. AIMB-279 User Manual...
  • Page 46 Advanced BIOS Setup option by highlighting it using the <Arrow> keys. All Advanced BIOS Setup options are described in this section. The Advanced BIOS Setup screen is shown below. The sub-menus are described on the following pages. Figure 3.2 AIMB-279 User Manual...
  • Page 47 3.2.2.1 CPU Configuration Advanced → CPU Configuration Figure 3.3 Efficient-Core Information Advanced → CPU Configuration → Efficient-Core Information Figure 3.4 AIMB-279 User Manual...
  • Page 48 Performance-Core Information Advanced → CPU Configuration → Performance-Core Information Figure 3.5 CPU SMM Enhancement Advanced → CPU SMM Enhancement Figure 3.6 AIMB-279 User Manual...
  • Page 49 3.2.2.2 Power & Performance Advanced → Power & Performance Figure 3.7 CPU - Power Management Control Advanced → Power & Performance → CPU - Power Management Control Figure 3.8 AIMB-279 User Manual...
  • Page 50 Figure 3.9 Current Turbo Settings Advanced → Power & Performance → CPU - Power Management Control → View/ Configure Turbo Option Figure 3.10 AIMB-279 User Manual...
  • Page 51 Turbo Ratio Limit Options Advanced → Power & Performance → CPU – Power Management Control → View/ Configure Turbo Option → Turbo Ratio Limit Options Figure 3.11 Figure 3.12 AIMB-279 User Manual...
  • Page 52 Figure 3.13 CPU VR Settings Advanced → Power & Performance → CPU - Power Management Control → CPU VR Settings Figure 3.14 AIMB-279 User Manual...
  • Page 53 Acoustic Noise Settings Advanced → Power & Performance → CPU - Power Management Control → CPU VR Settings → Acoustic Noise Settings Figure 3.15 AIMB-279 User Manual...
  • Page 54 Core/IA VR Settings Advanced → Power & Performance → CPU - Power Management Control → CPU VR Settings → Core/IA Settings Figure 3.16 Figure 3.17 AIMB-279 User Manual...
  • Page 55 GT VR Settings Advanced → Power & Performance → CPU - Power Management Control → CPU VR Settings → GT VR Settings Figure 3.18 Figure 3.19 AIMB-279 User Manual...
  • Page 56 RFI Settings Advanced → Power & Performance → CPU - Power Management Control → CPU VR Settings → RFI Settings Figure 3.20 AIMB-279 User Manual...
  • Page 57 Custom P-State Table Advanced → Power & Performance → CPU - Power Management Control → Cus- tom P-State Table Figure 3.21 AIMB-279 User Manual...
  • Page 58 CPU Lock Configuration Advanced → Power & Performance → CPU - Power Management Control → CPU Lock Configuration Figure 3.22 GT - Power Management Control Advanced → Power & Performance → GT - Power Management Control Figure 3.23 AIMB-279 User Manual...
  • Page 59 3.2.2.3 PCH-FW Configuration Advanced → PCH-FW Configuration Figure 3.24 Figure 3.25 AIMB-279 User Manual...
  • Page 60 3.2.2.4 AMT Configuration Advanced → PCH-FW Configuration → AMT Configuration Figure 3.26 AMT Configuration Advanced → PCH-FW Configuration → AMT Configuration → ASF Configuration Figure 3.27 AIMB-279 User Manual...
  • Page 61 Secure Erase Configuration Advanced → PCH-FW Configuration → AMT Configuration → Secure Erase Config- uration Figure 3.28 AIMB-279 User Manual...
  • Page 62 One Click Recovery (ORC) Configuration Advanced → PCH-FW Configuration → AMT Configuration → One Click Recovery (ORC) Configuration Figure 3.29 Firmware Update Configuration Advanced → PCH-FW Configuration → Firmware Update Configuration Figure 3.30   AIMB-279 User Manual...
  • Page 63 PTT Configuration Advanced → PCH-FW Configuration → PTT Configuration Figure 3.31 FIPS Configuration Advanced → PCH-FW Configuration → FIPS Configuration Figure 3.32 AIMB-279 User Manual...
  • Page 64 Unique Platform Id Configuration Advanced → PCH-FW Configuration → Unique Platform Id Configuration Figure 3.33 ME Debug Configuration Advanced → PCH-FW Configuration → ME Debug Configuration Figure 3.34 AIMB-279 User Manual...
  • Page 65 SMBIOS Type 130 OEM Capabilities Advanced → PCH-FW Configuration → ME debug Configuration → SMBIOS Type 130 OEM Capabilities Figure 3.35 Anti-Rollback SVN Configuration Advanced → PCH-FW Configuration → Anti-Rollback SVN Configuration Figure 3.36 AIMB-279 User Manual...
  • Page 66 OEM Key Revocation Configuration Advanced → PCH-FW Configuration → OEM Key Revocation Configuration Figure 3.37 3.2.2.5 Trusted Computing Settings Advanced → Trusted Computing Figure 3.38 AIMB-279 User Manual...
  • Page 67 3.2.2.6 ACPI Settings Advanced → ACPI Settings Figure 3.39 3.2.2.7 NCT6126D Super IO Configuration Advanced → NCT6126D Super IO Configuration Figure 3.40 AIMB-279 User Manual...
  • Page 68 Serial Port 1 Configuration Advanced → NCT6126D Super IO Configuration → Serial Port 1 Configuration Figure 3.41 Serial Port 2 Configuration Advanced → NCT6126D Super IO Configuration → Serial Port 2 Configuration   Figure 3.42 AIMB-279 User Manual...
  • Page 69 3.2.2.8 NCT6126D HW Monitor Advanced → NCT6126D HW Monitor Figure 3.43 Smart Fan Function Advanced → NCT6126D HW Monitor → Smart Fan Function Figure 3.44 AIMB-279 User Manual...
  • Page 70 Digital I/O Configuration Advanced → NCT6126D HW Monitor → Digital I/O Configuration Figure 3.45 3.2.2.9 S5 RTC Wake Settings Advanced → S5 RTC Wake Settings Figure 3.46 AIMB-279 User Manual...
  • Page 71 3.2.2.10 Serial Port Console Redirection Advanced → Serial Port Console Redirection Figure 3.47 Legacy Console Redirection Settings Advanced → Serial Port Console Redirection → Legacy Console Redirection Set- tings Figure 3.48 AIMB-279 User Manual...
  • Page 72 3.2.2.11 Intel® TXT Information Advanced → Intel TXT Information Figure 3.49 3.2.2.12 USB Configuration Advanced → USB Configuration Figure 3.50 AIMB-279 User Manual...
  • Page 73 3.2.2.13 Network Stack Configuration Advanced → Network Stack Configuration Figure 3.51 3.2.2.14 CSM Configuration Advanced → CSM Configuration Figure 3.52 AIMB-279 User Manual...
  • Page 74 3.2.2.15 NVMe Configuration Advanced → NVMe Configuration Figure 3.53 3.2.2.16 Tls Auth Configuration Advanced → Tls Auth Configuration Figure 3.54 AIMB-279 User Manual...
  • Page 75 3.2.2.17 Driver Health Advanced → Driver Health Figure 3.55 AIMB-279 User Manual...
  • Page 76 Users can display a Chipset Setup option by highlighting it using the <Arrow> keys. All Chipset Setup options are described in this section. The Chipset Setup screens are shown below. The sub- menus are described on the following pages. Figure 3.56 AIMB-279 User Manual...
  • Page 77 3.2.3.1 System Agent (SA) Configuration Chipset → System Agent (SA) Configuration Figure 3.57 Memory Configuration Chipset → System Agent (SA) Configuration → Memory Configuration Figure 3.58 AIMB-279 User Manual...
  • Page 78 Graphics Configuration Chipset → System Agent (SA) Configuration → Graphics Configuration Figure 3.59 External Gfx Card Primary Display Configuration Chipset → System Agent (SA) Configuration → Graphics Configuration → External Gfx Card Primary Display Configuration Figure 3.60 AIMB-279 User Manual...
  • Page 79 LCD Control Chipset → System Agent (SA) Configuration → Graphics Configuration → LCD Con- trol Figure 3.61 DMI/OPI Configuration Chipset → System Agent (SA) Configuration → DMI/OPI Configuration Figure 3.62 AIMB-279 User Manual...
  • Page 80 DMI Advanced Menu Chipset → System Agent (SA) Configuration → DMI/OPI Configuration → DMI Advanced Menu Figure 3.63 Figure 3.64 AIMB-279 User Manual...
  • Page 81 VMD Setup Menu Chipset → System Agent (SA) Configuration → VMD Setup Menu Figure 3.65 PCI Express Configuration Chipset → System Agent (SA) Configuration → PCI Express Configuration Figure 3.66 AIMB-279 User Manual...
  • Page 82 PCI Express Configuration Chipset → System Agent (SA) Configuration → PCI Express Configuration → PCI EXPRESS SLOT Figure 3.67 Figure 3.68 AIMB-279 User Manual...
  • Page 83 3.2.3.2 PCH-I/O Configuration Chipset → PCH-I/O Configuration Figure 3.69 ErP Support Note Chipset → PCH-I/O Configuration → ErP Support Figure 3.70 AIMB-279 User Manual...
  • Page 84 [PCIE Wake] Connect to PCIe slots, depending on add-on card driver behavior. [RT: S5] [WOR: S5] [WOL: depends on LAN chip and driver behavior(GBE)] Support S3/S4/S5 (with I219 & I226) PCI Express Configuration Chipset → PCH-I/O Configuration → PCI Express Configuration Figure 3.71 AIMB-279 User Manual...
  • Page 85 PCIe EQ Settings Chipset → PCH-I/O Configuration → PCI Express Configuration → PCIe EQ Settings Figure 3.72 LAN2 Chipset → PCH-I/O Configuration → PCI Express Configuration → LAN2 Figure 3.73 AIMB-279 User Manual...
  • Page 86 Figure 3.74 M.2 E-Key Chipset → PCH-I/O Configuration → PCI Express Configuration → M.2 E-Key Figure 3.75 AIMB-279 User Manual...
  • Page 87 Figure 3.76 M.2 M-Key Chipset → PCH-I/O Configuration → PCI Express Configuration → M.2 M-Key Figure 3.77 AIMB-279 User Manual...
  • Page 88 Figure 3.78 SATA Configuration Chipset → PCH-I/O Configuration → SATA Configuration Figure 3.79 AIMB-279 User Manual...
  • Page 89 Figure 3.80 Security Configuration Chipset → PCH-I/O Configuration → Security Configuration Figure 3.81 AIMB-279 User Manual...
  • Page 90 HD Audio Subsystem Configuration Settings Chipset → PCH-I/O Configuration → HD Audio Subsystem Configuration Settings Figure 3.82 3.2.4 Security Figure 3.83 AIMB-279 User Manual...
  • Page 91 Administrator password. User Password  Select this option and press <ENTER> to access the sub-menu, and then type in the password to set the User Password. Secure Boot Security → Secure Boot Figure 3.84 AIMB-279 User Manual...
  • Page 92 Figure 3.85 Setup Prompt Timeout  User the <+> and <-> keys to adjust the number of seconds to wait for the setup activation key. Bootup NumLock State [Off]  On or off power state for the NumLock. AIMB-279 User Manual...
  • Page 93 Select this option to quit Setup without making any permanent changes to the system configuration. 1. Select Discard Changes and Reset from the Save & Exit menu and press <Enter>. The following message appears: Discard Changes and Exit Setup AIMB-279 User Manual...
  • Page 94 Select Restore Defaults from the Exit menu and press <Enter>. Save as User Default  Save the all current settings as a user default. Restore User Default  Restore all settings to user default values. Boot Override  Shows the boot device types on the system. AIMB-279 User Manual...
  • Page 95 Chapter Software Introduction & Services...
  • Page 96 Introduction The mission of Advantech Embedded Software Services is to "Enhance quality of life with Advantech platforms and Microsoft® Windows® embedded technology." We enable Windows® Embedded software products on Advantech platforms to more effectively support the embedded computing community. Customers are freed from the hassle of dealing with multiple vendors (hardware suppliers, system integrators, embedded OS distributors) for projects.
  • Page 97 (restarting the system) after a certain number of seconds. Hardware Monitor The Hardware Monitor (HWM) API is a system health super- vision API that inspects certain condition indexes, such as fan speed, temperature, and voltage. AIMB-279 User Manual...
  • Page 98 AIMB-279 User Manual...
  • Page 99 Chapter Chipset Software Installation Utility...
  • Page 100 Before you Begin To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the AIMB-279 are located on the Advantech support website: http://support.advantech.com/support. The drivers on the support website will guide and link you to the utilities and drivers under a Win- dows system.
  • Page 101 Chapter Display Driver Setup...
  • Page 102 See Chapter 5 for information on installing the CSI util- ity. Download the driver from the website to your computer. Navigate to the “AIMB-279 Technical Downloads” folder and complete the installation of the drivers for Windows AIMB-279 User Manual...
  • Page 103 Chapter LAN Configuration...
  • Page 104 Introduction The AIMB-279 has two Gigabit Ethernet LANs via dedicated PCI Express x1 lanes, Intel® i226 and I219LM (Phy) that offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ethernet at 2500 Mbps.
  • Page 105 AIMB-279 User Manual...
  • Page 106 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
