User Manual
MIC-733
AI Inference System Based on
®
the NVIDIA
Microcomputer
AI 推理系统,搭配 NVIDIA
Jetson AGX Orin ™ 微型计算机
AI 推理系統,搭配 NVIDIA
Jetson AGX Orin ™ 微型電腦
Jetson AGX Orin™
®
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the MIC-733 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Advantech MIC-733

  • Page 1 User Manual MIC-733 AI Inference System Based on ® Jetson AGX Orin™ the NVIDIA Microcomputer ® AI 推理系统,搭配 NVIDIA Jetson AGX Orin ™ 微型计算机 ® AI 推理系統,搭配 NVIDIA Jetson AGX Orin ™ 微型電腦...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 Product Warranty (2 Years) / 产品质量保证 (两年)/ 產品品質保證 (兩年) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
  • Page 4 FCC A 级 注意:根据 FCC 规则第 15 款,本设备已经过检测并被判定符合 A 级数字设备标准。 这些限制旨在为商业环境下的系统操作提供合理保护,使其免受有害干扰。本设备会 产生、耗费和发射无线电频率能量,如果没有按照手册说明正确安装和使用,可能会 对无线电通讯造成有害干扰。此时,用户需自行解决干扰问题。 FCC A 级 注意:根據 FCC 規則第 15 款,本設備已經過檢測並被判定符合 A 級數位設備標準。 這些限制旨在為商業環境下的系統操作提供合理保護,使其免受有害干擾。本設備會 產生、耗費和發射無線電頻率能量,如果沒有按照手冊說明正確安裝和使用,可能會 對無線電通訊造成有害干擾。CNS15936 警告:為避免電磁干擾,本產品不應安裝或使 用於住宅環境。 本產品於國內裝置使用時,其電源僅限使用機架電源模組所提供直流電源輸入,不得 使用交流電源及附加其他電源轉換裝置提供電源,其電源輸入電壓及電流請依說明書 規定使用。 MIC-733 User Manual/用户手册...
  • Page 5 Packing List / 包装清单 / 包裝清單 Before system installation, check that the items listed below are included and in good condition. If any item does not accord with the list, contact your dealer immediately. 1 x MIC-733  1 x Power terminal block (4P) ...
  • Page 6 For more information on this and other Advantech products, please visit our website http://www.advantech.com For technical support and service, please visit our support website for MIC-733 at: https://advt.ch/mic-733 Register your products on our website and get 2 months extra warranty for free at: http://www.register.advantech.com...
  • Page 7 The equipment should be installed in a restricted access area where only quali- fied and skilled personnel have access. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. 请仔细阅读此安全操作说明。...
  • Page 8 用濕抹布清洗設備前,請從插座拔下電源線。請不要使用液體或去污噴霧劑清洗 設備。 對於使用電源線的設備,設備周圍必須有容易接觸到的電源插座。 請不要在潮濕環境中使用設備。 請在安裝前確保設備放置在可靠的平面上,意外跌落可能會導致設備損壞。 設備外殼的開口是用於空氣對流,從而防止設備過熱。請不要覆蓋這些開口。 當您連接設備到電源插座上前,請確認電源插座的電壓是否符合要求。 請將電源線佈置在人們不易絆到的位置,並不要在電源線上覆蓋任何雜物。 請注意設備上的所有警告標識。 如果長時間不使用設備,請將其同電源插座斷開,避免設備被超標的電壓波動損 壞。 請不要讓任何液體流入通風口,以免引起火災或者短路。 請不要自行打開設備。為了確保您的安全,請由經過認證的工程師來打開設備。 如遇下列情況,請由專業人員來維修:  電源線或者插頭損壞;  設備內部有液體流入;  設備曾暴露在過於潮濕的環境中使用;  設備無法正常工作,或您無法通過用戶手冊來使其正常工作;  設備跌落或者損壞;  設備有明顯的外觀破損。 免責聲明:該安全指示符合 IEC 704-1 的要求。研華公司對其內容的準確性不承擔任 何法律責任。 警告使用者:這是甲類資料產品,在居住的環境中使用時,可能會造成射頻干擾,在 這種情況下,使用者會被要求採取某些適當的對策。 電腦配置了由電池供電的即時時鐘電路,如果電池更換不正確,將有爆炸的危險,因 此只可以使用製造商推薦的同一種或者同等型號的電池進行替換。請按照製造商的指 示處理舊電池。 MIC-733 User Manual/用户手册 viii...
  • Page 9 UL ou une source CC adaptée à une utilisation à Tmax minimum 60°C dont la sortie est conforme SELV ou ES1 et est nominale 9-36 V , 15-5A min., si besoin d'aide supplémentaire, veuillez contacter Advantech pour plus d'informa- tions. L'équipement n'est pas adapté à une utilisation dans des endroits où des ...
  • Page 10 Disconnect the power before making any configuration changes. A sudden  surge of power after connecting a jumper or installing a card may damage sen- sitive electronic components. 为了保护您和您的设备免受伤害或损坏。请遵照以下安全措施:  操作设备之前,请务必断开机箱电源,以防触电。不可在电源接通时接触 CPU 板或其它板上的任何组件。  在更改任何配置之前请断开电源,以免在您连接跳线或安装卡时,瞬间电涌损坏 敏感电子元件。 為了保護您和您的設備免受傷害或損壞,請遵照以下安全措施:  操作設備之前,請務必斷開主機殼電源,以防觸電。不可在電源接通時接觸 CPU 卡或其它卡上的任何元件。  在更改任何配置之前請切斷電源,以免在您連接跳線或 安裝卡時,瞬間電湧損 壞敏感電子元件。 MIC-733 User Manual/用户手册...
  • Page 11 Electrical Specifications /电源规格/電源規格 ......5 Environmental Specifications /环境规格/環境規格 ....5 Chapter H/W Installation 硬件安装 硬體安裝7 MIC-733 I/O Overview / I/O 概观 / I/O 概觀......8 Connectors /接口/介面 ...........8 2.2.1 Power Button and Power Indicator / 电源开关及指示灯 / 電源開關 及指示燈 ..........8 2.2.2 4 x In - 4 x Out DI/DO ..............9 Table 2.1: Isolated Digital Input ...........
  • Page 12 MIC-733 User Manual/用户手册...
  • Page 13 Chapter General Introduction 概述 產品資訊...
  • Page 14 The MIC-733 is pre-integrated with NVIDIA Jetson AGX Orin™, and is ideal for use in industrial AI applications. The MIC-733 design includes 4 x Gigabit Ethernet LAN ports, 1 x HDMI video, 4ch-DI, 4ch-DO, 2 x RS-232/RS-422/RS-485 (internal pin header reserved), 2 x external USB 2.0, 4 x external USB 3.2, 1 x internal Micro USB for system recovery, 2 x Mini PCIe (Signal: PCIe+USB), 1 x M.2 2280 (PCIe x4...
  • Page 15 1 x iDoor 空間 & 1 x iModule 連接器  1 x 電源開關  1 x M.2 2280 (signal: PCIe x4 NVMe)  1 x M.2 3052 (signal: USB)  1 x Micro SD  2 x NANO SIM MIC-733 User Manual/用户手册...
  • Page 16 Dimensions: 192 x 230 x 87 mm (7.56" x 9.06" x 3.43") Reference Weight: 4.5 kg   尺寸:192 x 230 x 87 mm (7.56" x 9.06" x 3.43")  参考重量:4.5 kg  尺寸:192 x 230 x 87 mm (7.56" x 9.06" x 3.43")  參考重量:4.5 kg MIC-733 User Manual/用户手册...
  • Page 17 工作湿度:95% @ 40°C(非凝结) 储存温度:-40 ~ 85°C (-40 ~ 185°F)   储存湿度:60°C @ 95% RH,非凝结 工作溫度:0 ~ +60°C (14 ~ 140°F)*   工作濕度:95% @ 40°C (非凝結) 儲存溫度:-40 ~ 85°C (-40 ~ 185°F)   儲存濕度:60°C @ 95% RH,非凝結 MIC-733 User Manual/用户手册...
  • Page 18 MIC-733 User Manual/用户手册...
  • Page 19 Chapter H/W Installation 硬件安装 硬體安裝...
  • Page 20 Power Button and Power Indicator / 电源开关及指示灯 / 電源開 關及指示燈 The MIC-733 comes with a Power ON/OFF Button with LED indicators on the front side to show ON status (Green LED) and OFF/SUSPEND status (Red LED). It also supports the dual function of Soft Power-On/Off (instant off or a 4-second delay), and suspend.
  • Page 21 2.2.2 4 x In - 4 x Out DI/DO MIC-733 comes with a 4 x In / 4 x Out DI/DO port on the front side of the device. MIC-733 在本机前面板提供了一组支持 4ch 输入 /4ch 输出的 DI/DO。 MIC-733 在本機前面板提供了一組支援 4ch 輸入 /4ch 輸出的 DI/DO。...
  • Page 22 2.2.3 USB 2.0 & USB 3.0 The MIC-733 provides two USB 2.0 and four USB 3.2 Gen 2 on the front panel. MIC-730AI 在前面板上提供了 2 個 USB 2.0 以及 4 個 USB 3.2 Gen 2。 MIC-730AI 在前面板上提供了 2 个 USB 2.0 以及 4 个 USB 3.2 Gen 2。...
  • Page 23 2.2.4 Ethernet (LAN) / 网络 / 網路 MIC-733 comes with one LAN Port on the front side of the device. The Ethernet LAN port has two LEDs. The Green LED indicates activity; the other Green-Amber LED indicates speed. MIC-733 在本机前面板提供了两组网路埠,其上方有两个 LED 灯,绿色 LED 灯表示...
  • Page 24 Choose the appropriate wire diameter. The terminal block is suitable for a 14 AWG torque value of 7 in-lbf. 连接线使用直流电 须由专业人员安装。 只使用铜导体。 选择合适的线径。 适合 14 AWG 的接线盒扭矩值为 7 in-lbf。 連接線使用直流電 須由專業人員安裝。 只使用銅導體。 選擇合適的線徑。 適合 14 AWG 的接線盒扭矩值為 7 in-lbf。 MIC-733 User Manual/用户手册...
  • Page 25 2.2.6 iModule Connector / iModule 连接器 / iModule 連接器 MIC-733 provides one iModule connector which is compatible with MIC-75M10* to add one PCIe x8 card. (Please find more details on the Advantech i-Module website.) MIC-733 内部提供了一个连接 iModule 连接器可相容于 MIC-75M10* 并可提供扩充 1 个PCIe x8 卡片。...
  • Page 26 2.2.7 AT/ATX Power Mode Jumper / 电源模式跳线器/電源模式跳線器 MIC-733 provides one AT/ATX jumper. MIC-733 内部提供了一个 AT/ATX 跳线器。 MIC-733 內部提供了一個 AT/ATX 跳線器。 Table 2.4: PSON1 Power Mode MIC-733 User Manual/用户手册...
  • Page 27 2.2.8 Micro SD MIC-733 provides one Micro SD card slot. MIC-733 内部提供了一个 Micro SD 卡卡槽。 MIC-733 內部提供了一個 Micro SD 卡卡槽。 MIC-733 User Manual/用户手册...
  • Page 28 2.2.9 Internal USB 2.0 / 內部 USB 2.0 MIC-733 provides one USB 2.0 on board for a software license key. Only the upper one is available. MIC-733 在本机内部提供一组 USB 2.0 供软件密钥连接使用。只有上方端口可用。 MIC-733 在本機內部提供一組 USB 2.0 供軟體金鑰埠使用。只有上方埠可用。 MIC-733 User Manual/用户手册...
  • Page 29 2.2.10 Micro USB MIC-733 provides one Micro USB for system BSP recovery (OTG). MIC-733 在本机内部提供一组 Micro USB 用于系统 BSP 复原。 MIC-733 在本機内部提供一組 Micro USB 用於系統 BSP 復原。 MIC-733 User Manual/用户手册...
  • Page 30 2.2.11 Reset & Recovery Button / 重启 & 复原按钮 / 重啟 & 復原按鈕 MIC-733 provides two buttons: one is for Reset and other one is Recovery, which is for system BSP recovery. MIC-733 内部提供了 2 个按钮,分别是 Reset 及 Recovery,此两个按钮主要用于系 统 BSP 复原使用。...
  • Page 31 2.2.12 Mini PCIe Slot / 插槽 MIC-733 provides two Mini PCIe slots; the signals are PCIe x1 & USB 2.0. MIC-733 在本机内部提供了两组 Mini PCIe card 的扩展槽,此两组扩展槽均支援 PCIe x1 & USB 2.0 讯号。 MIC-733 在本機内部提供了兩組 Mini PCIe card 的擴充槽,此兩組擴充槽均支援 PCIe x1 & USB 2.0 訊號。...
  • Page 32 2.2.13 M.2 2280 Slot / 插槽 MIC-733 provides one M.2 2280 slot which can support a PCIe x4 NVMe storage device. MIC-733 在本机内部提供一个支援 PCIex4 NVMe M.2 2280 的卡槽。 MIC-733 在本機内部提供一個支援 PCIex4 NVMe M.2 2280 的卡槽。 MIC-733 User Manual/用户手册...
  • Page 33 2.2.14 M.2 3052 Slot / 插槽 MIC-733 provides one M.2 3052 slot for a USB 2.0 signal. MIC-733 在本机内部提供一个 M.2 3052 卡槽,其支持讯号为 USB 2.0。 MIC-733 在本機内部提供一個 M.2 3052 卡槽,其支援訊號為 USB 2.0。 MIC-733 User Manual/用户手册...
  • Page 34 2.2.15 NANO SIM Slot / 插槽 MIC-733 provides two NANO SIM; SIM1 for a Mini PCIe slot and SIM2 for an M.2 3052 slot. MIC-733 在本机内部提供两个 NANO SIM 卡槽,其中 SIM1 提供与 Mini PCIe slot 连 接使用,而 SIM2 则提供给 M.2 3052 使用。...
  • Page 35 2.2.16 COM Port / 端口 / 埠 MIC-733 provides 2 x COM ports internally for RS-232/RS-422/RS-485 usage. MIC-733 在本机内部提供 2 组 COM 端口供 RS-232/RS-422/RS-485 使用。 MIC-733 在本機內部提供 2 組 COM 埠供 RS-232/RS-422/RS-485 使用。 When using the COM port, please adjust both SW_COM1 and SW_COM2 shown in the figure below to OFF (the factory default, as in the figure below).
  • Page 36 For RS485: sudo bash /opt/advantech/tools/serial_port.sh rs485 com1 sudo bash /opt/advantech/tools/serial_port.sh rs485 com2 在使用 2 个 COM 端口之前,通过命令打开终端以配置 COM 端口模式: $sudo chmod 777 /opt/advantech/tools/serial_port.sh For RS232: $sudo bash /opt/advantech/tools/serial_port.sh rs232 com1 $sudo bash /opt/advantech/tools/serial_port.sh rs232 com2 For RS422: sudo bash /opt/advantech/tools/serial_port.sh rs422 com1 sudo bash /opt/advantech/tools/serial_port.sh rs422 com2...
  • Page 37 2.2.17 Terminal Port / 终端端口 / 終端埠 MIC-733 provides one COM port internally for entering terminal mode. MIC-733 在本机内部提供 1 组终端机端口供进入终端机模式使用。 MIC-733 在本機內部提供 1 組終端埠供進入安裝終端模式使用。 MIC-733 User Manual/用户手册...
  • Page 38 MIC-733 User Manual/用户手册...
  • Page 39 Chapter Installation 安装 安裝...
  • Page 40 Bracket Installation / 支架安装 / 支架安裝 Take out the mounting kit from the accessory box. Secure with 4 x screws (P/N: 1930007259-01 M4x4L F/S D=8.5 H=1.5 (2+) ST/ H BZn-NK) and install the system on a table surface. 1930007259-01 *4pcs MIC-73328 User Manual/用户手册...
  • Page 41 1930007979 * 4pcs Thermal pad 1990021546N010 - 40x25(mm) : miniPCIe x2 , M.2 3052 x1 1990037043N000 - 59x24(mm) : M.2 2280 x1 MIC-733 User Manual/用户手册...
  • Page 42 限用物質含有情況標示聲明書 Declaration of the Presence Condition of Restricted Substance Marking PLM MDR NO: MDR-006782 設備名稱:電腦 型號 ( 型式 ):MIC-733-AO5A1 Equipment name: Computer Type designation (Type): MIC-733-AO5A1 限用物質及其化學符號 Restricted substances and their chemical symbols 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚...
  • Page 43 MIC733AO2406-T MIC733AO2506-T MIC733AO2606-T MIC733AO2706-T MIC-733-AO5B1 MIC733AO2307-T MIC733AO2407-T MIC733AO2507-T MIC733AO2607-T MIC733AO2707-T MIC-733-AO6B1 MIC733AO2308-T MIC733AO2408-T MIC733AO2508-T MIC733AO2608-T MIC733AO2708-T MIC-733-AO5B2 MIC733AO2309-T MIC733AO2409-T MIC733AO2509-T MIC733AO2609-T MIC733AO2709-T MIC-733-AO6B2 MIC733AO2310-T MIC733AO2410-T MIC733AO2510-T MIC733AO2610-T MIC733AO2710-T MIC-733-AO5B3 MIC-733-AO6B3 MIC-733-AO5C1 MIC-733-AO6C1 MIC-733-AO5C2 MIC-733-AO6C2 MIC-733-AO5C3 MIC-733-AO6C3 MIC733AO MIC-733 User Manual/用户手册...
  • Page 44 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024 www.advantech.com.cn 使用前请检查核实产品的规格。本手册仅作为参考。 产品规格如有变更,恕不另行通知。 未经研华公司书面许可,本手册中的所有内容不得通过任何途经以任何形式复制、翻...
