Figure 4-5. Processor Bottom-Side Marking Placement on Interposer
NOTE: 2D Matrix Mark only present on Itanium 2 processor (6 MB), Itanium 2 processor (4 MB) and Itanium 2
processor (1.3 GHz, 3 MB).
Datasheet
AH25
AH1
Mechanical Specifications
Laser Mark including
2D Matrix Mark
A25
A1
Pin 1
Indicator
001267b
