Intel Skylake-U / Kaby Lake-U Core i CPU,
DDR4 2133 MT/s SODIMM, 2 x LAN / HDMI /
2 x Intel GbE LAN, 2 x PCIe mini card slots, HDMI, VGA
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 2I610HW
Release date: July. 02. 2021
2I610HW
USB / COM / PCIe mini card
Intel Skylake-U / Kaby Lake-U Core i CPU,
7 x USB, 2 x COM, Wide Range DC-IN
All wafer IO
,

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2I610HW and is the answer not in the manual?

Questions and answers

Related Manuals for Intel 2I610HW

Summary of Contents for Intel 2I610HW

  • Page 1 USB / COM / PCIe mini card All wafer IO Intel Skylake-U / Kaby Lake-U Core i CPU, 2 x Intel GbE LAN, 2 x PCIe mini card slots, HDMI, VGA 7 x USB, 2 x COM, Wide Range DC-IN CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
  • Page 2 1-3-1 REMOVING THE SO-DIMM ..................1-4 INSTALLING THE MINI PCI-E CARD (FULL SIZE) ............. CHAPTER 2 HARDWARE INSTALLATION ..............2-1 DIMENSION-2I610HW ....................2-2 LAYOUT-2I610HW-CONNECTOR AND JUMPER ............2-3 DIAGRAM-2I610HW TOP .................... 2-3-1 DIAGRAM-2I610HW BOT ..................2-3-2 FUNCTION MAP-2I610HW ..................2-4 LIST OF JUMPERS ......................
  • Page 3 3-14 CT1: TOUCH SCREEN (2X5 PIN 2.0MM WAFER) COM INTERFACE ..... 3-15 LVDS1: LVDS INTERFACE (2X15 PIN 1.25MM WAFER) .......... 3-16 HDMI1: HDMI INTERFACE (2X10 PIN 1.25MM WAFER) ......... 3-17 SATA INTERFACE ..................... 3-18 PCI EXPRESS MINI CARD ..................3-19 CONNEXTOR WAFER OF COMPATIBLE BRAND AND PART NUMBER LIST ..CHAPTER 4 INTRODUCTION OF BIOS ................
  • Page 4 Trademarks Intel is a registered trademark of Intel Corporation. Award is a registered trademark of Award Software, Inc. All other trademarks, products and or product's name mentioned here are for identifi...
  • Page 5 Warning ! Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.
  • Page 6 Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 7 Photo 1 Insert Unplug...
  • Page 8 Chapter-1 General Information The 2I610HW is a 2.5" (102 x 88 mm) motherboard powered with Intel® Skylake-U processor & off ered the ideal platform for high performance applications. 2I610HW's all wafer IO design delivers high fl exibility toward expanded functions and also provides user hassle-free solution of integrating the SBC board within various mechanical enclosures.
  • Page 9 Processor 2.3GHz / 2.8GHz (Dual core), Intel® Core i7-6600U Processor 2.6GHz / 3.4GHz (Dual core) Intel 9th generation (Gen 9) LP graphics and media encode / decode engine, Intel® Celeron 3955U 300MHz / 900MHz, Intel® Core i5-6200U 300MHz / 1GHz, Intel®...
  • Page 10 6.0 Gb/s (600 MB/s). LAN: 2 Intel I210-AT LAN chipset with 10 / 100 / 1000 Mbps for PCIe x 1 V2.1 l/O Chip: F81804U I/O chipset for 2 ports RS232 / RS422 / RS485 auto switch by BIOS USB: 2 type A USB 3.0, 4 USB 2.0...
  • Page 11 1-3 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.
  • Page 12 Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden fi nger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card fi...
  • Page 13 1-3-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.
  • Page 14 1-4 Installing the Mini PCI-e Card (Full Size) 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.
  • Page 15 Chapter-2 2-1 Dimension-2I610HW...
  • Page 16 2-2 Layout-2I610HW-Connector and Jumper JSB1 CL11 CL21 JAT1 JVC1 CBT1 JVC2 CPP1 CL22 CU31 CPO1 (OEM) CU34 CU24 CU33 CU23 MPCE1 JVL2 CU28 CU29 CU210 HDMI1 MPCE2 CIO1 CPI1 COH1 CFP1...
  • Page 17 2-3 Diagram- 2I610HW JSB1 CL11 CL21 JVC1 CBT1 JAT1 JVC2 CPP1 CL22 CU31 CPO1 (OEM) CU34 CU24 DDR4 SODIMM CU33 CU23 MPCE1 JVL2 CU28 CU29 CU210 HDMI1 MPCE2 CIO1 CFP1 CPI1 COH1...
  • Page 18 2-3-1 Diagram- 2I610HW SATA1...
  • Page 19 2-3-2 Function MAP- 2I610HW CMOS Jumper Power in always ON COM1 RI/+5V/+12V Jumper LAN2 Battery COM2 RI/+5V/ LAN1 LAN1 +12V Jumper Pannel Backlight power COM2 COM1 +5V/+12V OUT Touch USB3.0 MPCE1 Panel PCIe/mSATA/USB Power Jumper USB2.0 MPCE2 PCIe/USB2.0 4DI/DO Heater...
  • Page 20 2-4 List of Jumpers JSB1: CMOS DATA Clear JVL2: LVDS panel power select JVC1 / 2: COM1 / 2 PIN9 RI / +12V / +5V Select JAT1: Power in always ON function 2-5 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.
  • Page 21 2-6 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin 1 and Pin 2 of JSB1 to store the CMOS data. To clear the CMOS data, please follow the steps as below: 1.
  • Page 22 2-7 JVL2: LVDS panel power select JVL2 DESCRIPTION *2-3 +3.3V Note: Attention! Check Panel Power in spec JVL2 1 2 3 1 2 3 *+3.3V 2-8 JVC1/2: COM1/2 PIN9 RI/+12V/+5V Select JVC1/2 DESCRIPTION *1-2 COM port pin9 use RI signal COM port pin9 use +5V voltage COM port pin9 use +12V voltage JVC1...
  • Page 23 2-9 JAT1: Power in always ON function JAT1 DESCRIPTION *1-2 Disabled Enabled NOTE: Power always on function default is disabled. JAT1 1 2 3 1 2 3 *Disabled Enabled...
  • Page 24 Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CBT1: COMS battery 1x2 pin (1.25mm)wafer CC1 : COM1 2x5 pin (2.0mm) wafer CC2 : COM2 2x5 pin (2.0mm) wafer CFP1:...
  • Page 25 HDMI1: HDMI1 2x10 pin (1.25mm) connector SATA1: SATA connector 7 pin SODIMM1: DDR4 Channel 0 SODIMM H: 5.2mm MPCE1 : Full size mini card port 1 sockets 52 pin MPCE2 : Full size mini card port 2 sockets 52 pin 3-2 CMOS battery connector CBT1: CMOS Battery 1x2pin (1.25mm) Wafer PIN NO.
  • Page 26 3-3 COM interface CC1/2: COM1/2 2x5pin (2.0mm) wafer RS232 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS485 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data- Data+ RS422 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Note: 1. Pin 9 RI and Voltage setting only for COM 1/2 ports, JVC1 for COM1, JVC2 for COM2 2.
  • Page 27 3-4 Front Panel Pin Header CFP1: Front Panel connector 2x5pin (2.0mm) wafer PIN NO. Description PIN NO. Description Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1 3-5 VGA Display interface...
  • Page 28 3-6 Digital Input/Output/Watch Dog Time CIO1: DIO 0-3 2x5pin (2.0mm) wafer PIN NO. Description PIN NO. Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Note: 1. DI pin default pull up 10KΩ to +5V 2. If use need isolate circuit to control external device 3.
  • Page 29 3-6-1 IO Device: F75111 under DOS The Sample code source you can download from http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS Source fi le: F75111_Dos_Src.rar Binary fi le: F75111_Dos_Bin.rar USERNAME & PASSWORD: sf How to use this Demo Application 1.Boot Ms-Dos Operating System 2.execute "75WDT.EXE" binary fi le 3.Input 1 to Enable WDT timer or input 0 to Disable it.
  • Page 30 Introduction How to use this Demo Application WriteI2CByte(I2CADDR, CONFIG, 0x03);//Set Watch Dog Timer function WriteI2CByte(I2CADDR, WDT_TIMER, timer);//Set Watch Dog Timer range from 0-255. WriteI2CByte(I2CADDR, WDT_TIMER_CTL, 0x73);//Enable Watch Dog Timer in second and pulse mode How to use this Demo Application WriteI2CByte(I2CADDR, WDT_TIMER_CTL, 0x00);...
  • Page 31 3-6-2 IO Device: F75111 under Windows The Sample code source you can download from Source fi le: F75111_DIO_Src_v2.8W(32bit).zip http://tprd.info/lexwiki/index.php/IO_Device:F75111 Binary fi le: F75111_DIO_Bin_v2.8W(32bit).zip USERNAME & PASSWORD: sf We do the demo test with a test tool which DIx connect to DOx with Relay.
  • Page 32 How to use this Demo Application one F75111 two F75111 Attention Please: You must be install vcredist_x86.exe when fi rst time you run the F75111_DIO.exe DEMO AP,The vcredist_x86.exe include all required DLL fi le. WARNING: win7 system architecture, use the system administrator to open DIO utility 1.
  • Page 33 p.s. f75111 send "F75111_SetWDTEnable(BYTE byteTimer)" including a parameter "timer", if there's no disable signal (F75111_SetWDTDisable()) to stop it before timer countdown to 0, System will reboot. if there's disable signal received, resent Enable WDT signal, for a loop to prevent from reboot F75111 Layout Picture Introduction Initial Internal F75111 port address (0x9c)
  • Page 34 Enable/Disable WDT Enable : F75111_SetWDTEnable (BYTE byteTimer) Disable: F75111_SetWDTDisable () PULSE mode Sample to setting GP33, 32, 31, 30 output 1mS low pulse signal. this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_PULSE_CONTROL, 0x00); //This is setting low pulse output this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_PULSE_WIDTH_CONTROL, 0x01); //This selects the pulse width to 1mS this->Write_Byte(F75111_INTERNAL_ADDR, GPIO3X_CONTROL_MODE, 0x0F);...
  • Page 35 Get Input value BYTE F75111::InterDigitalInput() BYTE byteGPIO1X = 0; BYTE byteGPIO3X = 0; BYTE byteData = 0; this->Read_Byte(F75111_INTERNAL_ADDR,GPIO1X_INPUT_DATA,&byteGPIO1X) ; // Get value from GPIO1X this->Read_Byte(F75111_INTERNAL_ADDR,GPIO3X_INPUT_DATA,&byteGPIO3X) ; // Get value from GPIO3X byteGPIO1X = byteGPIO1X & 0xF0; // Mask unuseful value byteGPIO3X = byteGPIO3X &...
  • Page 36 //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_INPUT_DATA 0x12 // GPIO1X Input #defi ne GPIO3X_INPUT_DATA 0x42 // GPIO3X Input //-------------------------------------------------------------------------------------------------------- #defi ne GPIO2X_OUTPUT_DATA 0x21 // GPIO2X Output //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_PULSE_CONTROL 0x13 // GPIO1x Level/Pulse Control Register // 0:Level Mode // 1:Pulse Mode #defi ne GPIO1X_PULSE_WIDTH_CONTROL 0x14 // GPIO1x Pulse Width Control Register #defi...
  • Page 37 3-6-3 IO Device: F75111 VB6 under Windows The Sample code source you can download from Source fi le: 75111_VB_v1.2.rar http://tprd.info/lexwiki/index.php/IO_Device:F75111_VB6 Binary fi le: 75111_VB_Src1.2.rar USERNAME & PASSWORD: sf How to use this Demo Application ● A Function - Choose your motherboard model ●...
  • Page 38 F75111 Layout Picture SDK Function Introduction Function EnableWDT Function EnableWDT(timer As Integer) Call WriteI2CByte(&H3, &H3) Call WriteI2CByte(&H37, timer) Call WriteI2CByte(&H36, &H73) End Function Function DisableWDT Function DisableWDT() Call WriteI2CByte(&H36, &H0) End Function...
  • Page 39 Function SetDOValue Function SetDOValue(dovalue As Integer) Dim Data As Integer Dim Value As Integer Data = 0 Value = dovalue If (Value And &H1) <> 0 Then Data = Data + &H1 End If If (Value And &H2) <> 0 Then Data = Data + &H2 End If If (Value And &H4) <>...
  • Page 40 Function CheckDIValue Function CheckDIValue() Dim GPIO1X As Integer Dim GPIO3X As Integer Dim DI1Xhex As String Dim DI3Xhex As String Dim Data As Long Data = 0 Call ReadI2CByte(&H12, GPIO1X) Call ReadI2CByte(&H42, GPIO3X) GPIO1X = GPIO1X And &HF0 GPIO3X = GPIO3X And &HF If (GPIO1X And &H10) <>...
  • Page 41 3-6-4 IO Device: F75111 under linux The Sample code source you can download from Source fi le: F75111v2.4L_SRC.tar.gz http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_linux Binary fi le: F75111v2.4L_BIN.tar.gz USERNAME & PASSWORD: sf How to compile source code 1. Compile source code with Code::Blocks download and install the Code::Block with command "apt-get install codeblocks" Open an exist project(F75111.cbp) in Code::Blocks, click the compile button ( add an option 'pkg-config --libs gtk+-2.0 gthread-2.0' in "Project->Build Option- >Linker Setting->Other linker option")
  • Page 42 1. Press the "Start" button to test DIO function 2. Press the "Enable" button to test WDT function 3. Press the "Disable" button to disable WDT 4. Check the "Enable Loop" box and press "Enable" to do WDT loop test 5.
  • Page 43 Introduction IO function In fi le SMBus.c void SMBusIoWrite(BYTE byteOff set,BYTE byteData) outb( byteData , m_SMBusMapIoAddr + byteOff set); BYTE SMBusIoRead(BYTE byteOff set) DWORD dwAddrVal; dwAddrVal = inb(m_SMBusMapIoAddr + byteOff set); return (BYTE)(dwAddrVal & 0x0FF); Initial internal F75111 void F75111::InitInternalF75111() this->Write_Byte(F75111_INTERNAL_ADDR,GPIO1X_CONTROL_MODE ,0x00);...
  • Page 44 Get Input value BYTE F75111::InterDigitalInput() BYTE byteGPIO1X = 0; BYTE byteGPIO3X = 0; BYTE byteData = 0; this->Read_Byte(F75111_INTERNAL_ADDR,GPIO1X_INPUT_DATA,&byteGPIO1X) ; // Get value from GPIO1X this->Read_Byte(F75111_INTERNAL_ADDR,GPIO3X_INPUT_DATA,&byteGPIO3X) ; // Get value from GPIO3X byteGPIO1X = byteGPIO1X & 0xF0; // Mask unuseful value byteGPIO3X = byteGPIO3X &...
  • Page 45 //-------------------------------------------------------------------------------------------------------- #defi ne F75111_INTERNAL_ADDR 0x9C OnBoard F75111 Chipset #defi ne F75111_EXTERNAL_ADDR 0x6E External F75111 Chipset //-------------------------------------------------------------------------------------------------------- #defi ne F75111_CONFIGURATION 0x03 Confi gure GPIO13 to WDT2 Function //-------------------------------------------------------------------------------------------------------- #defi ne GPIO1X_CONTROL_MODE 0x10 Select Output Mode or Input Mode #defi ne GPIO2X_CONTROL_MODE 0x20 Select GPIO2X Output Mode or Input Mode #defi...
  • Page 46 3-7 USB Interface CU31: Micro USB3.0 Port 1 (option) PIN NO. USB3.0 VBUS DATA- DATA+ USB2.0 VBUS U3_TX- U3_TX+ U3_RX- U3_RX+ CU33/34: USB3.0 Port 3/4 1x5pin 1.25mm wafer CU31 PIN NO. DESCRIPTION USB3_TX_P USB3_TX_N USB3_RX_P USB3_RX_N CU34 pin1 CU33 pin1 CU22/23/24/28/29/210 USB2.0 port 2,3,4,8,9,10 (1x4pin 1.25mm Wafer) CU29...
  • Page 47 3-8 LAN Interface CL1/2: LAN1/2 (2x5pin 2.0mm wafer) PIN NO. Description PIN NO. Description MDI0- MDI0+ MDI2+ MDI1+ MDI1- MDI2- MDI3- MDI3+ pin1 pin1 CL11/21: LAN1/2 LED indicator (1x4pin 1.25mm wafer) PIN NO. Description Speed 10M Speed 100M Speed 1000M CL11 CL21 pin1...
  • Page 48 3-9 SMBus Interface CO1: SMBus 4pin (1.25mm) Wafer PIN NO. Description +3.3V SMBus Clock SMBus DATA pin1 3-10 COH1: +12V Heater (1x2pin 2.0mm Wafer) PIN NO. Description +12V Note: Then +12V will powered when adapter plug-in. COH1 pin1...
  • Page 49 3-11 DC Power Input CPI1: DC Power input (2x4pin 2.0mm Wafer) (Red) PIN NO. Description 3,4,5,6 DC-IN 1,2,7,8 Note: Very important check DC-in Voltage CPI1 pin1 3-12 DC +12V/+5 Voltage Power Output CPO1: +12V/+5V DC voltage output wafer connector (Black) (1x4pin 2.0mm) PIN NO.
  • Page 50 3-13 Panel Inverter Power Interface CPP1: Panel backlight power (1x5 pin 2.0mm wafer) PIN NO. Description +12V PWM dimming ENBKL (3.3V) ENBKL (5V) Note: 1. CPP1 PIN 3 and LVDS1 PIN1 is same signal. CPP1 pin1...
  • Page 51 3-14 CT1 : Touch screen (2x5 pin 2.0mm wafer) COM interface CT1: For 8-wire type pin defi ne PIN NO. DESCRIPTION PIN NO. DESCRIPTION Bottom Bottom Sense Top Sense Right Right Sense Left Left Sense Note: For eight wire type cable Pin 3 and Pin4 need short CT1: For 4-wire type pin defi...
  • Page 52 3-15 LVDS1 : LVDS interface (2x15 pin 1.25mm wafer) PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWM dimming +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA3+ Channel-0-DATA3+ Channel-1-DATA3- Channel-0-DATA3- Channel-0-DATA2+ Channel-0-CLK+ Channel-0-DATA2- Channel-0-CLK- Channel-0-DATA1+ Channel-0-DATA0+ Channel-0-DATA1- Channel-0-DATA0- +LCD(5V or 3.3V) +LCD(5V or 3.3V) Channel-1-DATA2+ Channel-1-CLK+ Channel-1-DATA2-...
  • Page 53 LVDS Panel resolution table list Item Resolution Channel bits 640 x 480 800 x 600 1024 x 768 800 x 480 1024 x 600 1280 x 800 1366 x 768 800 x 600 1024 x 768 1280 x 800 1366 x 768 1280 x 1024 1440 x 900 1600 x 1200...
  • Page 54 3-16 HDMI1: HDMI interface (2x10 pin 1.25mm wafer) PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS_D2_N TMDS_D2_P TMDS_D1_N TMDS_D1_P TMDS_D0_N TMDS_D0_P TMDS_CLK_N TMDS_CLK_P CLOCK DATA Hot Plug Detect pin1 HDMI1...
  • Page 55 3-17 SATA Interface SATA1: SATA Port 1x7pin connector PIN NO. Description Note: 1. CPO1 provide SATA HDD power +12V, GND, +5V. SATA1...
  • Page 56 3-18 PCI Express Mini card MPCE1/2 PCI Express Mini card PIN NO. Description PIN NO. Description +3.3V +1.5V PCIe-CLK- PCIe-CLK+ Reset MPCE1 PCIe-RX-/mSATA-RX+ +3.3V pin52 PCIe-RX+/mSATA-RX- +1.5V SMB-CLK PCIe-TX-/mSATA-TX- SMB-DATA PCIe-TX+/mSATA-TX+ USB-DATA- USB-DATA+ +3.3V pin1 +3.3V MPCE2 pin52 +1.5V mSATA/PCIe detect +3.3V Note: 1.
  • Page 57 3-19 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS CFP1 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10Pin 2.00mm B10B-PHDSS PHDR-10VS CIO1 2x5 10Pin 2.00mm...
  • Page 58 Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.
  • Page 59 4-2 BIOS Menu Screen & Function Keys There are six menu bars on top of BIOS screen: Main To change system basic confi guration Advanced To change system advanced confi guration Security Password settings Power ACPI and wake device settings Boot To change system boot confi...
  • Page 60 4-3 Getting Help Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>. In the above BIOS Setup main menu of, you can see several options.
  • Page 61 4-4 Main Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the Date. Please use [Tab] to switch between data elements. System Time Set the Time.
  • Page 62 4-5 Advanced Boot Confi guration Please refer section 4-5-1 Graphics Confi guration Please refer section 4-5-2 PCH-IO Confi guration Please refer section 4-5-3 PCH-FW Confi guration Please refer section 4-5-4 SIO FINTEK81804 Please refer section 4-5-5...
  • Page 63 4-5-1 Boot Confi guration Numlock Select Power-on state for Numlock, default is <Off >...
  • Page 64 4-5-2 Graphics Confi guration GTT Size Graphics Translation Table Size. The optional settings are: 2MB, 4MB, 8MB(default) Aperture Size The optional settings are: 128MB, 256MB, 512MB, 1024MB(default), 2048MB DVMT Pre-Allocated Use this item to select DVMT 5.0 pre-allocated (fi xed) graphics memory size used by the internal graphics device.
  • Page 65 4-5-2-1 ► Display Confi guration LFP 1 Confi gure to LVDS Panel, default is Disabled The Panel resolution supported are below: 640 x 480 18bit 800 x 600 18bit 1024 x 768 18bit (default) 800 x 480 18bit 1024 x 600 18bit 1280 x 800 18bit 1366 x 768 18bit 800 x 600 24bit...
  • Page 66 1920 x 1080 48bit Boot Display To select the displays priority to LVDS, HDMI or VGA 4-5-3 PCH-IO Confi guration PCI Express Confi guration Please refer section 4-5-3-1 SATA And RST Confi guration Please refer section 4-5-3-2...
  • Page 67 4-5-3-1 ► PCI Express Confi guration PCI Express Root Port 03 for MPCE1 Please refer section 4-5-3-1-1 PCI Express Root Port 04 for MPCE2 Please refer section 4-5-3-1-2...
  • Page 68 4-5-3-1-1 ► PCI Express Root Port 03 for MPCE1 PCI Express Root Port 03 for MPCE1 The optional settings are: Enabled(default), Disabled. Select PCI Express port speed. The optional settings are: Auto, Gen1(default), Gen2, Gen3...
  • Page 69 4-5-3-1-2 ► PCI Express Root Port 04 for MPCE2 PCI Express Root Port 04 for MPCE2 The optional settings are: Enabled(default), Disabled. Select PCI Express port speed. The optional settings are: Auto, Gen1(default), Gen2, Gen3...
  • Page 70 4-5-3-2 ► SATA And RST Confi guration SATA Controller Use this item to Enable or Disable SATA Device. The optional settings are: Enabled(default) or Disabled SATA Mode Selection Support AHCI Mode only.
  • Page 71 4-5-4 PCH-FW Confi guration ME State The optional settings are: Enabled (default) or Disabled Manageability Features State The optional settings are: Enabled or Disabled (default)
  • Page 72 4-5-5 SIO FINTEK81804 Serial Port 1/2 Use this item to enable or disable serial port. The optional settings are: Enabled(default), Disabled. Serial Port A Base IO Address / Interrupt / Serial Mode Use this item to select an optimal setting for super IO device. The optional settings are: IO=3F8h;...
  • Page 73 IO=2E8h; IRQ=3,4 IO=3E8h; IRQ=3,4 IO=3F8h; IRQ=3,4 Mode RS232(default)/RS485/RS422 Power Loss setting This item specifi es whether your system will reboot after a power failure or interrupt occurs. [Last state] Restores the system to the status before power failure or interrupt occurred. [Always on] Leaves the computer in the power on state.
  • Page 74 4-6 Security Supervisor Password To set up an Supervisor password 1. Select Supervisor Password. The screen then pops up an Create New Password dialog. 2. Enter your desired password that is no less than 3 characters and no more than 10 characters. 3.
  • Page 75 4-7 Power Wake On USB Wake on USB from Mouse or Keyboard interrupt signal when system in S3 state The optional settings: S3(default), Disabled Wake On LAN Wake on LAN from LAN1 when system in S3 S5, or both of them state The optional settings: S3(default), S5, S3/S5, Disabled Wake On RTC To select an alarm event to wake on a specifi...
  • Page 76 4-8 Boot Boot type Select boot type for Dual type ,Legacy boot type or UEFI boot type, default is UEFI boot type Quiet Boot The optional settings are: Enabled(default), Disabled. Network Stack Enabled for PXE function, default is disabled. Determine which EFI storage device for booting, this item will not show on this page if there is no any storage device found.
  • Page 77 4-9 EXIT Exit Saving Changes This item allows user to reset the system after saving the changes. Save Change Without Exit This item allows user to saving the changes but doesn’t restart. Exit Discard Changes This item allows user restart the system but no saving the changes Load Optimal Default Use this item to restore the optimal default for all the setup options.
  • Page 78 STEP 3. Copy the latest BIOS for your LEX motherboard from our website to your bootable disc. STEP 4. (Here take 2I610HW as an example, please enter your motherboard’s name) Insert your bootable disc into X: (X could be C:, A: or others.
  • Page 79 Appendix A: Power Consumption Test Condition ( 2I610HW ) Item Spec Celeron 3955U 2.00GHz / i5-6200U 2.30GHz / i7-6600U 2.60GHz Memory DDR4 2133 16GB Operating System Windows 10 Enterprise 64bit Test Program 3D Mark 06 HDD 2.5" SATA 500GB mSATA...
  • Page 80 Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
