The "Optional" input board MUST be used to perform this
function (Part# Q203).
Relay Contact Rating
0.5 Amp - 125 VAC
1 Amp - 24 VDC
S O L E N O I D / M A G L O C K C O N N E C T I O N
14
13
16
16-Pin Plug
To ENSURE proper operation of external devices:
• ENSURE bare wires make good contact inside removable
terminal connections.
• DO NOT let wire insulation interfere with connection.
Part #
Dry Contact Relay
Power
N.C.
for
Maglock
Common
16
CAUTION
A MG 1300
