REPLACEMENT PARTS

MODEL RSW12V™ & RSW12VH™
INDIVIDUAL PARTS
ITEM PART NUMBER
1 K1A6426-2
2 K1C3196-7
3 K13-34729
4 K204B195-1
5 K20-9012B-1
6 K32-34656-1
7 K32-35618
8 K73-34637
9 K75-34709-1
10 K76-34743
11 K76-35228-1
12 K94-35225
13 K29-50279-1
14 Q029
15 K1A6636
16 Q181
17 K1A6407-1
NOT SHOWN
K1A6636-1
K75-35343-1
K75-35400-1
K2
DESCRIPTION
Control Board
Antenna
Dust Guard
Transformer, 14.5 Vac, 30 VA
Motor, 12 Vdc
Gear Reducer Top, 30:1
Gear Reducer Bottom, 30:1
Chassis
Control Enclosure with Mounting Hardware
Access Panel, 120 Vac with Receptacles
Reset Switch
Battery Harness Assembly
Alarm
Learn Limit Switch
Receiver Module 315 MHz
Coupling 2-1/2"
RPM Sensor
Receiver Module 390 MHz (optional)
Access Door with Lock and Key
Operator Cover Assembly with Access Door
K1
6
7
16
5
8
10
NOT SHOWN (continued)
Q084
Q118
Q104
Q061
Q059
K45-50676
Q268
Q062
Q103
29-NP712
K94-35225
A12330SGLPK
ITEM PART NUMBER
K1 K70-35677
K2 K70-35678-1
K3 K76-35321
K4 K94-35658
12
K4
K3
14
9
11
4
Cam Lock with Keys
Access Door Keys
Operator Arm Assembly
Cludge Assembly
Output Arm (Solid)
Star Knob
Cludge Cover (Plastic)
Cludge Cover (Stainless Steel)
Uphill Arm Kit
7AH Battery, 12 Vdc
7AH Battery Harness
33AH Battery with Harness
KITS
DESCRIPTION
Limit Shaft Kit
Complete with: Limit Shaft, Sprocket,
Chain, Cam
Sprocket Kit
Complete with: Chain, Sprockets
Learn Limit Assembly Kit
Complete with: Learn Limit Switch, Learn
Limit Nut, Limit Shaft Assembly, Sprockets,
RPM Sensor, Set Screw, Wire Harness
Wiring Harness Kit
Complete with: Wiring, Limit/Battery/RPM
17
13
2
1
15
3
