USER'S GUIDE
V E H I C U L A R S L I D E / S W I N G G A T E O P E R A T O R S
RSL12V ™ & RSL12VH ™
RSW12V ™ & RSW12VH ™
Your model may look different than the model illustrated in this user's guide.
Please contact your authorized LiftMaster dealer
for all of your service needs.
Installation Date
www.liftmaster.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chamberlain Elite RSL12V
Summary of Contents for Chamberlain Elite RSL12V
- Page 1 V E H I C U L A R S L I D E / S W I N G G A T E O P E R A T O R S RSL12V ™ & RSL12VH ™ RSW12V ™ & RSW12VH ™...
- Page 2 The reset switch/button is located on the front of the operator and serves several functions. MODEL RSL12V SLIDE GATE OPERATOR Model RSL12V has a reset switch. When referring to “toggling” the reset switch it means pressing the reset switch to the RESET/DISCONNECT position, then back to the NORMAL OPERATION position.
-
Page 3: Operator Alarm
OPERATION OPERATOR ALARM If a contact sensor detects an obstruction twice consecutively the alarm will sound (up to 5 minutes) and the operator will need to be reset. When the inherent force of the operator (RPM/current sensor) detects the following (twice consecutively) the alarm will sound (up to 5 minutes) and the operator will need to be reset: The gate is hitting a wall or... - Page 4 Replace BATTERY The battery should be replaced every three years. Use only LiftMaster part 29-NP712 for replacement batteries. The operator comes with one 7AH battery. A second 7AH (29-NP712) battery may be added or one 33AH (A12330SGLPK) may be used in place of the 7AH batteries. The batteries contain lead and need to be disposed of properly.
-
Page 5: Entrapment Protection Devices
Passport™ remote controls to satisfy your application needs. Single-button to 4-button, visor or key chain. Additionally, Passport™ remote controls are ideal for integration with Telephone Entry and Access Control Systems. Contact your authorized LiftMaster dealer for details. ® 3-BUTTON SECURITY✚... - Page 6 ACCESSORIES MISCELLANEOUS DUAL GATE WIRING KIT The dual gate wiring kit is 40 feet of interconnecting cable required for dual gate applications. Model MSWIRE12GA6C MOUNTING STAND For Model RSL Slide. Ideal to raise slide operator higher above the ground for snow and other applications.
- Page 7 ACCESSORIES VEHICLE SENSING PROBE The vehicle sensing probe is buried in the ground and can detect a car as it approaches and will then open the gate. Model LM202 SOLAR PANEL KIT - 10 WATT This kit is to replace or add a solar panel to the operator application. Up to three solar panels can be connected to the operator.
- Page 8 845 Larch Avenue Elmhurst, Illinois 60126-1196 01-35314C © 2010, The Chamberlain Group, Inc. – All Rights Reserved...
