Dc Power Connection - Chamberlain THE ROBO SLIDE Instruction Manual

Do not use solar panel and plug-in transformer at the same time.
Use Chamberlain Elite's optional 25 VDC plug-in transformer
(APOW1). Hook up the transformer to 120 VAC. Use two,
low voltage, 14 gauge / 300watt direct burial, landscape lighting
cables. Hook these wires to the plug-in transformer and to the
power input connection on the surge suppressor. Polarity does
not matter.
Earth Ground Rod Highly Recommended!
Use 14 gauge / 300 watt direct burial, landscape lighting
When the plug-in transformer has been connected to the power source, connect the battery cable plug to the motor harness plug. You
will hear 3 beeps. After the beeps, check the
D C P O W E R C O N N E C T I O N
VOLTAGE VOLTAGE
25 VDC
To 120 VAC
Plug-in
Transformer
Polarity Does Not Matter
wire NOT to exceed 1000 ft. for transformer .
"Charge OK" LED...it must be "ON".
Motor Harness
Beep!
Beep!
Beep!
To AVOID damaging 25 Vdc plug-in transformer, it MUST be
enclosed in a suitable weatherproof enclosure and provided
with proper weatherproof fixtures.
To AVOID damaging control board, DO NOT use the solar panel
and the plug-in transformer at the same time.
®
®
DC DC ACCESS SYSTEMS INC ACCESS SYSTEMS INC ACCESS SYSTEMS INC
–
LOW LOW
ONLY! ONLY!
POWER INPUT
25 VDC
DC
POWER INPUT
25 VDC
Alarm Sensor
during power connection. This
means the board is OK.
12
CAUTION
®
® ROBO SURGE SUPPRESSOR
DC ACCESS SYSTEMS INC ACCESS SYSTEMS INC ACCESS SYSTEMS INC
1 – – 4 5 6 7 8 9
–
SAFETY SAFETY EXIT EXIT FIRE DEPT FIRE DEPT STRIKE OPEN STRIKE OPEN
LOOP LOOP LOOP LOOP KEY SWITCH KEY SWITCH PUSH BUTTON PUSH BUTTON
LED will flash
3 times
P/N Q412 P/N Q412
PATENT PENDING P A T ENT PENDING
10 11 12 13
– – + +
CLASS 2
SUPPLY
RADIO RADIO
RECEIVER RECEIVER
