QMS Print System 1725E Getting Started Manual page 48

1 Press the printer control panel Online/Offline key.
The indicator goes out and the message window displays
2 Press the Menu key to enter the top-level menu.
3 Press the Next key one or more times until the message win-
dow displays
4 Press the Select key to enter the Administration menu.
5 Press the Next key one or more times until the message win-
dow displays
6 Press the Select key to enter the Communications menu.
7 Press the Next key one or more times until the message win-
dow displays
8 Press the Select key to enter the Serial menu.
9 Press the Next key one or more times until the message win-
dow displays
10 Press the Select key to enter the Baud Rate menu.
The message window displays the currently selected baud rate:
11 Press the Next key to cycle through the list of baud rates.
IDLE
OPERATOR CONTROL
ADMINISTRATION
ADMINISTRATION
COMMUNICATIONS
COMMUNICATIONS
SERIAL
SERIAL
BAUD RATE
*9600 BAUD
