QMS Print System 1725E Getting Started Manual page 27

n
Enough space to allow you to open the top cover, access the rear
delivery tray, and slide out the paper cassettes.
21.7'' (550 mm)
21.7'' (550 mm)
Your printer requires a properly grounded AC outlet with a power
range of ±10% of the rated voltage (100, 110/120, or 220/240 V).
Noise-generating equipment should not be connected to the same
electrical outlet as the printer. The recommended frequency is 50 Hz
±2 Hz for 100 and 220/240 V systems and 60 Hz ±2 Hz for 110/120 V
systems.
O
39.4'' (1000 mm)
15.7'' (400 mm)
7.9'' (200 mm)
58.3'' (1480 mm)
