PC-CARD-DAS16/16AO User's Guide

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions

Connector and pin out

Connector type
Compatible cables
Compatible accessory products
Pin Signal Name
1 AGND
2 CH0 HI
3 CH0 LO
4 CH1 HI
5 CH1 LO
6 CH2 HI
7 CH2 LO
8 CH3 HI
9 CH3 LO
10 CH4 HI
11 CH4 LO
12 CH5 HI
13 CH5 LO
14 CH6 HI
15 CH6 LO
16 CH7 HI
17 CH7 LO
18 AGND
19 N/C
20 N/C
21 N/C
22 N/C
23 N/C
24 N/C
25 N/C
Table 14. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 95% non-condensing
Table 15. Mechanical specifications
PCMCIA type II: 85.6 mm (L) x 54.0 mm (W) x 5.0 mm (H)
Table 16. Connector specifications
50-pin connector
CPCC-50F-39: 50-pin Micro connector to 50-pin female IDC, one-meter cable
(39 inches).
CPCC-50M-4: 50-pin Micro connector to 50-pin male IDC, 4 inch adapter cable.
and
C50FF-x: 50-pin IDC female to female cable. x = length in feet.
CIO-MINI50
SCB-50
Table 17. 8-channel Differential mode pin out
Pin Signal Name
26 DGND
27 DIO0
28 DIO1
29 DIO2
30 DIO3
31 NC
32 NC
33 NC
34 NC
35 DA GND0
36 DA OUT0
37 DA GND1
38 DA OUT1
39 CTR1 CLK
40 CTR1 GATE
41 CTR1 OUT
42 A/D EXTERNAL PACER
43 EXTERNAL INTERRUPT
44 A/D PACER GATE
45 A/D EXTERNAL TRIGGER
46 N/C
47 A/D PACER OUT
48 VDD +5V POWER
49 N/C
50 DGND
24
Specifications
