PC-CARD-DAS16/16AO User's Guide
Pin Signal Name
1 AGND
2 CH0 IN
3 CH8 IN
4 CH1 IN
5 CH9 IN
6 CH2 IN
7 CH10 IN
8 CH3 IN
9 CH11IN
10 CH4 IN
11 CH12 IN
12 CH5 IN
13 CH13 IN
14 CH6 IN
15 CH14 IN
16 CH7 IN
17 CH15 IN
18 AGND
19 N/C
20 N/C
21 N/C
22 N/C
23 N/C
24 N/C
25 N/C
Table 18. 16-channel Single-ended mode pin out
Pin
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
25
Signal Name
DGND
DIO0
DIO1
DIO2
DIO3
NC
NC
NC
NC
DA GND0
DA OUT0
DA GND1
DA OUT1
CTR1 CLK
CTR1 GATE
CTR1 OUT
A/D EXTERNAL PACER
EXTERNAL INTERRUPT
A/D PACER GATE
A/D EXTERNAL TRIGGER
N/C
A/D PACER OUT
VDD +5V POWER
N/C
DGND
