!1 SQUELCH LEVEL INDICATOR
Shows the squelch level.
!2 VOLUME LEVEL INDICATOR
➥ Shows the volume level.
➥ The bars appear n ascendng order repeatedly whle
the volume loud functon s actvated. (p. 12)
➥ Blnks whle the volume mute functon s actvated. (p. 12)
!3 VOLUME LEVEL ADJUSTING INDICATOR (p. 11)
➥ Blnks whle adjustng the volume level.
➥ Ths ndcator and the volume level ndcator appear
alternately whle the volume level s turned up by the
nose detecton functon. (p. 20)
!4 SQUELCH LEVEL ADJUSTING INDICATOR (p. 12)
Blnks whle adjustng the squelch level.
!5 CHANNEL NUMBER READOUT
➥ Indcates the selected operatng channel number.
➥ In the set mode, ndcates the selected condton or
value. (p. 17)
!6 CHANNEL GROUP INDICATOR (p. 9)
" " appears when U.S.A. channel group*; "
when Internatonal channel group s selected.
* U.K. verson only.
!7 A TIS INDICATOR (p. 9)
"ATIS" appears when the channel group, whch ATIS func-
ton s actvated, s selected. (Avalable wth German and
Holland versons only.)
!8 LOW POWER INDICATOR (p. 10)
➥ "LOW" appears when low power s selected.
➥ "LOW" blnks when swtchng forced low power mode
because of a hgh temperature error or low voltage.
" appears
