10.2 FlashCopy establish phase performance

The FlashCopy of a volume has two distinct periods:
initial
The
physical
The
The FlashCopy establish phase, or
microcode is preparing things, such as the bitmaps, necessary to create the FlashCopy
relationship so the microcode can properly process subsequent reads and writes to the
related volumes. During this logical FlashCopy period, no writes are allowed to the volumes.
After the logical relationship has been established, normal I/O activity is allowed to both
source and target volumes according to the options selected.
When there are a large number of volumes, the method used to invoke the FlashCopy
commands can influence the time it takes to complete the logical FlashCopy for all FlashCopy
pairs. An in-band invocation will source the commands to the microcode faster than an
out-of-band method in most cases. An in-band establish is one that uses the CCW
commands directly, like in z/OS.
The fastest out-of-band method is the DS CLI. The method to control or invoke FlashCopy
should be selected based upon the total solution requirements and not strictly on
FlashCopy performance considerations, unless this is a critical performance issue.
Additionally, there is a modest performance impact to logical FlashCopy performance when
using incremental FlashCopy. In the case of incremental FlashCopy, the DS6000 must create
additional metadata (bitmaps). However, the impact is negligible in most cases.
Finally, the placement of the FlashCopy source and target volumes has an effect on the
establish performance. You can refer to the previous section for a discussion of this topic as
well as to Table 10-1 on page 113 for a summary of the recommendations.

10.3 Background copy performance

background copy
The
source volume to the target volume. If the FlashCopy relationship was established requesting
the NOCOPY option, then only write updates to the source volume will force a copy from the
source to the target. This forced copy is also called a
Note: The term
write to the source has occurred. This occurs on the
the DS6000 writes to non-volatile cache, there is typically no direct response time delay on
host writes. The forced copy only occurs when the write is destaged onto disk.
If the COPY option was selected, then upon completion of the logical FlashCopy establish
phase, the source will be copied to the target in an expedient manner.
If a large number of volumes have been established, then do not expect to see all pairs
actively copying data as soon as their logical FlashCopy relationship is completed. The
DS6000 microcode has algorithms that limit the number of active pairs copying data. These
algorithms will try to balance active copy pairs across the DS6000 device adapter resources.
Additionally, they will limit the number of active pairs such that there remains bandwidth for
host or server I/Os.
114
IBM System Storage DS6000 Series: Copy Services with IBM System z
logical FlashCopy (also called
FlashCopy (also called
logical
physical
phase, or
collision
describes a forced copy from the source to the target because a
establish
)
background
copy)
FlashCopy, is the period of time when the
FlashCopy, is the actual movement of data from the
collision
.
first
write to a track. Note that since
logical
