3
Getting Started

3.2 Installing Computer Mount

1. Using the 4 fix screws, tighten the VESA monitor mount on the back of the computer
monitor.
Figure 3-2
2. Attach the GV-NVR System Lite to the VESA monitor mount and tighten the stand screw.
Stand Screw
Figure 3-3
Note: For the mounting method of computer monitor, make sure your monitor is VESA
compliant. The supplied VESA monitor mount features the two mounting-hole patterns of 3" x
3" and 4" x 4".
7
