Chapter 2 Overview

2.1 Front and Left-Side View

1
2
3
4
5
6
7
No. Name
1 DVI Port
2 USB 2.0 Port
3 Giga LAN Port
4 Power Port
5 AUX Port
6 Base Stand Screw
7 Base Stand
8 Power Button
4
Figure 2-1
Description
Connects a monitor.
Connects USB devices.
Connects the switch or hub.
Connects to the power outlet.
Connects the speaker amplifier.
Fastens the Base Stand to the GV-NVR System Lite.
Supports the GV-NVR System Lite to stand.
Turns on the power of GV-NVR System Lite.
8
