Quick Start Guide
GV-RNVR256G0-N
The Vision of Security
Thank you for purchasing GV-SNVR. This guide is designed to assist the new user in getting
immediate results from the GV-SNVR. For advanced information on how to use the GV-SNVR, please
RNVR-QG-A
refer to GV-SNVR User's Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-RNVR256G0-N and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-RNVR256G0-N

Summary of Contents for GeoVision GV-RNVR256G0-N

  • Page 1 Quick Start Guide GV-RNVR256G0-N The Vision of Security Thank you for purchasing GV-SNVR. This guide is designed to assist the new user in getting immediate results from the GV-SNVR. For advanced information on how to use the GV-SNVR, please RNVR-QG-A...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    3.2 Live View Overview ....................11 3.2.1 Main Window ......................11 3.3 Recording Playback ....................13 3.3.1 Accessing the Playback Window on GV-RNVR256G0-N ........13 3.3.2 Exporting and Playing Recordings ................13 4. Remote Access via Web Client ................ 14 4.1 Basic System Requirements ................. 14 4.2 Looking Up the Dynamic IP Address ..............

  • Page 4: Introduction

    1. Introduction Welcome to the GV-RNVR256G0-N Quick Start Guide. In the following sections, you will learn about the basic installations and configurations. For more details, see GV-RNVR256G0-N User’s Manual. Note: The first time you run the NVR, you will be required to set your password immediately in order to protect your privacy.
  • Page 5 Solid on The device is operating properly. Power LED Not lit The device is shut down or not powered on. The hard disk is operating properly and no data Lit green is read or written. The hard disk is operating properly and there is HDD LED Flash green data read or written.

  • Page 6: Rear View

    1.2 Rear View Item Description Audio input Connected to an analog audio input device. Audio output Connected to an analog audio output device. Used to restore the factory settings. You can press and hold the button for 10 seconds to make the system automatically Reset button restore the factory settings, and the buzzer rings four times at the same time.
  • Page 7 Grounding Terminal Connect to the grounding cable. Note: The device only supports HDMI 1 output 8K. If the output resolution of HDMI 1 is set to 8K, the maximum output resolution of HDMI 3 and 4 will be limited to 1080P, and HDMI 2 will be disabled.

  • Page 8: Connection

    2. Connection 2.1 Connection Diagram...

  • Page 9: Hdd Installation

    2.2 HDD Installation The number of 3.5" SATA hard drives that the NVR can support varies depending on the model. The following procedures are for reference only. The practical operation may be different depending on the NVR you purchased. Caution: Do not install or remove the hard disk drive while the power is turned Remove the placeholder from the ejector lever.
  • Page 10 Open the front panel Press the buckles on the two sides on the upper part of the front panel and pull the front panel outwards. Insert the hard drive Align the hard drive slot and insert the hard drive gently and smoothly. Buckle up the hard drive and close the front panel Push in the hard drive until you hear a click.

  • Page 11: Power Supply Connection

    2.3 Power Supply Connection Caution: Only use the supplied power adapter that comes with the NVR. Connect one end of the power adapter to the power connector on the back of the NVR. Plug the other end of the power adapter into the wall outlet. And press the Power Switch to turn on the power.

  • Page 12: Getting Started

    3. Getting Started 3.1 Start Wizard 3.1.1 Start Wizard Click Start Wizard to proceed to the next step. 3.1.2 Connecting IP Cameras After finishing setting Network Configuration and Date and Time, this page appears.
  • Page 13 Click Search to search for IP cameras in the same network. Select the IP camera(s) you want to add, and then click icon to add to the NVR. Or, click button to manually add an individual IP camera to a single channel. This dialog box appears.

  • Page 14: Live View Overview

    3.2 Live View Overview 3.2.1 Main Window Name Description Camera Title Display channel number. Status Icon This indicates that the NVR is currently recording. This icon appears when the camera has detected motion. The icon indicates that the external I/O alarm device is triggered. This icon indicates that the HDD is in error to work.
  • Page 15 Located at the bottom of the live view screen. Refer to 4.2.2 Taskbar Task Menu Bar in the manual for details. No Camera: No camera is assigned. Failed to connect to camera, please check the network connection!: The added camera is off-lined or lost connection. User name or password error!: Incorrect user name or password of the camera.

  • Page 16: Recording Playback

    Select the desired files and click Start Download to download the video clips. Playing Video Clips Exported Locally or from the Web Interface of GV-RNVR256G0-N Install one of the following players:  GV-R Series Video Player ...

  • Page 17: Remote Access Via Web Client

    4. Remote Access via Web Client Use the Web Client to remotely access your NVR at any time via a PC. Before you access the Web Client, ensure that your PC’s system meets the basic requirements and that the network settings of the NVR are configured properly. 4.1 Basic System Requirements Item Minimum...

  • Page 18: Looking Up The Dynamic Ip Address

    4.2 Looking Up the Dynamic IP Address By default, when the NVR is connected LAN with DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address. Note: By default, the Administrator’s username is admin and cannot be modified. This function is only applicable on GV-IP Device Utility V8.9.8 or later.
  • Page 19 IMPORTANT: 1. To change the password using GV-IP Device Utility, click on the NVR’s IP address, and select Configure > Change Password. Or you can optionally change the password on the camera’s Web interface by clicking Config → Security → User ; see “Modify User” in 4.8.1 User Configuration in the user’s manual.

  • Page 20: Upgrading Firmware

    5. Upgrading Firmware You can upgrade the firmware either on GV-RNVR256G0-N or on the device remotely through GV-IP Device Utility. Follow the instructions below. 5.1 Upgrading Firmware on GV-RNVR256G0-N Copy the firmware file to your USB drive, and insert the USB drive to the NVR’s USB port.

  • Page 21: Upgrading Firmware Using Gv-Ip Device Utility

    5.2 Upgrading Firmware Using GV-IP Device Utility Note: This is only applicable to GV-IP Device Utility V9.0.1 or later. Make sure the PC used to configure the IP address is under the same LAN as the NVR. Download and install GV-IP Device Utility from our website. On the GV-IP Utility window, click the button to search for the IP devices connected in the same LAN.
