Eurotech Winner Series User Manual

Isdn bri to gsm gateway
Hide thumbs Also See for Winner Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Winner Series
BRI Gateway
ISDN BRI to GSM Gateway
Version 5.1

User Manual

Note:
The most updated Dual Cell BRI Gateway manual is located on our Web site, at:
www.gsm4voip.com
in the downloads section.
Check this site for latest updates.
Connecting Landline Phones
to Cell Phones directly
1/34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Winner Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eurotech Winner Series

Summary of Contents for Eurotech Winner Series

  • Page 1: User Manual

    Winner Series BRI Gateway ISDN BRI to GSM Gateway Version 5.1 User Manual Note: The most updated Dual Cell BRI Gateway manual is located on our Web site, at: www.gsm4voip.com in the downloads section. Check this site for latest updates.
  • Page 2 Without a notice and without obligation, the contents of this manual may be revised to incorporate changes and improvements. Every effort has been made to ensure that the information is complete and accurate at the time of publication. Nevertheless, Eurotech Communication cannot be held responsible for errors or commissions.
  • Page 3 3/34...

  • Page 4: Table Of Contents

    User Manual........................1 Getting Started ......................5 Check Your Package Items ................... 8 The Dual Cell BRI Gateway Solution Overview............9 Chapter 1: Installing SIM Cards and Connecting the Cables ........11 Chapter 1.1: Installing the SIM Cards ..............11 Chapter 1.2: Connecting the Cables ................

  • Page 5: Getting Started

    Getting Started Eurotech Communication team is glad you have chosen to use the Eurotech’s Dual-Cell GSM to BRI Gateway for your needs. We will do our best, to make your installation efforts as well as day-to-day configuration and monitoring tasks, to be as pleasant as possible. We wish you a smooth operation, while greatly saving on your office mobile phone calls.
  • Page 6 Mandatory – General configurations In order to operate the system, mandatory basic setup steps should be performed by using the serial RS-232 via PC COM port. Refer to “Chapter 3: Configurations with the BRI Management application”. Mandatory - System configuration Use the RS-232 connection and BRI Management MS-Windows application.
  • Page 7 system. Refer to “Chapter 7: Monitoring Calls and Reports” For getting the most updated product Info on the Web Refer to http://www.gsm4voip.com At menu: Cellular Gateways Please give us feedback to improve your BRI Gateway product Please let us know your feedback and enhancement ideas to improve the product to your best value.

  • Page 8: Check Your Package Items

    Check Your Package Items Please verify that your package contains the following components (some were ordered specifically) before installation: Main Hardware Device - The Dual Cell BRI Gateway 110/220V 50-60Hz Electric Power Converter to 12V with cables supplied Software Installation CD - Installation kit of the Dual Cell Manager CD for MS- Windows Management Application, including the User Manual file and additional auxiliary utilities.

  • Page 9: The Dual Cell Bri Gateway Solution Overview

    The Dual Cell BRI Gateway Solution Overview The Dual Cell BRI Gateway, that will be referred as the BRI Gateway in short, is a device that connects your desk phones directly to cellular phone networks. This gateway completely bypasses the local landline telephone company. Two desk phones can be connected to each Dual Cell Gateway via a phone switching unit (often a PBX type switch).
  • Page 10 The BRI Management MS-Windows application provides the following functionalities: Configuration Connections, ports, channels, SIM cards and operational modes can be configured Monitoring Call operations can be monitored from the management application. Therefore you may wish to leave the computer permanently connected to the Multi-Cell BRI system. Reports and statistics Call reports, calls history, antenna reception, status logs and more, can be generated for analysis with standard MS-Windows data processing tools such as MS-ACCESS...

  • Page 11: Chapter 1: Installing Sim Cards And Connecting The Cables

    Chapter 1: Installing SIM Cards and Connecting the Cables First you shall install the GSM SIM cards and later connect several cables and install the antennas to the BRI Gateway. Chapter 1.1: Installing the SIM Cards Insert the SIM cards into the Dual Cell as follows: On the bottom of the Dual Cell, open the SIM chambers by sliding the cover panels sideways.

  • Page 12: Chapter 1.2: Connecting The Cables

    Chapter 1.2: Connecting the Cables 12v power cable - The device power cable is supplied with a power supply converter for covering all main voltage electricity services in the world. Connect a 120V (North America), or 240V (Europe) power supply cable to the BRI-Cell Gateway. ISDN cable - The regular ISDN cable is used to connect the system to the PBX, serving the office landline phones.

  • Page 13: Chapter 2.1: Install The Bri Management Application Into An Ms-Windows Pc

    Before operation, configuration settings must be made in the Winner Series BRI Gateway. Configuration is done on an auxiliary computer by using the BRI Management MS-Windows Application provided for MS-Windows operating system. Chapter 2.1: Install the BRI Management Application into an MS-Windows PC Insert the BRI Management installation CD into the CD drive of the PC.

  • Page 14: Chapter 3: Configurations With The Bri Management Application

    Click Next. The Setup Type window will open. Select Complete and click next. The Begin Installation window will open. 8. Click Install. The BRI Management application installs itself. Wait until a completion message will appear. Chapter Configurations with Management Application 14/34...
  • Page 15 Connection between the PC and the BRI Gateway as described below. 1. Launch the BRI Management by pressing on your desktop, or by pressing: Start > Programs > Eurotech-Communication > BRI Management v5.1. The BRI Management application window will open. 15/34...
  • Page 16 Press in the toolbar. The Selected Connection window will open. Select the Com Port to which the Winner Series BRI Gateway is connected to. Select in the Connection Mode Com Port and press the OK button. Note: For the connection via TCP/IP see Appendix A.

  • Page 17: Chapter 4: Port And Sim Settings

    Chapter 4: Port and SIM Settings This chapter describes port dial settings, as well as timetables and channel locks for SIM cards in use. Chapter 4.1: Define Dial Settings for Each Port Press to define dial settings for each port. The Port Setting window opens. To define port dial settings, choose a port and proceed as described on the following pages.

  • Page 18: Chapter 4.2: Define Type Of Dialed Numbers Dispatch Mode

    Chapter 4.2: Define Type of Dialed Numbers Dispatch Mode You can define manual or automatic dispatch. Select the mode in which telephone numbers are dispatched to the GSM network. To dispatch phone numbers manually, in the Send Complete list, select HASH. In this mode, after you dialed all digits of a phone number, press to send the phone number.

  • Page 19: Chapter 4.3: Define Minimum Amount Of Time Between Outgoing Calls

    SIM. After making port settings, you MUST press Write Port Setting to send the settings to the Winner Series BRI Gateway unit. Then make settings for each SIM, as explained in the following section. Chapter 4.5: Define SIM Specifications In order to define a specific SIM setting you need to choose the specific SIM in the Port SIMs Tree on the left side of the main screen.
  • Page 20 Enter SIM specifications: 1. Enter the Predial number in the Predial number box. 2. Enter the PIN code of the SIM in the PIN CODE box. 3. Select a caller identification option in the Caller ID list: To enable the GSM network to set caller ID standards, select Network. To disable identification of the SIM, select CLIR Suppression.

  • Page 21: Chapter 4.6: Define The Sim Operator

    Chapter 4.6: Define the SIM Operator To assign the SIM to work with a specific GSM network, in the Operator ID, enter the GSM network operator ID, between 1–999999. Enter 0 to work with the SIM operator. 21/34...

  • Page 22: Chapter 5: Isdn And Time Settings

    Chapter 5.1: ISDN Settings Each Winner Series BRI Gateway has a master printed circuit board (PCB). The ISDN card is a small PCB mounted on the master PCB. The ISDN card is between ports in the Winner Series BRI Gateway and the external phones PBX switching unit.
  • Page 23 Continue settings in the ISDN configuration window as follows: 1. System Version is the version of the master card software in the PCB. 2. The ISDN module is a small PCB connected to the master PCB. The ISDN module has an EEPROM containing ISM software. The ISM version is the version of the ISM software.

  • Page 24: Chapter 5.2: Time And Date Setting

    Imitation Processing the ring back will begin automatically at the end of the alerting timer. 7. If you have more than one Winner Series BRI Gateway on site, enter the address of each Winner Series BRI Gateway unit in System Identification Number.

  • Page 25: Chapter 6: B-Channel - Port Association

    (example 6001 = 4 digits) ISDN (BRI) 2 x B- Channels Mapped into 2 operating GSM SIM Cards This chapter explains the assigning of B-channels to in-house phones and the allocation of calls to Winner Series BRI Gateway ports. 25/34...
  • Page 26 These settings are made in the B-channel/Port window. Press to open the B- Channel/Port setup window. This window is divided into four frames, as shown on the following page. 26/34...

  • Page 27: Chapter 6.1: B-Channel To In-House Phone Number Association

    Chapter 6.1: B-Channel to In-House Phone Number Association Assign office “in-house” phone number extensions to B-Channels In-house phone numbers are assigned in the lower left frame. Outgoing number refers to internal telephone numbers (For example, 6001 and 6002). For each channel that extends to a phone simply mark the check box, as shown in the screen snapshot above.

  • Page 28: Chapter 6.3: Network Prefixes Settings

    Chapter 6.4: Port Allocation Mode Settings The manner in which a phone call is directed to a port is determined in this frame. By Prefixes: if selected, then the Winner Series BRI Gateway directs a call through a port according to the defined prefixes table.

  • Page 29: Chapter 6.5: Make Port Settings

    Else, if one GSM network is designated for both ports, then select the manner in which ports will be selected: Cyclic indicates that ports will be selected in a cyclic manner: for example, if the first call is via port 1, the following call will be directed through port 2, the third call will be directed through port 1, and so forth.
  • Page 30 b) Click the remaining cell in the B-channel column and drag it to the row of the desired port. c) Drag the cell in the Stock column to the desired position in the B-channel column. After completing these steps, the Dual Cell is ready for operation. Calls can be monitored. 30/34...
  • Page 31 Chapter 7: Monitoring Calls and Reports This chapter explains how to monitor calls and review reports. Chapter 7.1: Monitoring Calls To monitor calls press: The monitor screen opens. GSM Network ID SIM Status Broadcast Control Channel Network Network Connection Status SIM Connection Status B-Channel Number Led Setting:...
  • Page 32 Left click on the play button will give you the port options: Disable port: disable or enable the port. Refresh port: reed the data from the port. DTMF Dialer: open DTMF dialer dialog box in it you can dial DTMF While Talking.

  • Page 33: Chapter 7: Monitoring Calls And Reports

    Chapter 7.2: Call Reports Press to review the call report. Press Start to view the last calls that were made. Press Access/CSV/XML to export the calls list to a file in that format. For Automatic exporting of the list to a file you need to define the Path of the file (above), the Format, the Check every timer and the Export every.

  • Page 34: Chapter 7.3: Dela

    Chapter 7.3: DELA Press to enter the DELA. DELA is a way to direct calls from a GSM number to specified extension. There are two ways to do that. 1. Unlimited DELA Calls – Enter the GSM number in the OUT/IN number box, enter the extension number in the Extension box, Press Add button to list them.
  • Page 35 Appendix A: TCP/IP Setting TCP/IP settings task list 1. Connect the BRI Gateway to your LAN via the COM connector. 2. Install the software Network Enabler Administrator which is provided on the installation CD at the directory LAN Tools. 3. Launch the software Network Enabler and click the SEARCH icon (upper left side) to find the BRI Gateway IP.
  • Page 36 5. Double click on the IP, then Press the Network tab. The next screen will open: 6. Check the Modify check box above the IP Address and enter the desired IP, press the Modify below to change Netmask and other settings; after you made changes, press the OK button.
