Heat & Glo PALOMA-BL Owner's Manual

Heat & Glo PALOMA-BL Owner's Manual

Paloma freestanding fireplace
Hide thumbs Also See for PALOMA-BL:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
PALOMA
FREESTANDING FIREPLACE
Model:
PALOMA-BL
PALOMA-BZ
PALOMA-GR
PALOMA-GY
• Important operating and
maintenance instructions
included.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas

- Do not try to light any appliance.

Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies suggests NFI certified or factory-trained
professionals, or technicians super-
vised by an NFI certified professional.
CAUTION
DO NOT DISCARD THIS MANUAL
• Read, understand and
follow these instructions
for safe installation and
operation.
• Alert children and adults to hazards of high temperatures.
• Do NOT operate with protective barriers open or removed.
• Keep clothing, furniture, draperies and other combustibles
This appliance may be installed as an OEM installation in manufactured
home (USA only) or mobile home and must be installed in accordance with
the manufacturer's instructions and the manufactured home construction
and safety standard, Title 24 CFR, Part 3280 or Standard for Installation
in Mobile Homes, CAN/CSA Z240MH.
This appliance is only for use with the type(s) of gas indicated on the
rating plate.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during oper-
ation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same
room as appliance.
away.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber or gas
fitter.
• a CO detector shall be installed in the room where the
appliance is installed.
7031-220G
Beaverton
Tested and
Oregon USA
Listed by
C
OMNI- Test Laboratories, Inc .
February 8, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PALOMA-BL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heat & Glo PALOMA-BL

Summary of Contents for Heat & Glo PALOMA-BL

  • Page 1: Do Not Try To Light Any Appliance

    Owner’s Manual Installation and Operation PALOMA FREESTANDING FIREPLACE Model: Beaverton Tested and Oregon USA Listed by PALOMA-BL OMNI- Test Laboratories, Inc . PALOMA-BZ PALOMA-GR PALOMA-GY CAUTION DO NOT DISCARD THIS MANUAL • Read, understand and • Important operating and • Leave this manual with...
  • Page 2 Read this manual before installing or operating this appliance. Please retain this owner's manual for future reference. Congratulations Congratulations on selecting a Heat & Glo gas appliance - an This Owner's Manual should be retained for future reference. elegant and clean alternative to wood burning appliances. We suggest that you keep it with your other important The Heat &...

  • Page 3: Table Of Contents

    - TABLE OF CONTENTS - Section 1: Listing and Code Approvals Section 8: Appliance Setup A. Appliance Certifications ......4 A. Remove Shipping Materials ....31 B. Glass Specifications ......4 B. Unbolting Appliance from the Pallet ..31 C. Specifications ........4 C. Leveling and Lagging Down the D.

  • Page 4: Section 1: Listing And Code Approvals

    Listing and Code Approvals C. Specifications A. Appliance Certification MODEL Paloma Maximum Minimum Orifice Steady AFUE Model Input Input Size State LABORATORY OMNI-Test Laboratories, Inc. (US or Canada) (DMS) Efficiency* 061-S-63-5 Paloma 30,000 22,500 82.5 TYPE Vented Gas Fireplace Heater (NG) ּ...

  • Page 5: Section 2: Getting Started

    Getting Started C. Inspect Appliance & Components A. Design & Installation Considerations Heat & Glo direct vent gas appliances are designed to oper- ate with all combustion air siphoned from outside of the WARNING building and all exhaust gases expelled to the outside. No additional air source is required.

  • Page 6: Section 3: Appliance Location & Clearances A. Selecting Appliance Location

    Appliance Location and Clearances NOTE: WARNING · Illustrations reflect typical installations and are FOR DESIGN PURPOSES ONLY. Fire Risk · Provide adequate clearance: Illustrations/diagrams are not drawn to scale. • Around air openings · Actual installation may vary due to individual design •...

  • Page 7: Optional Stone Surround Installed

    C. Optional Stone Surround Installed Model Paloma Surround 3-1/4 30-3/4 4-3/4 Inches Millimeters *Distance is measured from flue collar to corner Figure 3.1 It is permissable to place the appliance on carpet. WARNING CAUTION Fire Risk. • Locate and install appliance to all Some carpet materials may be sensitive to radiant heat from the clearance specifications in manual.

  • Page 8: Vent Termination Minimum Clearances

    Termination Locations A. Vent Termination Minimum Clearances HORIZONTAL OVERHANG WARNING 2 FT. 2 FT. Fire Risk. MIN. VERTICAL WALL Explosion Risk. LOWEST DISCHARGE Maintain vent clearance to combustibles OPENING as specified. TERMINATION • Do not pack air space with insulation or other materials.
  • Page 9 (See Note 2) U.S. (3 FT) Electrical Service J or K = VENT TERMINAL = AIR SUPPLY INLET = AREA WHERE TERMINAL IS NOT PERMITTED = 3 ft. (U.S.A.) = 12 inches ..... clearances above grade, veran- 6 ft. (Canada) ..clearance to a mechanical (See Note 1) da, porch, deck or balcony (powered) air supply inlet...

  • Page 10: Section 5: Vent Information

    Vent Information A. Venting Components B. Use of Elbows In order to comply with applicable codes and product warranties, use only following venting components: CAUTION • Hearth & Home Technologies (HHT) ALL vent configuration specifications MUST be followed. • Simpson Dura-Vent (SDV) •...

  • Page 11: How To Use The Vent Graph

    D. How to Use the Vent Graph E. Venting Guidelines Notes: Measure the distance from the top of appliance to the • The maximum horizontal vent run is 15 ft. (5m) when the center of the 90° elbow. On the graph below, draw a vertical vent rise is 10 ft.

  • Page 12: Horizontal Termination

    Step 2. F. Horizontal Termination Direct vent pipe is designed with a locking connection. To connect the venting system to the appliance flue outlet, a twist-lock adapter is built into the appliance at the factory. Wall thickness may vary. Remember to include wall thickness 90 DEGREE ELBOW in minimum clearances when figuring venting lengths for...
  • Page 13 WOOD SCREW CENTER OF HOLE CENTER LINE CENTER LINE WALL THIMBLE PART HHW2 PART 841-0670 (Preferred) Figure 5.6 WALL THIMBLE NOTES: (1) The four wood screws provided should be replaced with Figure 5.5 appropriate fasteners for stucco, brick, concrete, or other types of sidings.
  • Page 14 WARNING VINYL SIDING Fire Hazard. APPLY SEALANT TO ALL FOUR SIDES Exhaust Fume Risk. SCREWS Impaired Performance of Appliance. • Ensure vent components are locked together correctly. BOLT HORIZONTAL TOP TO VINYL STANDOFF • Pipe may separate if not properly joined. SCREWS WALL THIMBLE COVER...

  • Page 15: Vertical Termination

    G. Vertical Termination 1. Direct Vent Pipe VERTICAL TERMINATION CAP USE PART #SLK-991DA STORM COLLAR 40 ft. (12m) MAXIMUM FLASHING FIRESTOP SUPPORT PIPE LENGTH Figure 5.11 Step 2. et the gas appliance in its desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate On vertical terminations use only Part #SLK-991DA or the ceiling.
  • Page 16 Step 3. To install the round support box/wall thimble cover in a flat SHINGLES OVERLAP ON ceiling, cut a 10 in. (254mm) square hole in the ceiling, TOP EDGE OF FLASHING centered on the hole drilled in Step 2. Frame the hole as shown in Figure 5.13.
  • Page 17 Step 9. Twist-lock the vent cap and seal. Note: For multi-story vertical installations, a ceiling firestop is required at the second floor, and any subsequent floors (Figure 5.16). The opening should be framed to 10 in. x 10 in. (254mm x 254mm) inside dimensions, in the same manner as shown in Figure 5.13.
  • Page 18 2. Cathedral Ceiling Step 1. Follow installation Steps 1 and 2 under vertical installation section, page 15. Step 2. Remove shingles or other roof covering as necessary to cut the rectangular hole for the support box. Cut the hole 1/8 in. (3mm) larger than the support box outline.
  • Page 19 3. Class A Metal Chimney Step 4. Pass the flex pipe down through the center of the chimney system, and center the top adapter on the top of the chimney TERMINATION pipe. Drill four 1/8 in. (3mm) diameter holes through the CAP PART #SLK-991DA top adapter, and into the chimney top.

  • Page 20: Existing Masonry Chimney

    4. Existing Masonry Chimney Type B Type A CHIMNEY LINER TERMINATION CAP PART #923GK 3 in. (76mm) FLEX LINER CO-AXIAL TO CO-LINEAR CONNECTOR PART #923GCL PIPE LENGTH (OPTIONAL) SHOWING TWO 30 ft. (9m) SECTIONS OF FLEX LINER Type D - Hearth Mount Type C - Up &...
  • Page 21 CAUTION CUT AND BEND FLASHING AS NEEDED TO FIT CHIMNEY Ensure that existing chimney is functionally sound and clean. • Have inspection done by qualified chimney sweep or professional installer BEFORE converting to direct vent appliance. Step 1. Before cutting any holes, assemble the desired sections of direct vent pipe to determine the center of the masonry penetration.
  • Page 22 FLEX LINER 6 in. (152mm) DIAMETER OPENING IN MASONRY WALL FLEX COUPLER SHEET METAL RETRO CONNECTOR SCREWS THREE MASONRY BOLTS (NOT INCLUDED) Figure 5.27 Figure 5.29 Step 8. Secure the top adapter to the flashing. Use three sheet Step 10. metal screws through the side of the top adapter into the Slide wall thimble cover over retro connector and secure flange on the flashing (Figure 5.28).

  • Page 23: Slim Line Wall Thimble

    Slim Line Wall Thimble BEFORE YOU BEGIN: Review the venting configurations in Figures A, B and C on the next page. 1. Assembling Slim Line Trim Ring and Heat Shield Attach the heat shield to the trim ring with the four Figure 5.33 screws provided.
  • Page 24 FIG. A 90 DEGREE ELBOW Use HEAT SHIELD / WAL L THIMBL E Place mark where protrudes through exterior wall to cut off excess 90 DEGREE ELBOW CENTER LINE PIPE LENGTH TRIM RING HTI Vent HHW2 Part #841-0670 (recommended for optimum performance) PIPE LENGTH FIG.

  • Page 25: Section 6: Gas Information

    Gas Information PROCEDURE FOR CONVERSION: A. Fuel Conversions Turn off gas to appliance by closing the inlet line Before making gas connections ensure that the appliance valve. being installed is compatible with the available gas type. Turn off power to the module and valve. Any natural or propane gas conversions necessary to meet Remove the front door assembly, inner glass door the appliance and locality needs must be made by a qualified...
  • Page 26 14. Reinstall the bottom plate and valve assembly into the WARNING appliance. Reinstall the six hold down screws. 15. Reconnect the inlet gas line to the valve assembly and turn on the gas line valve. Check the incoming line for Fire Risk.

  • Page 27: Gas Pressures

    Verify the performance of the ignition system: B. Gas Pressures Verify pilot sparks, pilot lights, pilot stops sparking, and the main burner turns "ON". Proper input pressures required for optimum appliance per- formance, gas line sizing requirements need to be followed Turn the appliance "OFF".

  • Page 28: Gas Connection

    C. Gas Connection WARNING Fire Risk or Explosion Hazard. NOTE: Have the gas supply line installed in accordance with • Gas build-up during line purge may ignite. local building codes, if any. If not, follow ANSI Z223.1. Instal- • Purge should be performed by a qualified lation should be done by a qualified installer approved and/or technician.

  • Page 29: Section 7: Electrical Information

    Electrical Information A. Recommendation for Wire The thermostat should be mounted on an inside wall and not in direct line with the appliance convection air. See B5 below for recommended maximum lead length (two 10. If the thermostat is located too close to the appliance, wire) when using wall thermostat/switch.

  • Page 30: Loss Of Power & Battery Backup Usage

    IGNITION MODULE 3 VAC PLUG-IN 3V INTERMITTENT TRANSFORMER PILOT IGNITOR FLAME SPARKER/SENSOR ON/OFF WALL SWITCH IGNITION MODULE (3V) BATTERY VALVE PACK GROUND TO APPLIANCE CHASSIS REMOTE CONTROL NEUTRAL GROUND PIGGYBACK ON/OFF SWITCH TRANSFORMER 3 VAC PLUG IN VALVE JUNCTION BOX NOTE: Appliance will not operate unless properly grounded.

  • Page 31: Section 8: Appliance Setup

    Appliance Setup A. Remove Shipping Materials B. Unbolting Appliance from the Pallet Remove shipping materials from inside or underneath the The appliance is bolted and screwed to the pallet for ship- firebox. ping. Use a 1/2 in. socket to remove the bolt in center of bottom plate.

  • Page 32: Leveling And Lagging Down The

    C. Leveling and Lagging Down the Appliance LAGGING LAGGING THE APPLIANCE DOWN CLEARANCE HOLE IS REQUIRED. WARNING Tipping Risk • Install appliance on a stable, level platform/ floor strong enough to support appliance without tipping. • USE wood flooring, ceramic tile, brick hearth or high pressure laminate flooring applied directly over the sub-flooring material.

  • Page 33: Top To Rear Conversion

    E. Top to Rear Vent Conversion INNER EXTENSION COLLAR When installing this appliance in a rear vent configura- tion with no vertical rise, a Snorkel Kit must be used. KIT CONTENTS: Top cover (no hole); Back panel (with hole). TOOLS REQUIRED: Power drill; #2 Phillips bit; 5/32 in. (4mm) Allen wrench;...

  • Page 34: Shutter Adjustment

    ON TOP OF APPLIANCE: G. Installing the Vent Restrictor Install the cover plate removed from the rear of the appliance to the top of the appliance with the screws The vent restrictor plate must be installed before installing previously removed. (Figure 8.12) the baffle.

  • Page 35: Installing The Baffle

    H. Installing the Baffle The baffle is shipped wrapped, inside the firebox. Install the baffle with the embedded “T” side up, place it on top of the brackets on the inside of the firebox, ensuring back edge of baffle makes contact with the back of the firebox. Place log #1 into the cradle in the burner.

  • Page 36: Mineral Wool

    K. Optional Blower J. Mineral Wool The GFK-160A Blower has been designed to circulate room air through the appliance to enhance heat output. WARNING Explosion Risk. The GFK-160A blower system operates on 120 VAC, 60 • Follow ember placement instructions in Hz power.
  • Page 37 CAUTION BLACK WIRES All wiring should be done by a qualified electrician and shall be in compliance with local codes and with the National Electric Code ANSI/NFPA NO. 70-current (in the United States), or with the current CSA C22.1 Canadian Electric Code (in Canada). WARNING BLUE WIRE BLUE WIRE...
  • Page 38 Plug the blower cord into the FAN outlet on the junction box. NOTE: THE SWITCH/BRACKET ASSEMBLY MUST Refer to Figure 8.31, on the next page. BE INSTALLED SO THAT THE SENSOR SWITCH MAKES CONTACT WITH THE BOTTOM OF THE FIRE- Push excess wires neatly towards the rear of the appliance.
  • Page 39 Figure 8.31 Blower Wiring Diagram CAUTION Shock hazard. • Replace damaged wire with type 105 rated wire. • Wire must have high temperature insulation. February 8, 2006 Page 39 Heat & Glo · Paloma · 7031-220G...

  • Page 40: Remote Controls

    L. Remote Controls Remove the bag containing a washer and blue and red plungers from the side of the flame control solenoid. TOOLS REQUIRED: Powered screwdriver with Phillips Place washer on flame control solenoid. head bit; hex wrench; 7/16 in. wrench; manometer. Insert the correct plunger (blue - Natural Gas, red - LP) into the flame control solenoid.
  • Page 41 GAS CONTROL VALVE WASHER KNOB FLAME CONTROL WASHER SCREW SOLENOID JAM NUT PLUNGER VARIABLE REGULATOR VARIABLE REGULATOR FLAME CONTROL SOLENOID Figure 8.34 Blower Wiring Diagram REMOTE RECEIVER IGNITION MODULE INTERMITTENT 3 VAC PILOT IGNITOR TRANSFORMER 3 VAC ORANGE GROUND TO FIREPLACE CHASSIS PLUG RED JUMPER...

  • Page 42: Front Door Glass Assembly Installation

    M. Front Door Glass Assembly Installation N. Inner Glass Door Assembly Replacement Turn the appliance OFF and let it cool down before replacing Remove the front door assembly by pulling bottom of front away from appliance and lifting it off of the spring-loaded the inner glass door assembly.

  • Page 43: Section 9: Operating Instructions

    Operating Instructions A. Before Lighting Appliance WARNING Read this entire manual prior to using the appliance. Improper installation, adjustment, alteration, service or Failure to follow the instructions may result in property maintenance can cause injury or property damage. Refer to damage, bodily injury, or even death.

  • Page 44: Lighting Appliance

    C. Lighting Appliance IntelliFire Ignition System ® LIGHTING FOR YOUR SAFETY INSTRUCTIONS READ BEFORE LIGHTING (IPI) WA R NING: If you do not follow these instruction s 1. Turn off all electric power to the appli- exactly, a fire or explosion may result causing prop- ance.

  • Page 45: After Appliance Is Lit

    D. After Appliance is Lit CAUTION Initial Break-in Procedure • Prevent accidental appliance operation when not When you light your appliance, you may notice that it pro- attended. • Unplug or remove batteries from remote control if absent duces heat which does have an associated odor or smell. If or if appliance will not be used for an extended period you feel this odor is excessive it may require the initial three of time.

  • Page 46: Section 10: Troubleshooting

    Troubleshooting With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualified service technician. Symptom Possible Causes Corrective Actions 1.
  • Page 47 Symptom Possible Causes Corrective Actions 3. Pilot lights but a. A shorted or loose Verify all connections to wiring diagram in manual. Verify connections continues to spark, connection in sensor underneath pilot assembly are tight. Verify connections are not grounding and main burner will rod.

  • Page 48: Maintaining And Servicing Appliance

    Maintaining and Servicing Appliance Although the frequency of your appliance servicing and CAUTION maintenance will depend on use and the type of installation, a qualified service technician should perform an appliance check-up at the beginning of each heating season. Handle glass assembly with care. NOTE: Clean glass after initial 3-4 hours operation.

  • Page 49: Maintenance Tasks

    A. Maintenance Tasks Inspect Maintenance Tasks Doors 1. Inspect for scratches, dents or other damage and repair as necessary. 2. Verify no obstructions to air flow. 3. Verify maintenance of proper clearance to combustible household objects. Gasket Seal, Glass 1. Inspect gasket seal and its condition. Assembly and Glass 2.

  • Page 50: Section 12: Reference Materials

    Reference Materials A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. For clearances to combustibles refer to Section 3. Height includes 3/8 in (9.53mm) hearth pad. Hearth Pad Location Inches Millimeter Location Inches Millimeter 18-7/8 7-1/8 41-1/8 1045 40-3/4...

  • Page 51: Appliance Dimension With Stone Surround Diagram

    B. Appliance Dimension with Stone Surround Diagram Hearth Pad Height includes 3/8 in (9.53mm) hearth pad. Height includes 3/8 in (9.53mm) hearth pad. Location Inches Millimeter Location Inches Millimeter 29-5/8 16-7/8 24-3/8 34-5/8 30-1/4 44-5/16 1126 3-1/4 Figure 12.2 Appliance Dimensions with Stone Surround February 8, 2006 Page 51 Heat &...

  • Page 52: Vent Components Diagram

    C. Vent Components Diagram 6-3/8 in. (162mm) 6-1/2 in. (165mm) 9-1/4 in. (235mm) 6-1/2 in. (165mm) 9-5/8 in. 6-3/8 in. (244mm) (162mm) 6-5/8 in. (168mm) SL-45D 6-5/8 in. (168mm) 9-5/8 in. SL-90D (244mm) 17-24 in. 6-1/2 in. (432-610mm) (165mm) 11-3/4 in. (298mm) 5-3/4 in.

  • Page 53: Vent Components List

    D. Vent Components List COMPONENTS TERMINATION KITS 930D Ceiling Support / Wall Thimble, Black SLK-01TRD Trapezoid Termination Kit 7-3/4 inch - 11 inch, 2 Firestops Cathedral Ceiling Support, Black SLK-991DA Vertical Termination Cap - High Wind 908B 6 inch Pipe Length, Black 970D Horizontal Termination Kit (includes 904B, 907B...

  • Page 54: Service Parts List

    PALOMA Service Parts List Beginning Manufacturing Date: 7-11-05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: * Part number list on following page. Page 54 February 8, 2006 Heat & Glo · Paloma · 7031-220G...
  • Page 55 PALOMA Service Parts List (cont’d.) Beginning Manufacturing Date: 7-11-05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM DESCRIPTION SERIAL #...

  • Page 56: Firebox Assembly

    PALOMA Service Parts List (cont’d.) Beginning Manufacturing Date: 7-11-05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: Firebox Assembly ITEM DESCRIPTION SERIAL # PART # ITEM DESCRIPTION SERIAL # PART # Baffle Support 7031-137 Glass Frame Assembly 7031-015 Firebox Back and Sides Heat Shield 7031-129 Firebox Bottom...
  • Page 57 PALOMA Service Parts List (cont’d.) Beginning Manufacturing Date: 7-11-05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: Firebox Bottom Assembly ITEM DESCRIPTION SERIAL # PART # Bulkhead with Flex Tube 7000-156 Burner Assembly 7031-032 Burner Support,One-piece 7031-236 Elbow, 3/8 inch 200-0720 Firebox Bottom 7031-122...

  • Page 58: Accessories

    PALOMA Accessories Beginning Manufacturing Date: 7-11-05 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When ordering, supply serial and model numbers to ensure correct service parts. DESCRIPTION SERIAL # PART #...

  • Page 59: Warranty Policy

    G. Warranty Policy LIMITED LIFETIME WARRANTY HEAT & GLO GAS APPLIANCE PRODUCTS BASIC ONE-YEAR W ARRANTY. HEAT & GLO, a brand of HEARTH & HOME TECHNOLOGIES INC., located at 20802 Kensington Boulevard, Lakeville, MN 55044, (“HEAT & GLO”) warrants to the original owner that your new HEAT & GLO Gas Appliance (the “Product”) will be free from defects in materials and workmanship for a period of one year from the date of installation.

  • Page 60: Contact Information

    H. Contact Information CONTACT INFORMATION: Heat & Glo, a brand of Hearth & Home Technologies, Inc. 20802 Kensington Boulevard Lakeville, MN 55044 www.heatnglo.com Please contact your Heat & Glo dealer with any questions or concerns. For the number of your nearest Heat & Glo dealer, please call 1-888-427-3973 CAUTION Do NOT discard this manual.
