Troubleshooting
The clock is not running. What do I do?
Measure the input voltage to the clock. The voltage should measure 10-28 volts in the 2.5"/24VDC model and 16-28 volt in the 4.0"/24VDC
model.
Make sure the ground wire is not touching other wires.
NOTE: If you fail to follow the above instructions, the fuses can be blown.
The clock is not receiving an input signal. What do I do?
If interfacing with other systems, make sure that the input voltage is zero when not applying a correction signal. When taking this measurement,
you must be sure that the clock is disconnected from the master clock. Also, measure both AC & DC voltage. (The current consumption needed is
very low, about 3mA, and a leakage current from the master clock can be interpreted as a continuous reset signal. If you are experiencing such a
problem, please install a bypass mechanical relay).
There is data noise bleeding into the intercom line. What do I do?
Clock correction data wiring should be isolated from one way audio pairs.
Valcom, Inc.
+1 540-563-2000 P.
5614 Hollins Road
+1 540-362-9800 F.
Roanoke, VA 24019
www.valcom.com
USA
12
