CFETF10xx-110
Cable Specifications
CFETF1011-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CFETF1013-110
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CFETF1014-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1015-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1016-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1017-110
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
The fiber optic transmitters on this device meet Class I Laser safety requirements per
IEC-825/CDRH standards and comply with 21 CFR1040.10 and 21CFR1040.11.
8
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
-- Continued
1310 nm multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
1310 nm multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
1310 nm single mode
min: -15.0 dBm max: -8.0 dBm
min: -31.0 dBm max: -8.0 dBm
16.0 dB
1310 nm single mode
min: -5.0 dBm max: -2.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1310 nm single mode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1550 nm single mode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB

Technical Specifications

For use with Transition Networks Model CFETF10xx-110 or equivalent.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
Standards IEEE 802.3™
Data Rate 100 Mb/s
Dimensions 3.4" x 5.0" x 0.87" (86 x 182 x 22 mm)
Weight 3 oz (91 g) (approximate)
Power Consumption 3.5 watts, 200 mA @ 13.9 VDC
MTBF** 406,000 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
1,593,000 hours (Bellcore7 V5.0)
Environment Tmra*:
Storage Temp:
Humidity
Altitude
Warranty Lifetime
*Manufacturer's rated ambient temperature: Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.
**MTBF is estimated using the predictability method. This method is based on MIL-
217F and Bellcore standards at 40°C ambient temperature, typical enclosure heat rise
of 10°C, and nominal operating conditions and parameters. Installation and
configuration specific MTBF estimates are available upon request. Contact Technical
Support.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into the
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
CAUTION: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232,
RS422, RS485, DS1, DS3, Video Coax, etc., are intended to be connected to intra-
building (inside plant) link segments that are not subject to lightening transients or
power faults. Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB,
RS232, RS422, RS485, DS1, DS3, Video Coax, etc., are NOT to be connected to inter-
building (outside plant) link segments that are subject to lightening transients or power
faults.
The information in this user's guide is subject to change. For the most up-to-date
information on the CFETF10xx-110 media converter, view the user's guide on-line at:
www.transition.com.
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
0 to 60°C (32 to 140°F )
-20 to 85°C (-4 to 185°F )
5 to 95%, non condensing
0 to 10,000 feet
