Technical Specifications - Transition Networks CFETF10 Series User Manual

CFETF10xx-205
CABLE SPECIFICATIONS
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate:
Singlemode fiber (recommended):
Multimode fiber (recommended):
Multimode fiber (optional):
CFETF1011-205
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CFETF1013-205
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CFETF1014-205
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1015-205
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1016-205
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1017-205
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CFETF1018-205
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
8
Tech Support: 1-800-260-1312 Int'l: 00-1-952-941-7600 7am-6pm CST (GMT-6:00)
-- Continued
<10-9
9 µm
62.5/125 µm
100/140, 85/140, 50/125 µm
1300 nM multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
1300 nM multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
1300 nM singlemode
min: -15.0 dBm max: -8.0 dBm
min: -31.0 dBm max: -8.0 dBm
16.0 dB
1300 nM singlemode
min: -8.0 dBm max: -2.0 dBm
min: -34.0 dBm max: -7.0 dBm
26.0 dB
1310 nM singlemode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1550 nM singlemode
min: -5.0 dBm max: 0.0 dBm
min: -34.0 dBm max: -7.0 dBm
29.0 dB
1300 nM multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB

TECHNICAL SPECIFICATIONS

For use with Transition Networks Model CFETF10xx-205 or equivalent
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
Standards IEEE 802.3™
Data Rate 100 Mb/s
Dimensions 2.9" x 4.8" x 1.4" (74 x 122 x 36 mm)
Weight 8 oz (227 g) (approximate)
Power Consumption 3.5 watts, 200 mA @ 13.9 VDC
MTBF 382,956 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
1,456,260 hours (Bellcore7 V5.0)
Environment Tmra*:
Storage Temp:
Humidity
Altitude
Warranty Lifetime
*Manufacturer's rated ambient temperature: Tmra range for this Slide-In-Module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this Slide-In-Module will be
installed.
CAUTION: Visible and Invisible Laser Radiation When Open. Do Not Stare
Into Beam Or View Directly With Optical Instruments.
CAUTION: Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous radiation exposure.
techsupport@transition.com -- Select the "Transition Now" Link for a Live Web Chat
0 to 60°C (32 to 140°F )
-20 to 85°C (-4 to 185°F )
5-95%, non condensing
0-10,000 feet
9
