Transition Networks C/F-SM-MM-04(LH) User Manual

COMPLIANCE INFORMATION

UL Listed
C-UL Listed (Canada)
CISPR/EN55022 Class A
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the user will be
required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on
the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes
Rundfunkstörungen auftreten, in weichen Fällen der Benutzer für entsprechende Gegenmaßnahmen
werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées
Trademark Notice
All registered trademarks and trademarks are the property of their respective owners.
Copyright Restrictions
© 1997-2001 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means –
graphic, electronic, or mechanical – without written permission from TRANSITION Networks.
Printed in the U.S.A.
C/F-SM-MM-04, C/F-SM-MM-04(LH), C/F-SM-MM-04(LW)
Media
Conversion
Center
Power Modules
1
2
Management
Module
TRANSITION Networks C/F-SM-MM-04 series media converters, designed to be
installed in the TRANSITION Networks E-MCC-1600 Media Converter Chassis,
connect 850nm(SX) and 1300nm(LX) fiber in the full-duplex or half-duplex gigabit
(1000Mb/s ) Ethernet™ environment
C/F-SM-MM-04
Provides an RX (receive) and TX
(transmit) SC connector to 850 nm
multimode fiber-optic cable and an RX
(receive) and TX (transmit) SC
connector to 1300 nm singlemode or
1300 nm multimode fiber-optic cable
C/F-SM-MM-04(LH) (long haul)
Provides an RX (receive) and TX
(transmit) SC connector to 850 nm
multimode fiber-optic cable and an RX
(receive) and TX (transmit) SC
connector to 1310 nm singlemode
fiber-optic cable
NOTE: In conformance with the
IEEE 802.3z standard, the 1300nm
singlemode fiber-optic connector
also can be used with 1300nm
multimode fiber-optic cable.
33045.E
850nm/1300nm Gigabit Fiber
Slide-In-Module Media Converters
USER'S GUIDE
Power
In Use
Power
In Use
Power
Link
TX
RX
.
C/F-SM-MM-04(LW) (long wave)
Provides an RX (receive) and TX
(transmit) SC connector to 850 nm
multimode fiber-optic cable and an RX
(receive) and TX (transmit) SC
connector to 1550 nm singlemode
fiber-optic cable
C/F-SM-MM-04 in the Network . . . . .2
Installation . . . . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . . . . .4
Fault Isolation and Correction . . . . .5
Cable Specifications . . . . . . . . . . . . .6
Technical Specifications . . . . . . . . . .7
Compliance Information . . . . . . . . . .8
