Technical Specifications

For use with Transition Networks Model SBFTF10xx-10x or equivalent.
Data Rate
Dimensions
Weight
Power Consumption
Power Supply
MTBF
Packet Size:
Filtering & Forwarding 14,880 pps for Ethernet; Rate 148,800 pps for Fast Ethernet
Environment
Storage Temp
Humidity
Warranty
Compliance Safety:
For current information on the
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view the beam
directly with optical instruments. Failure to observe this warning could result in an eye injury or
blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than those specified
herein may result in hazardous radiation exposure.
*MTBF is estimated using the predictability method. This method is based on MIL-217F and Bellcore
standards at 40°C ambient temperature, typical enclosure heat rise of 10°C, and nominal operating
conditions and parameters. Installation and configuration specific MTBF estimates are available upon
request. Contact Technical Support.
CAUTION: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1,
DS3, Video Coax, etc., are intended to be connected to intrabuilding (inside plant) link segments that are
not subject to lightening transients or power faults. Copper based media ports, e.g., Twisted Pair (TP)
Ethernet, USB, RS232, RS422, RS485, DS1, DS3, Video Coax, etc., are NOT to be connected to inter-
building (outside plant) link segments that are subject to lightening transients or power faults.
Failure to observe this caution could result in damage to equipment.
33404 Rev. G
10 Mbps; 100 Mbps, Layer 2
Width: 3.25" [82.55 mm] x Depth: 4.8" [121.92 mm] x Height: 1" [25 mm]
2 lbs. [0.90 kg]
3 watts
12 VDC, 0.8 Amp (N. America, Europe, Japan, UK)
12 VDC, 1.25 Amp (Latin Am., Australia, N.Z., S. Africa)
(external power supply provided with this product is UL listed by the
manufacturer.)
Greater than 41,660 hours (MIL-HDBD-217F)
Greater than 114,580 hours (Bellcore7 V5.0)
Unicast MAC address: 1K
Maximum packet size:
- 2048 bytes untagged bytes
- 2044 bytes tagged bytes
Tmra*: 0 to 50°C (32 to 122°F) (Manufacturer's rated ambient temperature)
-15 to 65°C (-15 to 149°F)
5 to 95%, non condensing
Lifetime
Wall Mount Power Supply: UL Listed;
FCC Class A, VCCI Class 1, CISPR22/EN55022
Class A, EN55024, EN61000, CE Mark
SBFTF10xx-10x see the online user guide at https://www.transition.com.
https://www.transition.com
SBFTF10xx-10x User Guide
