Mixing
Acoustic echo cancellation (AEC)
Feedback elimination
Level control
Equalization
Noise cancellation
The system is designed to optimize audio capture/reproduction by providing:
Consistent audio input from all participants
Minimum room noise
Mute control
Wireless encryption
Automatic channel selection
Full duplex audio.
The Charger Base stores and charges the wireless microphones when not in use.
Charger Base also serves as a programming station for the microphones, should firmware
updates to the microphones be required.
Installing the Revolabs Executive HD ™ Base Station
The Revolabs Executive HD ™ Base Station, shown below in front and rear panel views,
manages wireless audio signal processing, pairing, and muting between the Revolabs
microphones and the Base Station.
Front View
2
1
3
Rear View
7
8
6
11
13
12
10
9
4
14
- 4 -
The
5
